WirelessIP 5000 User Guide
7. Icons on Display
Indicate vibration mode is on.
It gets displayed when ring
mode is set to vibration.
Indicate lamp mode is on.
LED blinks when there is
an incoming call.
Indicate signal strength.
More bars displayed
indicate better isolation
Indicate user is online.
For more description
refer to below.
Status message of idle mode display
Indicates user is online.
Indicates user is busy.
Indicates user is going to be right back.
Indicates user is away for a while.
Indicates user is on the phone.
Indicates user is out to lunch.
Indicates user is offline.
Unidata Communication Systems Inc.
Indicate alarm is on.
It gets displayed when alarm
clock setup is on.
Figure 8. Icons on Display
Page 12
Indicates new message(s).
It gets displayed when there is/are
new messages(s) that has not
been read
Indicate key lock.
While this mode is on,
pressing keys will do nothing
Indicate battery life.
More bars displayed
indicate more energy.
Icons on Display
