MP165E, applies to F-712.PM1
BRo, 14/11/2017
F-712.PM1 Photometer
400-1550 nm Wavelength Range, to 1 mA Input Current, 20 kHz Signal Bandwidth,
Logarithmic Output ±5 V, Benchtop Device, including Power Supply
Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany
Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws,
www.pi.ws
Advertisement
Table of Contents
Related Manuals for PI F-712.PM1
Summary of Contents for PI F-712.PM1
- Page 1 400-1550 nm Wavelength Range, to 1 mA Input Current, 20 kHz Signal Bandwidth, Logarithmic Output ±5 V, Benchtop Device, including Power Supply Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws,...
- Page 2 Ambient Conditions and Classifications ......................15 Dimensions ................................ 16 Pin Assignment ..............................16 Old Equipment Disposal Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 2 / 17 Phone: +49 721 4846-0, Fax: +49 721 4846-1019, Email info@pi.ws, www.pi.ws...
-
Page 3: About This Document
BRo, 14/11/2017 About this Document Objective and Target Group of this User Manual This user manual contains the required information on the intended use of the F-712.PM1 photometer. Basic knowledge on measuring optical power is assumed. The latest versions of the relevant user manuals for your system are available on our website for download. -
Page 4: Safety
Safety Intended Use The F-712.PM1 photometer is a laboratory device as defined by DIN EN 61010-1. The photometer is designed for indoor use and use in a clean environment within the specified operating temperature range. The photometer is intended for stationary use to measure optical power. The photometer does not protect the user against radiation hazards from the objects being measured. -
Page 5: Organizational Measures
Instruction of the user must include any possible risks. Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 5 / 17 Phone: +49 721 4846-0, Fax: +49 721 4846-1019, Email info@pi.ws,... -
Page 6: Product Description
BRo, 14/11/2017 Product Description Manufacturer Information and Product Labeling Gigahertz-Optik GmbH is the manufacturer of the F-712.PM1 photometer; for contact data, see "Customer Service Department" (p. 12). Figure 1: Product labeling: Type plate (left) and calibration label (right) on the bottom of the... -
Page 7: Features And Applications
BRo, 14/11/2017 Features and Applications The F-712.PM1 photometer can convert an optical signal into a voltage signal in high resolution and with an extremely high bandwidth. The design of the optical input enables measuring of the optical signal independent of the position of the optical fiber in the connector. -
Page 8: Rear Panel
Adapter, BNC/BNC, 1 x connector, 2 x socket, T-branch MP165E User manual for the photometer (this document) Calibration certificate Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 8 / 17 Phone: +49 721 4846-0, Fax: +49 721 4846-1019, Email info@pi.ws, www.pi.ws... -
Page 9: Unpacking
Connect the barrel connector of the adapter to the barrel connector socket of the power supply. Connect the power cord to the power supply. Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 9 / 17 Phone: +49 721 4846-0, Fax: +49 721 4846-1019, Email info@pi.ws,... -
Page 10: Startup And Operation
Switching the photometer on Connect the power cord of the power supply with the power socket. Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 10 / 17 Phone: +49 721 4846-0, Fax: +49 721 4846-1019, Email info@pi.ws,... -
Page 11: Calculating The Radiant Power And The Input Current
If the current input of the photometer is used with a photodiode, refer to the spectral responsivity in the documentation of this photodiode. Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 11 / 17 Phone: +49 721 4846-0, Fax: +49 721 4846-1019, Email info@pi.ws,... -
Page 12: Maintenance
If the problem that occurred with your system is not listed in the table above or cannot be solved as described, contact the customer service department (p. 13). Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 12 / 17 Phone: +49 721 4846-0, Fax: +49 721 4846-1019, Email info@pi.ws,... -
Page 13: Customer Service Department
The latest versions of the user manuals are available on our website (p. 3) for download. Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 13 / 17 Phone: +49 721 4846-0, Fax: +49 721 4846-1019, Email info@pi.ws,... -
Page 14: Technical Data
See "Calculating the Radiant Power and the Input Current" for exact calculation of the radiant power (p. 11). Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 14 / 17 Phone: +49 721 4846-0, Fax: +49 721 4846-1019, Email info@pi.ws,... -
Page 15: Responsivity
Degree of pollution Degree of protection according IP20 to IEC 60529 Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 15 / 17 Phone: +49 721 4846-0, Fax: +49 721 4846-1019, Email info@pi.ws, www.pi.ws... -
Page 16: Dimensions
Wiring with GND switches the photometer off (only relevant when the adapter cable supplied is not used) Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 16 / 17 Phone: +49 721 4846-0, Fax: +49 721 4846-1019, Email info@pi.ws,... -
Page 17: Old Equipment Disposal
In order to fulfil the responsibility as the product manufacturer, Physik Instrumente (PI) GmbH & Co. KG undertakes environmentally correct disposal of all old PI equipment made available on the market after 13 August 2005 without charge. Any old PI equipment can be sent free of charge to the following address: Physik Instrumente (PI) GmbH &...
