Summary of Contents for Appliance AWDH 124
- Page 1 AWDH 124 GEBRAUCHSANWEISUNG BRUGSANVISNING INSTRUCCIONES DE USO MANUEL D'UTILISATION KÄYTTÖOHJE OPERATING MANUAL...
- Page 2 Filter grating Air directional flap Fresh air system Power cord Outdoor Indoor DISPLAY RED LED power supply is connected YELLOW LED timer is on GREEN LED compressor is on BLUE LED night mode is on spirit level 3° INCLINATION...
- Page 3 LIFT IT UP LIFT IT UP HERE HERE Soft terminal Hard terminal Rubber cup Water LIFT IT UP HERE LIFT IT UP HERE...
- Page 4 Please contact your local authority for regulatory advice. Do not switch on before having totally assembled the air conditioner and before installing in its correct operating position. Before starting the appliance, check that it is correctly earthed, according to the legislation in force in the country concerned.
- Page 5 1.2 IMPORTANT SAFETY INSTRUCTIONS Install the device only when it complies with local regulations, by-laws and standards. The unit is only suitable for use in dry locations, indoors. Check the mains voltage and frequency. This unit is only suitable for earthed sockets, connection voltage 220 - 240 V. / 50 Hz. IMPORTANT - The device MUST always have an earthed connection.
- Page 6 Any batteries used in the remote control contain materials, which are hazardous to the environ- ment. They must be removed from the remote control when they reach the end of their life and disposed of responsibly. 1.6 TECHNICAL FEATURES(P1,P2) Model AWDH 124 Cooling capacity * W (BTU/h) 2400 (8200) Heating capacity * W (BTU/h)
- Page 7 2. INSTALLATION 2.1 POSITIONING THE AIR CONDITIONER (P3) To maintain the best performance from your air conditioner, prevent breakdowns or hazards, you must position it correctly. Please follow the guidelines and instruction below in full, as failure to do so could cause potential installation problems. - The air conditioner must be installed on an exterior wall that has access to the outside with a minimum of 2 meters clearance to the outside.
-
Page 8: Introduction
DRAINAGE HOLE (P13) This air conditioner has a double system to drain the condensated moisture automatically. Before installing the Air Conditioner choose which is the suitable system for your installation. Please read carefully the follow instructions. System “A”: drill a hole through the wall measuring 30 mm in diameter in the position shown in the paper template. -
Page 9: Installation
The appliance should not be installed in a wett cell. The appliance must be positioned so that the plug is accessible The appliance shall be installed in accordance with national wiring regulations. 3. USE AND MAINTENANCE 3.1 INTRODUCTION OF LCD ICONS... -
Page 10: Remote Control Functions
3.2 REMOTE CONTROL FUNCTIONS MODE BUTTON: Set up the air conditioner operating mode ON / OFF BUTTON: Turn on or turn off the air UP BUTTON: Increase the temperature and time DOWN BUTTON: Decrease the temperature and time FAN SPEED BUTTON: Set up the fan speed TIMER ON BUTTON: Set up the time the air conditioner starts... -
Page 11: Cooling Mode
3.4 Cooling mode Sequence of the operations Press the ON/OFF button “ ”, switch on the air conditioner, it will run by memory mode. Press the MODE button “ ” set up the mode to cool “ ”, the air conditioner will run in cooling. -
Page 12: Fan Mode
3.6 Fan mode Sequence of the operations Press the ON/OFF button “ ”, switch on the air conditioner, it will run by memory mode. Press the MODE button “ ” set up the mode to fan “ ”, the air conditioner will run in fan. -
Page 13: Auto Mode
3.8 Auto mode Sequence of the operations Press the ON/OFF button “ ”, switch on the air conditioner, it will run by memory mode. Press the MODE button “ ” set up the mode to auto “ ”, the air conditioner will run in heating auto mode. -
Page 14: Timer On Function
3.10 Timer on function Sequence of the operations The air conditioner is switched off. Press the TIMER ON button “ ”, set up the time the air conditioner should switch on. Press the button “ ” each time, adjusting up 1 hour; Press the button “... -
Page 15: Maintenance
This appliance is not intended for use by persons (including children) with reduced physical, senso- ry or mental capabilities, or lack of experience and knowledge, unless they have been given super- vision or instruction concerning use of the appliance by a person responsible for their safety. -
Page 16: Guarantee Conditions
3.15 GUARANTEE CONDITIONS The air conditioner is supplied with a 24-month guarantee, commencing on the date of pur- chase. All material and manufacturing defects will be repaired or replaced free of charge within this period. The following rules apply: 1. We expressly refuse all further damage claims, including claims for collateral damage. 2. - Page 17 +39 571 628 504 fax: +32 3 326 26 39 email: pvgitaly@zibro.com email: pvgbelgium@zibro.com u NORGE q SCHWEIZ Appliance Norge AS PVG Schweiz AG Vogellunden 31 Salinenstrasse 63 1394 NESBRU 4133 PRATTELN tel: +47 667 76 200 tel: +41 61 337 26 51...
