Bayan Audio SILVERPOINT User Manual

Hi-fi speaker system
Hide thumbs
Table of Contents

Advertisement

Quick Links

SILVERPOINT
USER GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SILVERPOINT and is the answer not in the manual?

Questions and answers

Related Manuals for Bayan Audio SILVERPOINT

Summary of Contents for Bayan Audio SILVERPOINT

  • Page 1 SILVERPOINT USER GUIDE...
  • Page 3 Contents Connecting your speaker to other equipment Welcome Bluetooth Bluetooth Pairing Important Safety Instructions Pairing with NFC FCC Regulations Controlling the volume for Bluetooth music Recycling Optical Auxiliary Quick Start Controlling the volume for Auxiliary source music Configuring your speaker using WPS Configuring your speaker from Android Installing the StreamQ App Configuring your speaker from iOS...
  • Page 4 Thank you for your purchase of a Bayan Audio SilverPoint Hi-Fi speaker system. We hope that this product will bring you many years of enjoyment, and welcome you to the world of HD Digital music throughout your home.

  • Page 5: Important Safety Instructions

    Important Safety Instructions Please read these instructions and then keep them safely for future reference Heed all warnings and follow all instructions in this manual Only clean this product with a dry, lint free cloth Do not block any vents, and only install in accordance with the manufacturer’s instructions Do not use this product near to any heat sources such as radiators, heaters, cookers or other devices (including amplifiers) that produce heat Do not use this product near to water or wet surfaces...
  • Page 6 FCC Regulations Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 7: Quick Start

    Quick Start Unbox your speakers and check that you have the following parts: Active speaker Passive speaker 4-way speaker connection cable Mains power cable Speaker grill covers Remote control Active speaker Passive 4-way Main Speaker Remote speaker speaker power grill covers control connection cable...
  • Page 8 Quick Start (continued) Position your speakers as desired and locate the nearest mains power outlet to the speakers. The active speaker may go on the left or the right – it does not matter at this stage. Connect the active speaker to the passive speaker using the 4-way speaker connection cable. Tighten the locking nut being careful not to cross the threads –...
  • Page 9 Configuring your speaker using WPS Power on your speaker and wait for a white light indicating it WiFi has finished its initialisation. Press the WPS button on your Router (see your router’s Bluetooth instruction manual for help). You now typically have up-to 2 minutes to go to the speaker and press the WPS button.
  • Page 10 Configuring your speaker from Android Power on your speaker and wait for a white light indicating it has finished its initialisation. Swipe down from the top of the screen and choose to search for a new wifi network. Select your new speaker from the list of available wifi networks.
  • Page 11 Next you will need to select the name of the Wi-Fi network to which you wish to connect the speaker from the ‘Network Name’ drop down selection box. If your network is not listed, please check the router is turned on, and that your android device is connected to it.

  • Page 12: Speaker Overview

    Speaker overview Status Lights The status lights can be found on the front of the active loudspeaker next to the tweeter (small speaker). White Wi-Fi / Network input selected Blue Bluetooth input selected White Optical input selected Standby mode Red flashing Speaker is initialising White Auxiliary input selected...

  • Page 13: Remote Control

    Remote Control Power Wake speakers from standby or put to sleep Mute Silence the speakers until mute is pressed again Bluetooth Selects the Bluetooth as the current input mode Pair Disconnect any Bluetooth devices currently connected to the speaker, and allow new devices to pair.

  • Page 14: Back Panel

    Back Panel Power This is the main power on / off switch for the loudspeaker Internet Used to connect your speaker to the network using an RJ45 Ethernet cable (where Wi-Fi signal is weak or not available, or for best performance) L Aux connect the left channel of auxiliary equipment such as CD players here...
  • Page 15 Connecting your speaker to other equipment Bluetooth Select the Bluetooth input either with the remote control or by short pressing the Volume / Input knob to the rear of the product. Your speaker will automatically connect to the last Bluetooth audio source it was used with (if available) – if not you will be able to search for it and pair in the normal way Bluetooth Pairing You can use Bluetooth Secure Simple Pairing to connect and stream music:...
  • Page 16 First, turn on your android device and unlock the screen (ensuring that NFC is enabled in the settings) Next, Touch the back of your audio source to the back cover of the remote control for your Silverpoint Speaker. (Note – if you have multiple Silverpoint Speakers, you will need to remember which remote goes with which speaker, as the NFC chips in the remotes are individually coded to the speaker during manufacture).
  • Page 17 Optical Ensure that your audio source is connected via an Optical (S/PDif) cable to the rear of the active speaker, and is switched on. Select the Optical input either with the remote control or by short pressing the Volume / Input knob to the rear of the product. Auxiliary Ensure that your audio source is connected via a stereo RCA lead to the rear of the active speaker, and is switched on and playing music.
  • Page 18 Installing the StreamQ App Android Installation Launch the Play Store on your Android device and search for ‘Bayan StreamQ’, the official Bayan App which has this icon: Install the StreamQ App to your mobile device. Ensure that your android device is on the same WiFi network as your speakers, then tap on the StreamQ App to launch it. iOS Installation Launch the App Store on your mobile device, and search for ‘Bayan StreamQ’, the official Bayan App which has this icon: Install the StreamQ App to your mobile device.

