Page 1: User Guide
G2201 GSM Mobile Phone User Guide Huawei Technologies Co., Ltd. Address: Huawei Industrial Base, Bantian, Longgang, Shenzhen 518129, People's Republic of China... - Page 2 Tel: +86-755-28780808 Global Hotline: +86-755-28560808 E-mail: mobile@huawei.com Website: www.huawei.com Copyright © Huawei Technologies Co., Ltd. 2009. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd.
- Page 3 Huawei Technologies Co., Ltd reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation. NO WARRANTY THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”.
- Page 4 Table of Contents SIM Card ............1 Charging the Battery ........1 Your Phone............ 2 Keys and Functions ........3 Screen Icons ..........5 Using the Function Menu......... 6 Phone Lock ........... 6 PIN and PUK..........7 Locking the Keypad ........7 Making a Call..........
-
Page 5: Sim Card
SIM Card Insert your SIM card before using your phone. Remove the SIM card and the battery only after powering off your phone. The following figures show the installation of the SIM card. 1. Remove the battery cover. 3. Insert the battery. 2. -
Page 6: Your Phone
Disconnect the charger from the phone. Disconnect the charger from the AC power socket. Your Phone The following figure shows the appearance of your phone and it is for your reference only. Earpiece # key Screen End/Power key Navigation keys 10 Right soft key Left soft key 11 Confirm key... -
Page 7: Keys And Functions
Call/Answer key 12 Charger jack Number keys 13 Headset jack * key Keys and Functions In this manual, the navigation keys of your phone are indicated by the follow icons: Press… To… Make a call. Answer an incoming call. View dialed calls in standby mode. Power on or off the phone (by pressing and holding the key for about 5s). - Page 8 Press… To… Access: Profiles ( ), Messages ), Create Message ( ), and Alarm Clock ( ) in standby mode. During a call, increase the volume ( or decrease the volume ( Display Menu in standby mode. Confirm a selection. Enter numbers, letters, and characters.
-
Page 9: Screen Icons
Press… To… Enter #. Lock the keypad in standby mode (by pressing and holding it for about 3s). Change text input modes when editing texts. Screen Icons Icon Indicates Signal strength. New text message(s). The SMS memory is full when the icon is blinking. -
Page 10: Using The Function Menu
Icon Indicates The My profile is activated. Using the Function Menu In standby mode, press (Menu) or Press to select the desired function menu. Press (Select) or to display the selected menu. Press to select the desired submenu. Press (Select) or to display the submenu. -
Page 11: Locking The Keypad
PIN and PUK The personal identification number (PIN) protects your SIM card from unauthorized use. The PIN unblocking key (PUK) can unlock the blocked PIN. Both PIN and PUK are delivered with the SIM card. For details, consult your service provider. If you enter wrong PINs for a specified number of times consecutively, the phone asks you to enter the PUK. -
Page 12: Answering A Call
code. Then enter the country code or region code, area code, and phone number in sequence. To call an extension, enter the phone number, press twice consecutively to insert P, and then enter the extension number. Press to dial the number. Press to end the call. -
Page 13: Text Input Modes
Text Input Modes The indicator of the current text input mode is displayed on the upper left corner of the screen. You can press to change the text input mode. Indicator Text Input Mode ABC, Abc and abc Multi-tap input mode Predictive input mode Number input mode Press... - Page 14 Predictive Input Mode In predictive input mode, do as follows to enter a word: Press each key only once according to the spelling sequence of the desired word. The phone displays the commonly used word according to the numeric sequence of key presses. Press to scroll to the desired word.
-
Page 15: Writing And Sending A Message
You can also press to change lines in the symbol list, and then press the number key to enter the symbol labeled with the corresponding number. Writing and Sending a Message Select Menu > Messages > Create Message. Edit the message. Press and then select Send. -
Page 16: Fm Radio
FM Radio The headset cable also functions as an antenna. To ensure good reception of radio programs, do not bend the headset cable extremely. Insert the headset to the headset jack properly. Choose Menu > FM Radio to activate the FM radio. After loading, the phone plays a program. -
Page 17: Warnings And Precautions
Warnings and Precautions This section contains important information pertaining to the operating instructions of your device. It also contains information about how to use the device safely. Read this information carefully before using your device. Electronic Device Power off your device if using the device is prohibited. Do not use the device when using the device causes danger or interference with electronic devices. - Page 18 explosion or a fire, resulting in bodily injuries or even deaths. Do not power on your device at refueling points such as service stations. Comply with restrictions on the use of radio equipment in fuel depots, storage, and distribution areas, and chemical plants. In addition, adhere to restrictions in areas where blasting operations are in progress.
- Page 19 the device may hurt you owing to the strong force when the air bag inflates. Do not use your device while flying in an aircraft. Power off your device before boarding an aircraft. Using wireless devices in an aircraft may cause danger to the operation of the aircraft and disrupt the wireless telephone network.
- Page 20 ambient temperature between -10°C to 55°C for using the device powered by a battery. Prevention of Hearing Damage Using a headset at high volume can damage your hearing. To reduce the risk of damage to hearing, lower the headset volume to a safe and comfortable level. Safety of Children Comply with all precautions with regard to children's safety.
- Page 21 Do not connect two poles of the battery with conductors, such as metal materials, keys, or jewelries. Otherwise, the battery may be short-circuited and may cause injuries and burns on your body. Do not disassemble the battery or solder the battery poles.
- Page 22 malfunction of the device, and an electric shock to the user. Do not place your device, battery, and charger in places where they can get damaged because of collision. Otherwise, it may lead to battery leakage, device malfunction, overheating, fire, or explosion. Do not place magnetic storage media such as magnetic cards and floppy disks near the device.
- Page 23 Emergency Call You can use your device for emergency calls in the service area. The connection, however, cannot be guaranteed in all conditions. You should not rely solely on the device for essential communications. Certification Information (SAR) This mobile device meets guidelines for exposure to radio waves.
- Page 24 (2) his device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications made to this device not expressly approved by Huawei Technologies Co., Ltd. may void the FCC authorization to operate this device.
- Page 25 Version: V100R001_01 NO.: 6015XXX...
