Overview
DENVER 360°Camera is a digital panoramic camera with two lenses. Through
the application of up-to-date technologies, it enables you to get panoramic
videos and photos,creating an experience of brand new panoramic world.
Important
Before using this product, please carefully read this Manual
Prepare one 32G (Class 6~Class 10) Micro SD card
Check the camera power. A full charging is recommended before use
(Until the charging indicator goes out)
Search for "Denver 360°action camera" on Apple Store and Google
Playstore, and then download and install it
About Camera
1.
LCD display
2.
Power button/Mode button
3.
WIFI indicator (red)
4.
Power indicator（red）/Charging indicator (blue)
5.
Wifi button/MENU button
6.
Busy indicator (red)
ACV-8305W Quick start guide
ENG 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Denver ACV-8305W
Summary of Contents for Denver ACV-8305W
- Page 1 ACV-8305W Quick start guide Overview DENVER 360°Camera is a digital panoramic camera with two lenses. Through the application of up-to-date technologies, it enables you to get panoramic videos and photos,creating an experience of brand new panoramic world. Important Before using this product, please carefully read this Manual ...
- Page 2 ACV-8305W Quick start guide Shutter button/OK button Lens×2 Triangle nut 10. Interface cover (USB/Micro SD) 11. Speaker 12. Microphone 13. Rope hole 14. Reset hole ENG 2...
- Page 3 ACV-8305W Quick start guide Quick start guide 1. Install SD card: Insert the Micro SD card you prepare into the slot as indicated, as shown on the right. Important: A high-speed Micro SD card between Class 6~Class 10 is a must; or else, this product may not work normally.
- Page 4 ACV-8305W Quick start guide Important: If power-on fails, charge the camera first, and see whether the blue indicator lights up during charging. If yes, it indicates the product is being charged. Power-off: After video stops, press and hold Power button for about 3 seconds and release.
- Page 5 ACV-8305W Quick start guide 3. Charging Use data cable included in the product pack for camera charging. During charging, the indicator displays in blue and lights constantly; when charging completed, the blue indicator goes out. Important: If other charger is used, check the output power before use to ensure it within 5V/0.5A ~ 5V/2.0A.
- Page 6 ACV-8305W Quick start guide ( With maximum 2GB video recording and then stop.Must be started manually on the camera again.) Stop video : During video , press Shutter button to stop it. The video will automatically be saved on your camera storage card. At that moment, the display screen will show remaining time available for video as below: photo : In photo mode, press photo button to take photos.
- Page 7 ACV-8305W Quick start guide setting (as shown below): Menu operation: In Menu mode, press WIFI button to move cursor. Press Shutter button to confirm. Press and hold WIFI button to back to previous menu or exit Menu mode. Explanation of menu functions: Power Save: Set Power-save mode.
- Page 8 ACV-8305W Quick start guide Important: After formatting, all existing data on the storage card will be lost due to such formatting. Please be cautious to this operation! 6. How to use accessories properly It is strongly recommended to use the accessories originally provided by the manufacturer.
- Page 9 Follow these steps to play panoramic videos or pictures on mobile phone or tablet. Download APP: Search for “Denver 360°action camera” on App Store or Google Playstore to download and install the product APP. Connect mobile phone and camera: Connect mobile phone and camera...
- Page 10 “WI-FI ON”, and then “ACV8305_XXXX”, and initial password is “1234567890”. ii. Turn on mobile phone WIFI, search for AP “ACV8305_XXXX” and select Connect. iii. If connected, the camera display screen will display as below picture. Activate APP: Activate “Denver 360°action camera” APP on mobile phone or ENG 10...
- Page 11 ACV-8305W Quick start guide tablet, and click the upper right corner to “Search for Camera”. Download: Enter camera folder, select the file to be downloaded and click to download. Play: Select the file on mobile phone and click to play.
- Page 12 ACV-8305W Quick start guide Important It is recommended to follow the above steps in order to achieve the best HD video or picture playing effect. Before connection, remember to make sure the SD card properly inserted into camera. After connection, it will not affect 4G communication function of mobile phone or tablet .
- Page 13 ACV-8305W Quick start guide Click “START TO SHARE”, videos shall start to merge together, after merging, videos can be shared via Youtube, Facebook, Wechat, QQ and etc. The sharing videos can be searched on its relevant websites or webpages. Notice: The merged video file is in .mp4 format.
- Page 14 ACV-8305W Quick start guide Effect of panoramic playing The following effects are available if played on APP player Tiny planet mode ENG 14...
- Page 15 ACV-8305W Quick start guide Fisheye mode Plane mode VR mode ENG 15...
- Page 16 CD ROM, or just go http://www.denver-electronics.com/pc-software-for-denver-acv-83 visit 05w/ to download and install Denver 360°action camera Player. Remind: If dialog box as below image appears during the installation process, please choose YES and continue the installation. Download video or picture onto PC:...
- Page 17 ACV-8305W Quick start guide Use the USB data cable attached to this product to connect the camera and PC. After connection, the camera display screen will display “MSDC”. Open “My computer” to select “VIDEO” OR “JPG” folder under “Removable disks”.
- Page 18 ACV-8305W Quick start guide Run player: Open the video or picture downloaded and stored on PC in the player. Playback video with player Clip the icon , choose the video which you want to play. ENG 18...
- Page 19 ACV-8305W Quick start guide When playing the video, move the mouse to top right cone, it will show some different mode(Plane/Planet/Invert). Clip it and will show different effects. Please clip and move the mouse, you could enjoy the video with full angle 360 degree.
- Page 20 ACV-8305W Quick start guide Edit and share video: The video and photo which are recorded by this device could be edited and shared, as above picture, it could be shared to YouTube, Facebook and some other popular social website. ENG 20...
- Page 21 ACV-8305W Quick start guide ENG 21...
- Page 22 ACV-8305W Quick start guide Important: On current video websites, the videos uploaded by users have been compressed automatically. This may lead to different video play effects between website and local videos. Technological parameters: Image sensor 4.0M (CMOS)×2 Functional mode Video & photo Lens F2.0 f=1.1mm...
- Page 23 ACV-8305W Quick start guide The product is equipped with a built-in battery. Do not put it directly into fire, or it may cause explosion or other dangers. The product may radiate heat due to long-time use or exposure to direct sunlight.
- Page 24 ACV-8305W Quick start guide ALL RIGHTS RESERVED, COPYRIGHT DENVER ELECTRONICS A/S Electric and electronic equipment and included batteries contains materials, components and substances that can be hazardous to your health and the environment, if the waste material (discarded electric and electronic equipment and batteries) is not handled correctly.
- Page 25 ACV-8305W Quick start guide Electric and electronic equipment and batteries is marked with the crossed out trash can symbol, seen below. This symbol signifies that electric and electronic equipment and batteries should not be disposed of with other household waste, but should be disposed of separately.
- Page 26 ACV-8305W Quick start guide www.facebook.com/denverelectronics Hereby, Inter Sales A/S, declares that this product (ACV-8305W) is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. A copy of the Declaration of conformity may be obtained Inter Sales A/S...
