Marco Beverage Systems Ltd.
INSTRUCTIONS FOR MODELS
QWIKBREW 2 TWIN 5.6kW
QWIKBREW 2 TWIN 8.4kW
Water pressure : 5 - 50 psi (min.-max.)35 - 345 kPa (min.-max.)
Marco Beverage Systems Limited.
63d Heather Road,
Sandyford Industrial Estate,
Dublin 18.
Ireland Tel: +353 (0)1 295 2674
Ireland Fax: +353 (0)1 295 3715
email: sales@marco.ie
www.marco.ie
(P/N: 1000495)
(P/N: 1000485)
Marco Beverage Systems Limited.
Shire House, Strixton Manor,
Strixton, Wellingborough, Northants,
NN29 7PA
UK Tel: +44 (0)2072 744 577
UK Fax: +44 (0)2079 788 141
email: sales@marco-bev.co.uk
www.marco-bev.co.uk
Advertisement
Table of Contents
Related Manuals for Marco Beverage Systems QWIKBREW 2 TWIN 5.6kW
Summary of Contents for Marco Beverage Systems QWIKBREW 2 TWIN 5.6kW
- Page 1 Marco Beverage Systems Ltd. INSTRUCTIONS FOR MODELS QWIKBREW 2 TWIN 5.6kW (P/N: 1000495) QWIKBREW 2 TWIN 8.4kW (P/N: 1000485) Water pressure : 5 - 50 psi (min.-max.)35 - 345 kPa (min.-max.) Marco Beverage Systems Limited. Marco Beverage Systems Limited. 63d Heather Road,...
- Page 2 Electrical installation: Electrical specification: 5.6 kW/230V ac & 6 kW/230V ac. This unit must be connected to a suitable single phase power supply. This should be done by a qualified electrician. Electrical specification: 8.4kW/400V ac. 3 PHASE ...
- Page 3 Time until first Time until Power Recovery rate brew tank is full 5.6kW 39 minutes 50 minutes 0.9 Litres/minute 36 minutes 47 minutes 1.0 Litres/minute 8.4kW 26 minutes 34 minutes 1.4 Litres/minute OPERATION: The Marco Qwikbrew 2 Twin uses the ‘Continuous fill cycle’ as standard. Continuous Fill Mode (Standard): ...
- Page 4 When the machine has enough water to brew coffee, the green ‘Ready to Brew’ lights illuminate (after approximately 26-39 minutes depending on power). A brew can be selected at this point, but the machine is NOT full yet and will continue to fill. After approximately 34-50 minutes (depending on power) the heaters will shut off.
- Page 5 A brew should only be selected whenever the green ‘Ready to brew’ lights are illuminated in order to produce the highest quality of coffee possible. (the brew light turns on when there is enough water at the correct brewing temperature. If there is enough water yet it is not at optimum temperature, it is possible to brew but the brew light will not be illuminated) ...
- Page 6 TROUBLESHOOTING: The Marco Qwikbrew 2 Twin uses an electronic diagnostic system to help determine faults. If an error is detected a sequence of flashes is displayed through the POWER light. This sequence is repeated (cycled) until: 1. The problem is rectified by a service agent, or 2.
- Page 7 MAINTENANCE: Marco machines have been designed to give many years of trouble free service. The only regular maintenance required is occasional de-scaling. In common with all water boiler manufacturers, service calls resulting from limescale are not covered by warranty. Fitting a scale reducer is recommended, especially in hard water areas.
- Page 8 SAFETY: This appliance must be earthed. Risk of flooding. The hose supplied with this unit is non-toxic food quality tested to 190psi. However, a hose is not a permanent connection. It is, therefore, advisable to switch off boiler and close the stopcock valve when boiler is not in use, e.g. overnight, weekends etc.