  • Page 19: Troubleshooting

    Troubleshooting What File Formats can I stream to the Speakers from the StreamQ App? StreamQ supports MP3, AAC, AAC+, FLAC, WAV, ALAC and PCM file formats up to 192KHz sampling rate and 24 bit resolution. Updating the Speaker Firmware From time to time new firmware will be released for the speakers to add new functionality. This can be downloaded and updated easily over the internet.

  • Page 20: Specifications

    Troubleshooting (contd) To perform a factory reset, turn on your speaker and wait for the RED light to stop flashing (indicating it has completed its initialisation) At the rear of the speaker, locate the button labelled ‘WIFI MODE’. Press and hold this button for 5 seconds, then let go. The RED light at the front will flash as the speaker restarts.
  • Page 21 Specifications SILVERPOINT SP1 SILVERPOINT SP2 Power Output 24W stereo 40W stereo Frequency Response 80Hz – 20KHz 50Hz – 20KHz <0.3% <0.3% Driver Configuration 3” paper cone, 1” silk dome 4” glass fibre cone, 1” silk dome Amplifier Configuration Class D Bi-Amped with digital crossover...
  • Page 22 3rd Party Licenses Boost http://www.boost.org/ Boost Software License – Version 1.0 – August 17th, 2003 Permission is hereby granted, free of charge, to any person or organization obtaining a copy of the software and accompanying documentation covered by this license (the “Software”) to use, reproduce, display, distribute, execute, and transmit the Software, and to prepare derivative works of the Software, and to permit third-parties to whom the Software is furnished to do so, all subject to the following: The copyright notices in the Software and this entire statement, including the above license grant, this restriction and the following disclaimer, must be included in all copies of the Software, in whole or in part, and all derivative works of the Software, unless such copies or derivative works are...
  • Page 23 FastDelegate http://www.codeproject.com/KB/cpp/FastDelegate.aspx THE WORK (AS DEFINED BELOW) IS PROVIDED UNDER THE TERMS OF THIS CODE PROJECT OPEN LICENSE (“LICENSE”). THE WORK IS PROTECTED BY COPYRIGHT AND/OR OTHER APPLICABLE LAW. ANY USE OF THE WORK OTHER THAN AS AUTHORIZED UNDER THIS LICENSE OR COPYRIGHT LAW IS PROHIBITED.
  • Page 24 License Grant (contd) • The Articles discussing the Work published in any form by the author may not be distributed or republished without the Author’s consent. The author retains copyright to any such Articles. You may use the Executable Files and Source Code pursuant to this License but you may not repost or republish or otherwise distribute or make available the Articles, without the prior written consent of the Author.
  • Page 25 Indemnity You agree to defend, indemnify and hold harmless the Author and the Publisher from and against any claims, suits, losses, damages, liabilities, costs, and expenses (including reasonable legal or attorneys’ fees) resulting from or relating to any use of the Work by You. Limitation on Liability EXCEPT TO THE EXTENT REQUIRED BY APPLICABLE LAW, IN NO EVENT WILL THE AUTHOR OR THE PUBLISHER BE LIABLE TO YOU ON ANY LEGAL THEORY FOR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL, PUNITIVE OR EXEMPLARY DAMAGES ARISING OUT OF THIS LICENSE...
  • Page 26 libogg http://www.xiph.org/ogg/ Copyright (c) 2002, Xiph.org Foundation Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: • Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. •...
  • Page 27 Tremolo http://wss.co.uk/pinknoise/tremolo Copyright (C) 2002-2009 Xiph.org Foundation Changes Copyright (C) 2009-2010 Robin Watts for Pinknoise Productions Ltd Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: • Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. •...
  • Page 28 Mersenne Twister http://www.math.sci.hiroshima-u.ac.jp/~m-mat/MT/MT2002/CODES/mt19937ar.c Copyright (C) 1997 – 2002, Makoto Matsumoto and Takuji Nishimura, All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.
  • Page 29 CURL http://curl.haxx.se COPYRIGHT AND PERMISSION NOTICE Copyright (c) 1996 – 2011, Daniel Stenberg, <daniel@haxx.se>. All rights reserved. Permission to use, copy, modify, and distribute this software for any purpose with or without fee is hereby granted, provided that the above copyright notice and this permission notice appear in all copies.
  • Page 30 Contact For customer support, please contact us at www.bayanaudio.com UK Telephone 0844 800 3480...
