IP CAMERA
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RYK-IP2280 and is the answer not in the manual?

Questions and answers

Related Manuals for Yoko Technology RYK-IP2280

Summary of Contents for Yoko Technology RYK-IP2280

  • Page 1 IP CAMERA User Manual...
  • Page 2 CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN! CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN COVERS (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. It is advised to read the Safety Precaution Guide through carefully before operating the product, prevent any possible danger.
  • Page 3 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 4 CONTENTS 1. INTRODUCTION..................1 1.1 Product Introduction................1 1.2 Application .................... 1 2. FEATURES ....................2 3. PACKING LIST.................... 3 4. INSTALLATION ................... 4 4.1 Software Installation ................4 4.2 System Configuration ................7 4.3 Suggested Computer Equipment............7 5. Location and Control..................8 5.1 Front Panel ...................

  • Page 5: Introduction

    1. INTRODUCTION 1.1 Product Introduction The Day & Night (optional) IP Camera is a high performance camera, with simple connection- no PC required. It can be viewed and controlled from the PC site using the IE browser or apply the free bundled 16-CH viewing software, to enable real-time remote site control and supports 3GPP for mobile surveillance.

  • Page 6: Features

    2. FEATURES Compact size Pan/Tilt IP camera, support Preset/Auto-pan functions. CMOS camera with VGA Resolution. Flip and mirror the videos and overlay time, date or text. Built-in MPEG4/ MJPEG compression format and VGA/ QVGA video resolution. Built-in 3GPP video compression format and QQVGA video resolution. Adjustable image quality, resolution and frame rate settings.

  • Page 7: Packing List

    3. PACKING LIST Check to make sure all of the items shown below are included in your product package. If something is missing, contact your dealer as soon as possible. Item Item Description Item Picture Qty. IP camera (Option Function: Wireless and IR LED) Camera Stand Power Adaptor...

  • Page 8: Installation

    4. INSTALLATION 4.1 Software Installation Please use the enclosed CD-ROM to precede the IP CAM Viewer software and follow the procedures to setup the software’s below: Local LAN IP camera search Software (Discoverer). IE Browser ActiveX Compression Software (New ActiveX software updates may be directly downloaded by the IP camera).
  • Page 9 Select Start Menu Folder. The default folder is IP CAM Viewer. Select if you want to create a desktop icon or not.
  • Page 10 Click “Install” button to start installation process. Installation completed.

  • Page 11: System Configuration

    4.2 System Configuration Connect the IP Camera online, transfer video image through LAN/ WAN to the PC terminal, and monitor from the IE browser, 16CH viewing software, or 3G Mobile phone. INTERNET 4.3 Suggested Computer Equipment 3.0 GHz (or above) 512 MB (or above) Sound Card For audio requirement...

  • Page 12: Location And Control

    5. Location and Control 5.1 Front Panel 1 Photo Sensor 2 Microphone 3 IR LED 4 ACT/LINK Indicator 5 LAN Speed Indicator (Flashing 6 Power Indicator (Red) green. LED unlit indicates activity on a 10Mbps Ethernet network, indicates activity 100Mbps Ethernet network). NOTE: The Wireless and IR LED functions are optional items.

  • Page 13: Rear Panel

    5.2 Rear Panel DC IN RJ45 network terminal Audio output terminal Microphone terminal SD card slot (Supports hot-swap function) DI/DO Input/Output terminal Wireless network antenna (Option) Reset button NOTE 1: To properly insert the SD card the brass fingers on the card should be facing down and towards the rear of the IP camera.

  • Page 14: Ip Camera Setup

    6. IP CAMERA SETUP Before using the IP Camera, you need to first change the default IP Address and setup the environment for future application. If you do not know the IP address of the IP Camera; first connect the PC to the IP Camera and search for it using the Discover software, change the IP address and finish the setup.

  • Page 15: On The Lan Using Discoverer

    6.2 On the LAN using Discoverer Please assign an IP address to the IP Camera; either by using a fixed IP or DHCP assigned IP address. Then enter the relevant IP Address, Subnet Mask and Gateway value (Default: IP 192.168.100.100 and Subnet Mask 255.255.0.0).
  • Page 16 On the LAN using Configure In the field “Host Name (Camera Title)” enter applicable alphanumeric characters, otherwise a dialog window pops up (Invalid Character). 1. To modify network setup, press Configure button and a dialog window pops up (Configure Network Device). After new network setup, enter admin password (Default Password: admin).

