nordictrack.com

Model No. 24860.2

Serial No.

Write the serial number in the space

above for reference.

Serial Number

Decal

ACTIVATE YOUR

WARRANTY

To register your product and

activate your warranty today,

go to my.nordictrack.com.

CUSTOMER CARE

For service at any time, go to

nordictrackservice.com.

Or call 1-800-TO-BE-FIT

(1-800-862-3348)

Mon.–Fri. 6 a.m.–6 p.m. MT

Sat. 8 a.m.–12 p.m. MT

Please do not contact the store.

CAUTION

Read all precautions and

instructions in this manual before

using this equipment. Save this

manual for future reference.

USER'S MANUAL

Table of Contents

Need help?

Do you have a question about the 24860.2 and is the answer not in the manual?

Questions and answers

Summary of Contents for NordicTrack 24860.2

Page 1 Model No. 24860.2 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to my.nordictrack.com. CUSTOMER CARE For service at any time, go to nordictrackservice.com.
Page 2 NORDICTRACK and IFIT are registered trademarks of ICON Health & Fitness, Inc. App Store is a trademark of Apple Inc., registered in the U.S. and other countries. Android and Google Play are trademarks of Google Inc. The BLUETOOTH word mark and logos are registered trademarks of Bluetooth SIG, Inc.
Page 3: Important Precautions
5. The treadmill is intended for home use only. 17. To purchase a surge suppressor, see Do not use the treadmill in any commercial, your local NORDICTRACK dealer, call the rental, or institutional setting. telephone number on the front cover of this manual, or see your local electronics store.
Page 4 19. Always stand on the foot rails when starting able to safely lift 45 lbs. (20 kg) to move the or stopping the walking belt. Always hold the treadmill. handrails while using the treadmill. 26. When folding or moving the treadmill, make 20.
Page 6 STANDARD SERVICE PLANS...
Page 7: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the new NORDICTRACK ® manual. To help us assist you, note the product model T 6.7 S treadmill. The T 6.7 S treadmill provides an number and serial number before contacting us. The...
Page 8: Part Identification Chart
PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.
Page 9: Assembly
• Left parts are marked “L” or “Left” and right parts are marked “R” or “Right.” 1. Go to my.nordictrack.com on your computer and register your product. • activates your warranty • saves you time if you ever need to contact Customer Care •...
Page 10 2. Make sure that the power cord is unplugged. Remove the tie securing the Upright Wire (81) to the front of the Base (6). Next, identify the Right Upright (90). Have a second person hold the Right Upright near the Base (6).
Page 11 4. Hold the Right Upright (90) against the Base (6). Make sure not to pinch the Upright Wire (81). Attach the Right Upright (90) with two 3/8" x 2 3/8" Screws (7), a 3/8" x 1 1/4" Screw (63), a 3/8" x 1 3/4" Screw (62), and four 3/8" Star Washers (13) as shown;...
Page 12: Surface To Avoid Scratching The Console Base
6. If there are four screws (E) preattached inside the Handrails (84), remove and discard the screws. Attach a Handrail (84) to the Right Upright (90) with two 5/16" x 3" Screws (28) and two 5/16" Star Washers (11); start both Screws, and then tighten them.
Page 13 8. IMPORTANT: To avoid damaging the Pulse Crossbar (31), do not use power tools and do not overtighten the #10 x 1 1/4" Screws (9). Orient the Pulse Crossbar (31) as shown. Attach the Pulse Crossbar to the Handrails (84) with four #10 x 1 1/4"...
Page 14 10. Set the console assembly (G) on the Handrails (84). Make sure that no wires are pinched. Insert the excess Upright Wire (81) into the Right Upright (90). Attach the console assembly (G) to the brack- ets on the Handrails (84) with four 1/4" x 1/2" Screws (4);...
Page 15 12. Raise the Frame (56) to the upright position. Have a second person hold the Frame until step 14 is completed. Remove the two 5/16" x 3/4" Screws (8) from the Latch Crossbar (41). Orient the Latch Crossbar (41) as shown. Make sure that the “This side toward belt”...
Page 16 14. Remove the 5/16" Nut (34) and the 5/16" x 2 1/4" Bolt (25) from the bracket on the Latch Crossbar (41). Align the upper end of the Storage Latch (26) with the bracket on the Latch Crossbar (41), and insert the 5/16"...
