Telldus PAN11-1 Manual

This plug-in ON/OFF switch PAN11 is a wireless switch, based on Z-Wave
TM
technology. Z-Wave enabled devices displaying the Z-Wave
used with it regardless of the manufacturer, and can also be used in other
TM
manufacturer's Z-Wave enabled networks. Remote On/Off control of the connected
load is possible with other manufacturer's wireless Controller. Each switch is
designed to act as a repeater. Repeaters will re-transmit the RF signal to ensure that
the signal is received by its intended destination by routing the signal around
obstacles and radio dead spots.
This plug-in ON/OFF switch is able to detect overload of connected lights or
appliances. When detecting overload state, the Switch will be disabled and its On/Off
button will be lockout of which LED will flash quickly. However, unplug and re-
connect the switch will reset its overload condition to normal status.
TM
Adding to Z-Wave Network
Note: Auto inclusion timeout is 4 minute during which the node information of
explorer frame will be emitted once several seconds. Unlike "inclusion" function as
TM
logo can also be shown in the table below, the execution of auto inclusion is free from pressing the
On/Off button on the Switch.
The table below lists an operation summary of basic Z-Wave functions. Please refer
to the instructions for your Z-Wave
Setup function, and to include/exclude/associate devices
Function
No node ID
Inclusion
1
TM Certificated Primary Controller to access the
Description
The Z-Wave Controller does not allocate
a node ID to the Switch.
1. Have Z-Wave Controller entered
inclusion mode.
2. Pressing On/Off button three times
within 1.5 seconds will enter
LED Indication
2-second on, 2-second off
Press On, for on
Press Off, for off