  • Page 17: Ie Connection

    6.3 IE Connection Open up the IE browser and enter the IP address of the IP Camera or double click the IP Camera icon in the Discoverer software. When a dialog box appears, enter the username and password (Default User Name: admin and Default Password: admin).
  • Page 18 Then a window will appear asking you to confirm whether or not you want to install the ActiveX control. Select “Install” and the installation will take care of itself. If you are unable to install ActiveX Control, please try again following the procedures below: On the IE browser Menu item bar, select [Tools] [Internet Options] item.
  • Page 19 3. After clicking on [Custom Level …] button, a security settings window appears. Please follow the steps below to change items to “Enable” or “Prompt”. Download unsigned ActiveX controls: [Prompt] Download signed ActiveX controls: [Prompt] Automatic prompting for ActiveX controls: [Enable] Initialize and script ActiveX controls not marked as safe: [Enable] Run ActiveX control and plug-ins: [Prompt] Script ActiveX controls marked safe for scripting: [Enable]...
  • Page 20 5. After clicking on [Customer Level…] button, a security settings window appears. Please follow the steps below to change items to “Enable” or “Prompt”. Download unsigned ActiveX controls: [Prompt] Initialize and script ActiveX controls not marked as safe: [Prompt] Download ActiveX Control...
  • Page 21 After Active Control has been successfully setup, live images will be displayed on the IE browser. Connect to IP Camera through IE browser NOTE: Up to a maximum of 5 users can access one IP Camera at the time. The 6th user may only implement function setup, but unable to view the display.

  • Page 22: Function Setup

    7. FUNCTION SETUP 7.1 Home Page Optimum Resolution: 1024*768 Image Control Buttons 1. Show original Image Size 2. Zoom In (Magnification - close up view) 3. Zoom Out（Range: Original Size - 300%） 4. Microphone On/Off (Only admin-level has the authority to switch the PC microphone On/ Off and Enable/ Disable 2-way audio (listen and also talk to the camera site) function.
  • Page 23 Function Control Buttons Direction Buttons (Up/Down/Left/Right): For camera position adjustment. Home: Return to the camera default position. Go to: Go to the selected Preset Point. PAN Step：Horizontal Movement 01(Short)/02/03/04/05/06(Medium)/07/08/09/10/11(Long) ………………... 3 Tilt Step：Vertical Movement 01(Short)/02/03/04/05/06(Medium)/07/08/09/10/11(Long) ………… 4 Enable the Auto Pan Function ……………...
  • Page 24 Click the last item “Display Title Bar”. The title bar will be displayed across the top of the screen display, as shown below: Display Frames per Second Camera Name IP Address Percentage Bite Rate Image Resolution Motion Detection Inactivated Motion Detection Activated Stop Recording Recording Camera Unconnected...

  • Page 25: Date/ Time Settings

    7.2 Date/ Time Settings 1 Time Zone：Select the local time zone. 2 Setup Date / Time via Network Time Protocol (NTP)：Synchronize date/ time with the time server. NTP Server：Enter the IP address or domain name of the time-server. 3 Manual Setup Date / Time： Date：Select Date.

  • Page 26: Name Settings

    7.3 Name Settings 1. Host Name：Enter IP CAM host name. Tip ： Applicable alphanumeric characters ： Underline (_), hyphen (-), numbers (0 - 9) and alphabet (a - z, A - Z). 2. Domain Name：Enter domain name (optional field, administrator login only） 。 3.

  • Page 27: Ip Settings

    7.4 IP Settings IP Settings： (1) Setup Dynamic IP (DHCP)：Assign an IP address via DHCP server. Enable DHCP to allow centralized assignation of IP addresses. (2) Setup Static IP：Setup fixed IP address manually. IP Address：Enter fixed IP address. Subnet Mask：Enter subnet mask. Gateway：Enter network gateway.

  • Page 28: Wireless Network Settings

    7.5 Wireless Network Settings Communication Mode：Setup communication mode (Infrastructure or Ad-Hoc, normally apply Infrastructure). Wireless Network Name (SSID)：Setup wireless network name. Wi-Fi Channel number：Setup channel (Auto, 1~11) Wireless Mode：Select wireless mode (11B/11G mixed mode, 11G only, or 11B only. Wireless Encryption：Select wireless encryption mode (Disable/ WEP). (1) Disabled (Open system)：Disable wireless encryption mode.
  • Page 29 (3) WPA-PSK WPA Encryption：Select TKIP or AES. Pre-shared Key Type：Select shared key type [Passphrase (8-63 characters) or Hex (64 digits)]. Pre-shared Key：Enter password. Click [Apply] button to complete the setup. Note: When “Setup Dynamic IP (DHCP)” is set under IP Settings page and “Ad-Hoc”...

