Ailebebe swing moon Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
•
If this child seat is not installed correctly or is not used properly, its performance may be compromised. You must
check before installation whether or not your vehicle can properly accommodate a "Universal" assistant restrain-
ing device for a child, by referring to the owner's manual for the vehicle.
•
For safe usage, please read these operating instructions carefully to understand their contents. If they are not
clear, contact our company (see the back cover) or CARMATE dealer.
This child seat is approved in accordance with European Safety standard ECE R44/04 under following
conditions; (Group: I, II, Universal category)
•
Usable only for a child whose weight is from 9 to 25 kg.
•
A passenger seat that is confi rmed to be able to properly accommodate a "Universal" assistant restraining
device for a child by the owner's manual for the vehicle.
Refer to the operating instructions for details.
Keep the protective plastic of the child seat out of the reach of small children after opening the package.
Warning
If a child gets wrapped up in it, it may cause suffocation.
EN
Operating Instructions
2070722B
For Safe
Usage
Packing
Contents
and Parts
Identifications
Before Use
Usage in
Child Style
Usage in
Junior Style
Maintenance
MEMO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the swing moon and is the answer not in the manual?

Questions and answers

Related Manuals for Ailebebe swing moon

Summary of Contents for Ailebebe swing moon

  • Page 1 2070722B For Safe Usage Packing Contents and Parts Identifications Before Use Operating Instructions • If this child seat is not installed correctly or is not used properly, its performance may be compromised. You must Usage in check before installation whether or not your vehicle can properly accommodate a “Universal” assistant restrain- Child Style ing device for a child, by referring to the owner’s manual for the vehicle.
  • Page 2 Introduction Thank you for purchasing AILEBEBE SWING MOON. Fold and store the For safe usage, please read these operating instructions carefully to understand their contents. We shall Operating Instructions under the base. not be held responsible for any trouble caused by incorrect installation or usage.
  • Page 3 Removing the body cover ..........40-41 How to adjust the headrest ........... 16 Reattaching the cover ............42-43 How to use the hold cushions (SWING MOON 4. Usage in Child Style ........... 17-32 premium only) ..............44 Preparations before use ..........17-22 Cleaning................

  • Page 4: For Safe Usage

    1. For Safe Usage Regarding the Safety Descriptions The important descriptions are symbolized as follows in these operating instructions: Risk of death or serious injury if not observed Warning Caution Possible exposure to risk of injury or physical damage Info Prudent usage Requirements Give priority to weight if height and age do not meet their requirements.

  • Page 5: Usable Seatbelt To Install The Child Seat

    1. For Safe Usage Usable seatbelt to install the child seat This child seat can be used only with a 3-point system seatbelt that is approved in accordance with European Safety Standard ECE Regulation No. 16 or other standard of equal level. 3-point seatbelt 2-point seatbelt How to check the comformable types of vehicle...
  • Page 6 1. For Safe Usage Type of Seatbelt Note: Refer also to the manual for your vehicle for the type and use of the seatbelt. Type of seatbelt Features of the seatbelt Cautions during use Availability E LR The seatbelt is automatically retracted Upon installation, draw the seatbelt out and locked by rapid pull in a sudden slowly.

  • Page 7: Seatbelt/Seat Not Proper For Installation

    If it is possible with sports-type seatbelt to inactivate the airbag, do so in accordance with Except for cases in which AILEBEBE con- the instructions in the owner’s manual for the formance information gives approval.
  • Page 8 1. For Safe Usage Storage/not in use Warning As the following are very important with regard to installation/usage, read them carefully. Even while the child seat is not in use, it When you carry the child seat, do not must be fi xed to a passenger seat with its touch the reclining lever or the belt guide.
  • Page 9 1. For Safe Usage Before use Warning As the following are very important with regard to installation/usage, read them carefully. Caution Do not use the child seat with its cover or cushion removed. Do not attach a cover Before use in the child style, be sure to check that the shoul- or cushion that is not specifi...
  • Page 10 1. For Safe Usage During use Warning As these are very important with regard to installation/usage, read them carefully. Do not slide or recline the passenger seat The child seat must not be adjusted on which the child seat is installed. Its or handled during driving.

  • Page 11: For Safe Usage

    1. For Safe Usage During use Securing your workspace Caution Install the child seat in a vehicle in an open and level place so that the child seat can During installation or use, be careful not be carried easily and the doors can be to pinch the child seat or seatbelt with a opened fully.

  • Page 12: Packing Contents And Parts Identifications

    First check the packing contents. If any part is missing, contact one of the service centers listed on the back cover. Packing contents Holding cushions Operating Instructions Body • The holding cushions are supplied only with SWING MOON premium. Nonslip pads Head hold Lumber hold Strings for fixing A hook is attached on the rear side. Shoulder harness...
  • Page 13 2. Packing Contents and Parts Identifications Front Side Belt guide (left/right) Headrest Shoulder belt guide (masked by the cover initially) Shoulder harness passage (3 steps) Belt guide button Tongue holder (left/right) Body Arm rest Belt stopper (left/right) Adjuster cover Reclining lever (on the rear) Side lever Base...

