Technical Data

The device is intended to be used in the engine room or on the engine directly.
HW Modification
RS-485
isolated
InteliVision 5
No
InteliVision 5
Yes
Remote
Display
Power Supply
Value
Voltage supply
Consumption depends on supply
voltage
Hint:
InteliVision 5 should be use with the same battery as the control unit. When external battery is needed
because of long wiring and etc.. InteliVision 5 RD is recommended to use.
Operating Conditions
Operating temperature
Storage temperature
Flash memory data retention time
Protection front panel
Humidity
Standard Conformity
Low Voltage Directive
Electromagnetic Compatibility
Vibration
Dimensions and Weight
Dimensions
Weight
InteliVision 5-1.1 Reference Guide ©ComAp – December 2011
Distance Binary
[m] Output
2 No
1000 Yes
Controller
8-36V DC
1,1A at 8VDC
-40...+70
-30...+80
10 years
IP65
85% without condensation
IEC/EN 60068-2-30
EN 61010-1:95 +A1:97
EN 61000-6-3
EN 61000-6-4
EN 61000-6-1
EN 61000-6-2
EN 60068-2-6
Front panel 245x164mm
LCD display cutout 175x115mm
855g
Analog Backlit
Input (Display
Buttons)
No No
Yes Yes
IV5 Display
8-36V DC
0,7A at 8 VDC
o
C
o
C
Protected Internal
IP buzzer
IP-65 No
(face)
IP-65 Yes
(face)
41