  • Page 30: Video Settings

    7.6 Video Settings 1 Video Property Settings：Setup video property. Brightness, Contrast, Saturation, Hue adjustment (Setup Range: 0 - 255) Flip：Flip image (up/ down, Setup Range: 0 - 255). Mirror：Mirror image (left/ right, Setup Range: 0 - 255). OSD Timer：Display OSD timer (Setup Range: 0 - 255). Flip：Flips an image upside.
  • Page 31 2 Video Stream Mpeg4 (Mpeg4 stream settings) (1) Streaming Property Setting： Frame Rate：Select fps [5, 10, 15, 20, 25FPS]. Resolution：Select resolution [QVGA (320 x 240) or VGA (640 x 480)]. NOTE：Two types of video stream: MPEG-4 and MJPEG (total of 30 FPS). MPEG-4 (default) provides 25FPS, while MJPEG provides only 5FPS.
  • Page 32 4 Video Stream 3GPP (1) Streaming Property Setting： Frame Rate：Select 5fps. Resolution：Select resolution [QQVGA (160x120)]. (2) Streaming Bit Rate Control：Select streaming bit rate. Constant Bit Rate：Bit Rate value is fixed, 16K bps – 64K bps Constant Quality ： Depend on quality [OK, Medium, Standard, Good, or Great].

  • Page 33: Motion Detection Windows

    7.7 Motion Detection Windows Motion Detection Window Settings：Use the mouse to click, hold and drag the window frame, remember to click [Apply] in order to validate the change. 1 Motion Detection Window Settings ： Setup motion detection area parameters. Window 1, 2, 3：[Enable/ Disable] motion detection setup for window 1-3. Sensitivity 1, 2, 3：[Very High, High, Normal, Low, or Very Low] sensitivity rate setup for window 1-3.

  • Page 34: Alarm Settings

    7.8 Alarm Settings Enable DI Alarm：You can select following two DI Alarm types DI Normal Close(N.C.)：The sensor is close in normal time. DI Normal Open(N.O.)：The sensor is open in normal time. Enable Motion Alarm：Issue alarm when motion detected. Enable DO Control： DO Normal Open(N.O.)：The sensor is open in normal time.
  • Page 35 Note: Select either one of the function [Save the motion snapshot to a JPG file] or [Save motions to an AVI file on the SD Card], but not both. Alarm OFF/ Alarm On/ Alarm Schedule When you select the Alarm Schedule, the above alarm settings will be triggered only within the scheduled timeline.

  • Page 36: Ir Led Control

    7.9 IR LED Control IR LED Control IR LED OFF： Disable IR function. IR LED ON：Enable IR function. Schedule ON：Enable IR LED Schedule IR LED AUTO：Enable or Disable IR LED by IP Camera automatically. Daily Schedule Select IR LED ON from time 0:00 to 24:00. One grid indicates half an hour.

  • Page 37: Sd Card File Management

    7.10 SD Card File Management SD Card status: Indicates SD card current storage status. File list：Insert the SD card to the IP camera to display file list stored in the SD card. Back：Click to return to previous folder. Select All：Select all files in the file list. Delete Select：Delete selected file in the file list.
  • Page 38 Format SD Card：Click [FORMAT] button to format SD card. All recorded data in the SD card will be deleted. After format, two files “AlarmPicture and AlarmVideo” will be created and motion-event data will be stored in these two files. When motion recording is activated it will be stored instantly onto the SD card.

  • Page 39: Smtp Settings

    7.11 SMTP Settings SMTP Server：Setup simple mail transfer protocol to transfer mail reliably and efficiently（similar to mail function setup）. Recipient：Enter recipient’s e-mail address. The SMTP Server need authorization：The user needs to give valid user name and password to send email via the server. Username：Enter the user name of the e-mail address.

  • Page 40: Ftp Settings

    7.12 FTP Settings 1 FTP Server：Enter FTP address, to enable file transfer via FTP when a Motion/ DI event occurs. 2 FTP Port：Enter FTP Port（normally apply 21）. 3 Username：Enter active user name of FTP server. 4 Password：Enter FTP user password. 5 Remote Folder：Create a remote folder;...

  • Page 41: Account Settings

    7.13 Account Settings Current User: Displays the current user. 1 Change Password New Password: Enter new password. Confirm: Enter the new password again to reconfirm. Click [Change] to validate the setup. 2 Add New Account (Maximum 32 user accounts) Account: Enter user account. Password: Enter user password.

  • Page 42: Pt Control

    7.14 PT Control Pan/Tile Config： Up/Down/Left/Right：For IP Camera position adjustment. You can see the images in the preview window. Home：Relocate the IP camera to the original position. Patrol：Enable the Patrol function. IP camera will follow the preset points in the Patrol List to do the multi points patrol. Stop：Stop the Patrol function.
  • Page 43 Preset List：User can set the desired camera position and save it as Preset point in the Preset List. It is a preset user-defined camera position; user can move the camera position very quickly when needed. 100 preset points are allowed in the Preset List. Use the Up/Down/Left/Right buttons to adjust the camera position, and then input the preset point name in the right column of Preset List.

