Adax Neo S5 Quick Instruction Manual

Adax Neo S5 quick instruction guide

Please follow the easy instructions below for the initial set up and

programming of your new Adax Neo S5 heater.

The Adax Neo S5 heater is fully ERP 2018 compliant and will allow

the user to program one on/off period each day to help you manage

the running costs effectively.

You will now follow the instructions to set the "OFF" times within

your programming schedule.

Note: When you have set the clock to the correct time it will not

automatically show the correct time in say 50 minutes. The clock is

set once at the correct time and knows where it is in the

background settings. Do not worry that the time setting has not

moved forward.

 Install the heater in the required position following the

detailed instruction drawings inside the heater box.

 Plug the heater into the power supply and turn the heater On

at the switch on the right hand side – Switch should be

pointing to I.

 The heater will display 20 in the small screen. Using the + or –

on the side of the heater set your ideal room temperature

now e.g 22. This will be the temperature that you require

when the heater is running a program.

 The red light in the display may come on indicating the heater

is operating.

 Now you need to set the day of the week and the current

time.

 Push OK button constantly for 5 seconds until "td" is displayed

 Release then push "OK" again once.

Table of Contents

Need help?

Do you have a question about the Neo S5 and is the answer not in the manual?

Page 1 Please follow the easy instructions below for the initial set up and programming of your new Adax Neo S5 heater. The Adax Neo S5 heater is fully ERP 2018 compliant and will allow the user to program one on/off period each day to help you manage the running costs effectively.
Page 2  A number will be displayed. Set the day of the week using the + or – buttons. 1 = Monday.  Push “OK” once.  Now the hours will appear in 24 hour format. Set the current hour and push “OK” once. ...
Page 3  Set the temperature by using the + or – buttons. 5 is effectively frost protection but most people set between 10 – 15 to ensure if the room gets cold the heater will turn on and maintain say 12 degrees C to keep the damp at bay. ...
Page 4 “OK” once. The green light will now illuminate on the screen to show the programs are now active. The Neo S5 can be manually adjusted whilst it is running a programmed schedule. If you want more or less heat simply push the + or –...
