- Page 2 PointDraw 3.0 pen USB cable (5 m) USB cable (0.9 m) Adaptor Charging cradle RF dongle...
- Page 3 Pouch Wrist strip Quick start guide License key card...
- Page 4 Table of contents English ........................4 Français ........................16 Deutsch ........................28 Italiano........................40 Español ........................52 Portuguê........................64 Svenska ........................76 Русский........................88 Nederlands......................101 Polski........................113 Türkçe ........................125 Čeština ........................137 ไทย ..........................149 繁體中文 ........................161 简体中文 ........................172 日本語........................183 한국어........................195 ........................207...
- Page 5 PointDraw OSD is activated pen tip Right mouse button/Used as a down key when the PointDraw OSD is activated Connection indicator Solid Blue: Paired with BenQ Activates the selected projector OSD menu item Blinking: Attempt to pair with...
-
Page 6: Battery Charging
English Battery charging The charging time varies by using different equipment. See the table below for details. Equipment Charging time (hour) Duration of pen use (hour) Computer 2~2.5 Power adaptor 1.5~2 Cradle (single pen) 1.5~2 Cradle (dual pen) 2.5~3 Do not disassemble the PointDraw pen yourself. Refer all servicing to qualified service personnel. The lithium battery is only rechargeable, and not user replaceable. - Page 7 English Operation...
- Page 8 "Dual Pen" or "Single Pen". Presentation Timer Language Projector Installation Front Table Menu Settings Operation Settings Remote Receiver Front+Top Panel Key Lock BenQ Background Color Splash Screen BenQ PointDraw Single Pen Analog RGB MENU Exit Single Pen For optimized interactive speed, it is recommended to select a single pen in PointDraw settings.
- Page 9 3 software and enter dual pen mode. Operation Settings Remote Receiver Front+Top When switching between PointDraw Panel Key Lock modes, it will take about 30 seconds to re- BenQ Background Color flash modes, the delay time depends on Splash Screen BenQ computer response time. PointDraw...
- Page 10 English How to hold the PointDraw 3.0 pen If the PointDraw pen is far away from the screen, be sure to press the left mouse button to click and drag. Avoid shadows! The PointDraw pen won't work if its tip is in a shadow or if it is pointing at a shadow: Correct (no shadow) Incorrect (shadow)
- Page 11 English $12,000 $12,000 $10,000 “Second Wave” $10,000 “Second Wave” Trough of commoditization Trough of commoditization $8,000 $8,000 and recession and recession $6,000 $6,000 “First Wave” “First Wave” $4,000 $4,000 $2,000 $2,000 1994 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004 2005...
-
Page 12: Troubleshooting
English Troubleshooting Check the battery status - if the battery is blinking red, please connect the pen to the charging cradle, or to the power adaptor via a USB cable to charge. Avoid direct strong CCFL light onto the projected image in a short When the pen does distance. -
Page 13: Specifications
SmartEco lamp mode and 3D mode are not active while PointDraw Others setting is On. This will ensure the best PointDraw interactive performance possible. Specifications Pen (PD03) Operation frequency 2.4 GHz ISM Band Rechargeable battery 1 pcs Model name UR14500P 3.7V... - Page 14 English Power adaptor AC input 100~240V AC, 50~60 Hz, 0.3 A max. DC input 5V DC, 2 A Charging cradle Power on/off 5V USB power on/off switch RF dongle Parameter Performance Remarks Working voltage Over low voltage will possibly cause communication error.
- Page 15 English Low battery (20% power) Flash 3 times (0.5 sec LED on, 0.5 Solid on sec LED off for 3 times) between 5- second interval (LED off). Low battery (10% power) Flash 3 times (0.5 sec LED on, 0.5 sec LED off for 3 times) between 5- second interval (LED off) Charging (power off and standby) Solid on...
- Page 16 English 1.3 RF dongle LED LED Behavior Status Blinks blue every 1.5 seconds Wireless channel search Dongle is synchronizing with interactive device(s) Blinks blue every 3 seconds Wireless channel selected to use for synchronization with interactive device(s) Blinks blue every 6 seconds Dongle successfully synchronized with interactive device(s) Blinks blue every 10 seconds...
