Summary of Contents for Salini SRC-8535B
- Page 1 OV EN B UILT IN R AN GEH OOD R AN GEH OOD RE C T R AC TAB LE R AN GEH O O D R AN GEH OOD Instruction Manual Instruction Manual Instruction Manual Instruction Manual Instruction Manual SOB-5002H SRC-3332S | SRC3335S SRC-3335S...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important safety information Installation Using your appliance Cleaning and maintenance Troubleshooting Technical data Declaration of conformity IMPORTANT: This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION General Information Carefully read the following important information regarding installation safety and maintenance. Keep this information booklet accessible for further consultations. This appliance is designed for domestic household use and designed be used indoors only. ... - Page 4 Do not check the status of the filters while the cooker hood is operating. The range hood and its filter mesh should be cleaned regularly in order to keep in good working order. Do not touch the light bulbs after appliance use. ...
-
Page 5: Installation
INSTALLATION INSTRUCTIONS Before installation, please ensure the area is clean to avoid suction of any remaining bits of broken wood and dust. The range hood cannot share the same air ventilation tube with other appliances such as gas tubes, warmer tubes, and hot wind tubes. ... - Page 6 The range hood should be placed at a distance of 65-75cm (26-30inch) from the cooking surface for the best effect. See Pic 1. Install the hooks on the wall according to the installation height and keep it level. The fixed position of the inside chimney bracket is the place of chimney.
-
Page 7: Using Your Appliance
USING YOUR APPLIANCE Features The range hood uses high quality materials in a streamlined design. Equipped with a powerful electric motor and centrifugal leaf; it produces strong suction, low noise and an easy to clean non-stick grease filter. ... - Page 8 Press button once, the hood will work at the speed which it works last time. Press button again, the hood stop working. The time button works when the motor is working only. Press , the cooker hood enter into timer setting mode. The max delay time is 9 min, and the LED display will display “9”.
-
Page 9: Cleaning And Maintenance
CLEANING AND MAINTENANCE Cleaning Of Carbon Grease Filter Mesh The filter mesh is made of high-density stainless steel. Please do not use a corrosive detergent on it. Keeping this filter clean will keep the appliance running correctly. Follow the guidelines below. -
Page 10: Troubleshooting
TROUBLESHOOTING If you suspect that your appliance is not functioning correctly, we advise you read below troubleshooting information to help you identify and asses how to best rectify any issues. Servicing of the appliance must only be carried out by an authorised service representative and the appliance must not be modified. -
Page 11: Technical Data
TECHNICAL DATA Specifications Model SRC-8535B Width 900mm Depth 500mm Height/Max Height 550-1030mm Extraction/ Max Air Flow 700m3/h Functions/Speed Noise When Working 60 dB(A) Rated Voltage 220-240V Max Rated Inputs (Total power) 194W -10-... -
Page 12: Declaration Of Conformity
DECLARATION OF CONFORMITY Australian Standards This product has been designed and manufactured to comply with all relevant Australian and New Zealand Standards. AS/NZS 60335.1 General Requirements for Domestic Electrical Appliances AS/NZS 60335.2.6 Specific Requirements for Domestic Electrical Cooking Appliances This appliance is SAA certified Installation of the appliance must be only be undertaken by a licenced electrician who can provide a compliance certificate.