  • Page 14: Packing Contents And Parts Identifications

    2. Packing Contents and Parts Identifications Rear Identifications of the seatbelt on the vehicle Shoulder harness passage (Use the PRESS passages from top to the button Back rest 3rd height.) Headrest * The lowest ones are not for use. Tongue Shoulder seatbelt Buckle...

  • Page 15: Before Use

    3. Before Use How to recline The child seat can be reclined in Child/Junior style 3 steps. [Weight of more than 9 kg, forward facing] 1st step 2nd step 3rd step While supporting the child seat with one hand, hold up the reclining lever and recline the child seat back and forth with both hands. Reclining lever Info The child seat may be pressed to the passenger seat because of the reclining step.

  • Page 16: Before Use

    3. Before Use 3. Before Use How to adjust the headrest Hold the headrest with both hands and move it up and down. Headrest Body Caution Take care not to pinch your fingers between the headrest and the body.

  • Page 17: Usage In Child Style

    4. Usage in Child Style Preparations before use Selecting the suitable shoulder harness passage Info The shoulder harnesses are set in the 3rd weight position of the passages initially. Change the height of the shoulder harness as your child grows. Before installation, pass the shoulder harnesses through the passages in the suitable height for your child.

  • Page 18: How To Change The Height Of The Shoulder Harnesses

    4. Usage in Child Style Preparations before use How to change the height of the shoulder harnesses First, set the child seat to the 1st step of reclining so Release the shoulder harnesses from the shoulder that the rear of the body can be seen. harness hanger.
  • Page 19 4. Usage in Child Style Pass the nonslip pads to their middle into the Insert the ends of the nonslip pads from the rear shoulder harness passages from the front. with, facing their nonslip sides facing the child’s body, into the suitable shoulder harness passages then draw them out from the front.

  • Page 20: How To Change The Height Of The Shoulder Harnesses

    4. Usage in Child Style Preparations before use How to change the height of the shoulder harnesses Pass the shoulder harnesses through the nonslip pads then through the harness passages into which the nonslip pads go. (For selecting the suitable shoulder harness passage, see page 17.) Shoulder harness Nonslip pads passages...
  • Page 21 4. Usage in Child Style Fit the shoulder harnesses on the shoulder harness hanger then store them inside the base. See the illustrations as for the positions of shoulder harness passages and shoulder harnesses. Child style (for a child more than 9 kg weight) Shoulder harness hanger Shoulder harness hanger Warning...
  • Page 22 4. Usage in Child Style Preparations before use When the shoulder harness hanger is put in the body (with the shoulder harnesses detached) Insert your hand into the body from the rear to draw While holding the adjustment lever up, push the out the shoulder harness hanger.

  • Page 23: Installation In The Vehicle

    4. Usage in Child Style Installation in the vehicle STEP 1 Preparations before installation Set the child seat to the 1st step of reclining. Place the child seat on the passenger seat facing forward then press it so that its base is pressed (For how to recline, see page 15.) against the backrest and the seat of the passenger seat firmly.

  • Page 24: Installation In The Vehicle

    4. Usage in Child Style Installation in the vehicle STEP 2 How to fix the seatbelt Turn over the adjuster cover and draw out the Pass the seatbelts fit together through the seatbelt harness adjuster until the shoulder harnesses are passage until they come out from the opposite side then insert the tongues into the buckle until it clicks.
  • Page 25 4. Usage in Child Style Pull the shoulder seatbelt strongly in the direction of Hang the waist seatbelt, which is on the opposite the arrow while holding the child seat with your hand, side of the buckle, on the belt hook. as shown in the illustration.

  • Page 26: Step 3 How To Tighten The Seatbelt

    4. Usage in Child Style Installation in the vehicle STEP 3 How to tighten the seatbelt Put your weight with one knee on the child seat and Open the belt stopper. While fastening the shoulder seatbelt with the belt stopper, lock them firmly with pull up the shoulder seatbelt to tighten the waist the side lever.
  • Page 27 4. Usage in Child Style See the following illustrations 1 to 3. While pressing the belt guide button, turn the ring segment downward, pass the shoulder seatbelt through the belt guide then turn the ring segment upward to lock. Closeup of the belt guide Belt guide Warning •...

  • Page 28: Verification After Installation

    4. Usage in Child Style Verification after installation Completion from the buckle side Completion of opposite side It is not necessary to use the belt The shoulder seatbelt is passed guide. through the belt guide securely. The seatbelt of the vehicle is not The shoulder seatbelt is fastened loosened or twisted.

  • Page 29: Notes On Removing The Child Seat From A Vehicle

    4. Usage in Child Style Notes on removing the child seat from a vehicle If the buckle of the passenger seat cannot be released because it goes inside the belt passage, try either of the following: Release the belt stopper of the child seat and draw out the buckle of the passenger seat. Then release the buckle. Use a ruler or equivalent to release the buckle of the passenger seat.

