BLUETOOTH DONGLE

The Bluetooth dongle provided helps connect your non-Bluetooth enabled TV or device to the Sobro table.
If you have a smart TV with Bluetooth built-in, you may not need the Bluetooth dongle to connect the audio from your TV to the Sobro table.
LED Indicator Light Bluetooth Button AUX IN Jack
Front
Setup & Assembly Connect to the Sobro table:
1. Connect the Micro USB plug to the 1. Power on the dongle by pressing the
Micro USB jack on the back of the dongle. Bluetooth button and to get ready to pair.
2. Connect the USB end into the power adapter 2. Wait for 5 seconds and the dongle will
and then into a wall outlet to power the dongle. connect to the Sobro table automatically.
3. Connect either the 3.5mm cable or RCA cable 3. Put Sobro in TV mode.
to the AUX IN jack on the back of the dongle
4. When connecting, the blue LED indicator
based on the outputs of your TV or device.
light will pulse.
4. Connect either the 3.5 mm or RCA plugs to
5. When the Bluetooth connection is
the audio output of your TV or device.
completed, the LED indicator will stop
5. Press the Power/Bluetooth button once to flashing.
start the dongle.
6. To turn off the dongle, press and hold the
Bluetooth button for 5 seconds.
22 ∙ bluetooth dongle
Micro USB
Jack
Back
Press Icon Lights Up
Bluetooth: Default Mode
After powering on the Sobro table, the Bluetooth icon on the display
will automatically light up and flash. On the device you want to
pair with the Sobro (mobile phone, tablet, Smart TV, etc...) begin
Bluetooth pairing mode. Pair with the device called "SOBRO." When
paired, the Bluetooth icon will illuminate steadily.
Specific procedures for Bluetooth Only one Bluetooth-enabled
pairing may vary from device to device can be paired with the
device. Check the user manual Sobro at a time. To connect a new
of your device for specific Bluetooth-enabled device, unpair
instructions about Bluetooth the first one, or press and hold the
pairing. In some cases, you may "Source" button to disconnect.
need to enter a password on your NOTE: Please keep the pairing
mobile device to pair. range within 10 meters.
If so, type in the password 0000.
AUDIO SELECTION
Press Icon Lights Up
TV Mode:
This mode is designed for pairing the table with the Bluetooth dongle.
First, power on the table. To select the TV mode, press the "Source"
button until the TV icon on the display screen lights up.
Press Icon Lights Up
Audio Input Mode:
When you have selected the AUX input, the "AUX In" logo will illuminate.
Connect a 3.5mm audio cable (provided) between your device and
the Sobro Coffee Table. You can now control the playback with your
connected device. The USB ports do not support audio input.
audio selection ∙ 23
