Salini SRR-6222W Instruction Manual

Range hood
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
R AN GEH OOD
R AN GEH OOD
R AN GEH OOD
R AN GEH OOD
OV EN B UILT IN
Instruction Manual
Instruction Manual
Instruction Manual
Instruction Manual
Instruction Manual
SRC-8535B
SRC-9535S
SRC-3335S
SRC-3332S | SRC3335S
SOB-5002H

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRR-6222W and is the answer not in the manual?

Questions and answers

Related Manuals for Salini SRR-6222W

Summary of Contents for Salini SRR-6222W

  • Page 1 OV EN B UILT IN R AN GEH OOD R AN GEH OOD R AN GEH OOD R AN GEH OOD Instruction Manual Instruction Manual Instruction Manual Instruction Manual Instruction Manual SOB-5002H SRC-3332S | SRC3335S SRC-3335S SRC-9535S SRC-8535B...
  • Page 2 TABLE OF CONTENTS Important safety information Installation Using your appliance Cleaning and maintenance Troubleshooting Technical data Declaration of conformity IMPORTANT: This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...

  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION General Information  Carefully read the following important information regarding installation safety and maintenance. Keep this information booklet accessible for further consultations.  The appliance has been designed as an exhausting version (external exhaust) or as a filter version (inter air recycle) range hood.
  • Page 4  Disconnect the electrical plug prior to any maintenance or cleaning.  Cleaning should be carried out in accordance with the “Cleaning and Maintenance” section to avoid possible hazards.  If the power cord is damaged it must be replaced by the manufacturer or a qualified service engineer.

  • Page 5: Installation

    INSTALLATION INSTRUCTIONS The range hood should be placed at a distance of 65-75cm from the cooking surface for best effect. 65cm 75cm Installation Option 1: (See drawing below)  To install onto the wall, mark and drill 4 holes of Ø8mm according to the dimensions on the diagram.

  • Page 6: Installation

    Installation Option 2: (See drawing below)  Drill 6 holes of 4mm diameter at the bottom of the hanging cupboard according to the dimensions in the diagram.  Put the air outlet on the range hood, then install the range hood underneath the cupboard, tighten the hood with enclosed 6 screws.

  • Page 7: Using Your Appliance

    USING YOUR APPLIANCE  Connect the plug into the power.  Push the switch ① in “ ”, to turn the light on; push into “0”, to turn the light off.  Push the switch ② in “I or II”, the hood has two speeds “low or high”, push into “0”, to turn the hood off.

  • Page 8: Cleaning And Maintenance

    CLEANING AND MAINTENANCE  It is recommended to operate the appliance prior to cooking.  There shall be adequate ventilation of the room when the range hood is used at the same time as appliances burning gas or other fuels. (Not applicable to appliances that only discharge the air back into the room.) ...
  • Page 9  Replace the light globe. See pic 5  Carbon filter (not supplied)  Carbon filters can be used to trap odours. Normally the activated carbon filter should be changed at three or six months according to your cooking habits. Activated carbon filters cannot be washed or recycled.

  • Page 10: Troubleshooting

    TROUBLESHOOTING If you suspect that your appliance is not functioning correctly, we advise you read below troubleshooting information to help you identify and asses how to best rectify any issues. Servicing of the appliance must only be carried out by an authorised service representative and the appliance must not be modified.

  • Page 11: Technical Data

    TECHNICAL DATA Specifications Model SRR-6222W Width 600mm Depth 280-430mm Height/Max Height 176mm Extraction/ Max Air Flow 440m3/h Functions/Speed Noise When Working 56 dB(A) Rated Voltage 220-240V Max Rated Inputs (Total power) 280W -10-...

  • Page 12: Declaration Of Conformity

    DECLARATION OF CONFORMITY Australian Standards This product has been designed and manufactured to comply with all relevant Australian and New Zealand Standards. AS/NZS 60335.1 General Requirements for Domestic Electrical Appliances AS/NZS 60335.2.6 Specific Requirements for Domestic Electrical Cooking Appliances This appliance is SAA certified Installation of the appliance must be only be undertaken by a licenced electrician who can provide a compliance certificate.
