SARATTO INSTRUCTION
Acceptable weight and height
Acceptable weight: 9 kgs through 18 kgs
Acceptable height: 75 cm through 100 cm
Age for reference: 1 through 4 year-old
Note:
Acceptable weight: 15 kgs through 25 kgs
Acceptable height: 100 cm through 120 cm
Age for reference: 3 through 7 year-old
Acceptable weight: 15 kgs through 36 kgs
Acceptable height: 100 cm through 145 cm
Age for reference: 3 through 11 year-old
Verify that following components are involved.
Booster Seat
Part names
Belt conduit
Belt-guide
Part names of a car
Backrest
Buckle
Seat
Install Impact Shield without failure
Impact Shield
Backrest
Shoulder belt conduit
Waist belt conduit
Shoulder seat belt
Waist seat best
Headrest
Keep the manual in the
pocket on the back
Pocket
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ailebebe SARATTO
Summary of Contents for Ailebebe SARATTO
- Page 1 SARATTO INSTRUCTION Acceptable weight and height Acceptable weight: 9 kgs through 18 kgs Acceptable height: 75 cm through 100 cm Age for reference: 1 through 4 year-old Note: Install Impact Shield without failure Acceptable weight: 15 kgs through 25 kgs...
- Page 2 How to assemble 1. Joint booster seat and backrest together as shown in Fig. 2. Lift a backrest to upright position as shown in Fig. 3. Insert headrest into guide holes on backrest and depress it until it clicks. 4. Put a flap of seating surface into backrest as shown in Fig. Flap How to detach 1.
- Page 3 How to use child safety seat with impact shield Place child safety seat on a car’s seat facing forward. Backrest of the product should contact car’s backrest as close as possible. Sit a child on a safety seat with its spine pressed against backrest. Install Impact Shield as it contacts with chest of child, and fix it by flaps right and left Impact Shield Flap...
- Page 4 How to use child safety seat without impact shield Place child safety seat on a car’s seat facing forward. Backrest of the product should contact car’s backrest as close as possible. Sit a child on a safety seat deep in a seat. Buckle up safety seat belt for sure. Pass waist seat belt and shoulder seat belt throught conduit as shown in Fig.
- Page 5 How to use booster seat 1. Place booster seat deep in on a car's seat. Sit a child deep in booster seat. Pass waist seat belt through conduit and buckle up for sure. Verify that safety best comes on groin so that child is restrained at pelvis. Pass shoulder seat belt through conduit.
- Page 6 Unhook and unscrew applied and remove cover. Unhook Unhook Unscrew Unhook 5. Unhook hooks inside conduit and remove cover. Conduit Unhook...