  • Page 30: Placing Your Child In The Child Seat

    4. Usage in Child Style Placing your child in the child seat While holding up the adjustment lever, draw out the Push down the red button of the buckle to release the tongue. shoulder harness. Tongue Nonslip pads Tongue Adjuster cover holder Red button Buckle...
  • Page 31 4. Usage in Child Style Place your child in the correct position. Have him/her sit in deeply. Pass the child’s arms under the shoulder harness, and put the left and right tongues together and insert them into the buckle. Check that the indicator lights in green. Put the left and right tongues together and Shoulder harness...

  • Page 32: Usage In Child Style

    4. Usage in Child Style Placing your child in the child seat Pull the nonslip pads downward strongly and Nonslip pad draw the harness adjuster to tighten the shoulder harness until one or two fingers of an adult can Pull the nonslip be inserted between the shoulder harness and the pads strongly.

  • Page 33: Usage In Junior Style

    Release the 4 hooks of the seat part of the body cover and turn up If your child seat is the SWING MOON premium, remove the holding the cover. Release the 2 hooks (left and right) at the end of each of cushions.
  • Page 34 5. Usage in Junior Style Preparation before use Storing the harnesses/Preparation of the shoulder belt guide Turn up the seat cushion (lower) and bind the Fix the 2 hooks (left and right) at the end of each tongues with the harness and put them in the hole black elastic strings inside the cover.
  • Page 35 5. Usage in Junior Style Place the shoulder harness hanger in the groove In Junior style, insert the belt guide cover inside the on the rear temporarily and set the child seat to the shoulder belt guide so that the shoulder belt guide is 3rd step of reclining.

  • Page 36: Installation In The Vehicle

    5. Usage in Junior Style Installation in the vehicle Place the child seat on the passenger seat facing forward and press it so that its base is pressed against the backrest of the passenger seat. Backrest The base must be pressed onto the seat firmly.

  • Page 37: Riding Your Child On The Child Seat

    5. Usage in Junior Style Riding your child on the child seat Press the buckle button of the vehicle to release the Pass the shoulder seatbelt through the shoulder belt seatbelt. guide. Adjust the headrest so that the shoulder seatbelt passes just Have your child sit in the child seat deeply.

  • Page 38: Usage In Junior Style

    5. Usage in Junior Style *Be sure to check all points referring to the illustration. Verification after installation Completion from the buckle side Completion of the opposite side The shoulder seatbelt is The head of the child passed through the belt does not come out from guide correctly.

  • Page 39: Maintenance

    6. Maintenance Removing the holding cushions (SWING MOON Premium only) Head hold Lumber hold Move the headrest upward. Pull the lumber hold to remove the hooked cloth from the waist harness passage. Then release the 2 (See “How to adjust the headrest” on page 16.) hooks (left and right).

  • Page 40: Removing The Body Cover

    6. Maintenance Removing the body cover • Set the child seat to the 1st step of reclining. • Release the tongues from the buckle before removing the body cover. Info The shoulder harness must be taken off before removing the body cover and shoulder harness cover. Crotch harness cover Nonslip pads See pages 18 and 19 for details.
  • Page 41 6. Maintenance Body cover Move up the headrest and release the Release the 8 outer hooks and 2 inner hooks. 2 hooks and 2 fastener tapes of the headrest. Outer hooks Rear of the body cover Fastener tapes Turned-up cover Black elastic string Hook hole...

  • Page 42: Reattaching The Cover

    6. Maintenance Reattaching the cover Body cover Pass the shoulder harnesses and tongues through Pass the buckle through the body cover and fix the 8 the body cover. (child style only) outer hooks (only for the child style). Shoulder harness Tongue Buckle Body cover...
  • Page 43 6. Maintenance Nonslip pads (child style only) Pass the nonslip pads through the harnesses so not to be After all covering is finished, pass the shoulder harnesses through the suitable passages and hang twisted. them on the shoulder harness hangers. Nonslip pad Pass the nonslip pads through the harnesses when the child seat is used...

  • Page 44: How To Use The Hold Cushions (Swing Moon Premium Only)

    6. Maintenance How to use the hold cushions (SWING MOON Premium only) Head hold Lumber hold Pass the lumber hold behind Draw up the headrest. the shoulder harnesses. (For height adjustment of the (Face the side without a hook headrest, see page 16.) Draw up.

  • Page 45: Maintenance

    6. Maintenance Warning Cleaning Do not use a solvent like a thinner to clean the body or harnesses. Notes on cleaning Wash the product by band using water under 30 ◦ C. Safekeeping for the child seat Chlorine bleach must not be used. •...

  • Page 46: Memo

    MEMO...

  • Page 47: Memo

    MEMO...

  • Page 48: Where To Contact

    Where to contact CAR MATE MFG. CO., LTD. 5-33-11,Nagasaki, Toshima-ku, Tokyo 171-0051 Japan E-mail: int@carmate.co.jp Tel: +81-3-5926-1226...