  • Page 44: System Settings

    7.15 System Settings Image Path：The saving path of the image snapshots (*.JPG/*.AVI). The default path is C:\IPCam\. Main Video Stream：Default is Mpeg-4 (this function is read only). Second Video Stream：You can select 3GPP (Output to 3G mobile phone) or Mjpeg format. NOTE：The Profile is stored in PC and not in IP CAM.

  • Page 45: Restore Factory Default

    7.16 Restore Factory Default NOTE：The system can only restore factory default settings of the parameter profiles within the IP CAM, but invalid to parameter profiles store on PC. Click [Restore] to restore the factory default settings. Any changes made so far will be lost and the system auto connects to the default IP address (Http://192.168.100.100).

  • Page 46: Firmware Update

    7.18 Firmware Update To install firmware updates for your IP camera. Click [Browsing] and select the firmware file named “IPCAM Firmware (bin file)”, and then click [Upgrade]. The whole process needs a few minutes, so please don’t turn off the power or press the reset button during a firmware update.
  • Page 47 In the [Internet Options] window click the [Connections] tab. Next, click the [LAN Settings...] button. In the "Proxy Server" area, remove the check mark next to “Use a proxy server for ..”, and then click [OK] button. When firmware update failure occurs, first store the firmware file (bin file) to the SD card and then reboot the device to enable auto update.

  • Page 48: G Mobile Phone Monitoring

    9. 3G MOBILE PHONE MONITORING 1. Please follow the setup on 8.6 Video Settings and select item “Enable 3G Streaming”. 2. Enable 3G Mobile Phone Streaming Media program.
  • Page 49 3. Connect to the IP address of the IP camera, using URL format“rtsp://[IP address]/3gv2” (remember to add 3gv2 at the end of the IP address), as shown below: 4. When online connection is successful, image will be displayed on the mobile phone screen display.

  • Page 50: Specification

    10. SPECIFICATION Image MPEG-4/MJPEG Compression Resolution Up to 30 fps at 640x480(VGA) Image Support both CBR & VBR Video Bitrate Adjustable quality frame rate and bit-rate (Compression Time Stamp and text caption Type) Flip& Mirror Two-Way Build in standard 3.5mm MIC and Audio Speaker (Audio-In/Out) connector Omni-directional...
  • Page 51 Operating 85% RH Humidity Input Voltage 12V DC /1A 3 detection window sensitivity adjustable Motion Detection Recording Size/Snapshot No. adjustable after Triggered Pre Alarm , Post Alarm Storage SD CARD Support Windows XP, Vista32 Viewing system Browser: Intenet Explorer 6.0 or above requirement Cellphone: 2.5G/3GPP player Free 16Ch recording/viewing software...

  • Page 52: Appendix

    11. APPENDIX Example 1 ： If you don’t understand DDNS application, you may refer to the mentioned example (DynDNS). Please go to http://www.dyndns.com/ sign up a free account： Enter DynDNS website. On the top right hand corner click “Create Account” to start creating an account. Please remember your account and password, because this account will be your future login account.
  • Page 53 3. Please read Acceptable Use Policy (AUP) and accept it prior to creating your account. Check “I agree to the AUP” and “I will only create one (1) free account”, and make sure the information is correct, then click [Create Account]. Then, you will see the screen “Account Created”, and Dyndns will email the instructions to your specified E-mail address for enabling your account.
  • Page 54 5. Press the link in the mail and you will see “Account Confirmed”. Your account is created successfully now and then login with your account Please return to DynDNS website. On the top right hand corner enter the “User” and “Pass” field that you just created. Then click [Login] to enter.
  • Page 55 After login successfully, click “My Service”. Please click “Dynamic DNS’ icon.
  • Page 56 9. Then click “Get Started” to setup new dynamic domain name. 10. Enter and choose the desired host name (ex: IPCAM) and its IP Address (The IP Address may be the same as your IPCAM IP Address). Click “Create Host” after setup has been completed. Fixed IP users can fill-in Fixed IP and Dynamic IP users can click “Use Auto Detected IP Address”...
  • Page 57 11. Below shows that you have created the host name. You will be connected to the corresponding IP address whenever you enter this host name. 12. When you have completed the above setup, you are no longer restricted by PPPoE application with your existing DDNS equipment (IP Camera).
  • Page 58 When you have setup the IP Camera in the LAN, to connect the router and the hub of the LAN through Intranet you have to setup the NAT Table in the router or bandwidth router so that the device IP Address matches with the Internet IP Address.
