Power Team C12-HTR series Operating Instructions And Parts List Manual

SPX Corporation
5885 11th Street
Rockford, IL 61109-3699 USA
Internet Address:
http://www.powerteam.com
C12-HTR / 12-HTR REMOTE HYDRAULIC
TOOL SECTION:
1.81 (4.60 CM) DIA.RAM, .96 (2.44 CM) STROKE WITH DIES.
CRIMPING FORCE, 13.1 U.S. TONS AT10,000 PSI (11.9 METRIC TONS
AT 70,000 kPA (700 BAR)
OIL TYPE USED, AMOCO RYKON MV.
OVERALL DIMENSIONS:
2.75 x 4.87 x 10.25 INCHES LONG (6.98 x 12.37 x 26.03 CM LONG)
TOTAL WEIGHT, 10.3 LBS. WITH OIL (4.7 kg WITH OIL)
CRIMPING CAPACITY:
NO.8 THRU 500 MCM CU GROUNDING TERMINALS AND SPLICES
NO.8 THRU 250 MCM CU GROUNDING TAPS AND 3/4 INCH GROUND ROD
NO.8 THRU 750 MCM CU INSULATED AND UNINSULATED TERMINALS
NO.8 THRU 750 MCM CU ALUMINUM TERMINALS
NO.8 THRU 350 MCM CU ALUMINUM SPLICES
NO.6 THRU 556.5 26/7 ACSR STRANDING
COUPLERS:
MALE COUPLER ASSEMBLY (Power Team Part No. 25599)
© 2005 SPX Corporation
®
Tech. Services: (800) 477-8326
Fax: (800) 765-8326
Order Entry: (800) 541-1418
Fax: (800) 288-7031
CRIMPING TOOL
INTRODUCTION
The 12-HTR compression head was designed for installing
tubular compression connectors on electrical conductors.
The 12-HTR remote compressor is a light weight, remote
powered, hydraulic tool that can be operated in any position.
The single acting cylinder develops twelve tons of thrust at
10,000 psi (68.9 MPa). Any pump capable of this pressure,
with a safety valve setting between 9,600 psi (66.2 MPa) and
10,400 psi (71.7 MPa) may be used.
The 0.92 inch (23.4 mm) open C-head permits the
compressor to be hooked over the conductor or accessory,
and the die locking devices allow it to be moved along without
accidentally dislodging the die halves.
SPECIFICATIONS
Form No. 1000023A
Operating Instructions and
Parts List for:
C12-HTR-C SERIES
WARNING
THE 12 HTR AND C12-HTR TOOL IS NOT TO BE USED
FOR "HOT LINE" WORK.
Sheet No.
Rev 1
12-HTR SERIES
1 of 5
Date: 13 June 2005