Page 17: How To Use The Treadmill
HOW TO USE THE TREADMILL HOW TO CONNECT THE POWER CORD more amps. To avoid overloading the circuit, do not plug other electrical devices, except for low- Use a Surge Suppressor power devices such as cell phone chargers, into the surge suppressor or into an outlet on the same Your treadmill, like other electronic equipment, can be circuit.
Page 18 CONSOLE DIAGRAM FEATURES OF THE CONSOLE To turn on the power, see page 19. To use the man- ual mode, see page 19. To use an onboard workout, The treadmill console offers a selection of features see page 21. To use a custom-focus weight loss designed to make your workouts more effective and workout, see page 22.
Page 19 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
Page 20 4. Change the incline of the treadmill as desired. Vertical Distance (VRT FT or VRT M)—The distance you have walked or run in vertical feet or To change the incline of the treadmill, press the vertical meters. Incline increase and decrease buttons or one of the numbered Quick Incline buttons.
Page 21 6. Measure your heart rate if desired. HOW TO USE AN ONBOARD WORKOUT You can measure your heart rate using either the 1. Insert the key into the console. handgrip heart rate monitor or a compatible heart rate monitor. For information about purchasing See HOW TO TURN ON THE POWER on page 19.
Page 22 4. Follow your progress with the display. 5. Follow your progress with the displays. See step 5 on page 20. See step 5 on page 20. The display will show the time or calories remaining instead of the elapsed 5. Measure your heart rate if desired. time.
Page 23 3. Connect your tablet to the console. THE SETTINGS MODE Press the iFit Sync button on the console; the 1. Select the settings mode. console pairing number will appear in the display. Then, follow the instructions in the iFit Bluetooth To select the settings mode, press the Settings Tablet app to connect your tablet to the console.
Page 24 Display Test—This screen is intended to be used Demo Mode—The currently selected demo mode by service technicians to identify whether the option will appear in the display. The console display is working correctly. features a demo mode, designed to be used if the treadmill is displayed in a store.
Page 25 THE OPTIONAL CHEST HEART RATE MONITOR HOW TO ADJUST THE CUSHIONING SYSTEM Whether your The treadmill features a cushioning system that goal is to reduces the impact as you walk or run on the treadmill. burn fat or to strengthen your Remove the key from the console and unplug the cardiovascular power cord.
Page 26: Fcc Information
FCC INFORMATION This console has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 27: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.
Page 28: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING MAINTENANCE c. Check the power switch located on the treadmill frame near the power cord. If the switch protrudes Regular maintenance is important for optimal per- as shown, the switch has tripped. To reset the formance and to reduce wear. Inspect and properly power switch, wait for five minutes and then press tighten all parts each time the treadmill is used.
Page 29 SYMPTOM: The walking belt slows when walked on SYMPTOM: The walking belt is not centered between the foot rails a. Use only a surge suppressor that meets all of the speciﬁ cations described on page 17. The edges of the walking belt should be aligned with the belt alignment marks (see the drawing below) on b.
Page 30: Exercise Guidelines
EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
Page 31: Part List
PART LIST Model No. 24860.2 R0817A Key No. Qty. Description Key No. Qty. Description #8 x 5/8" Screw Drive Roller/Pulley #8 x 3/4" Screw Left Inner Base Cover Base Pad Right Inner Base Cover 1/4" x 1/2" Screw 3/8" Plastic Bushing #10 Star Washer 1/4"...
Page 32: Exploded Drawing
EXPLODED DRAWING A Model No. 24860.2 R0817A...
Page 33 EXPLODED DRAWING B Model No. 24860.2 R0817A...
Page 34 EXPLODED DRAWING C Model No. 24860.2 R0817A...
Page 35 EXPLODED DRAWING D Model No. 24860.2 R0817A...
Page 36: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...

This manual is also suitable for:

T 6.7 s Ntl59018.0
