Northern Lights Everbright BR31 Owner's Manual page 8

Assembly Stage #5
Allen Key(1)
1. Remove the handlebar post cover (72) from main frame, and set in handlebar post (12).
2. Connect the heart rate cable upper (16) and lower (19).
3. Connect the cable wire upper (15) and lower (18).
4. Set the handlebar post (12) in main frame, and fix it with screw M8x16L (13) and
semicircle washer (14).
Assembly Stage #6
1. Set the front handlebar (3) with handlebar post. And fix it with allen bolt M7x30mm (7),
sprubf washer
7 Allen Bolt M7* 8 Flat washer
9 Spring Washer
P1.0*30mmL *(1) 7* 12*1T * (1) 7*2t *(1)
Allen Key(1)
flat washer
φ7*2t (9), and φ7*φ12*1T (8).
