Summary of Contents for Denver IPC-330
- Page 1 DENVER IPC-330 DENVER IPO-320...
-
Page 2: Installation Procedures
Pack list: IP camera Mounting bracket Antenna Power Adaptor Lan cable Screws Installation guide Some models are not equipped with an external antenna Note: Installation procedures: Start Connect the Hardware Install the Search Tool Login the IP Camera to the LAN Wireless Settings Login the IP Camera to the PC Client... - Page 3 IP Camera Internet Router Internet Cable Power Internet Router Internet Cable Power Connect the Camera with Internet cable to the router and with the power to the mains, as shown above.
- Page 4 1. Installation of the Search Tool Next Insert the CD and install the following software: Open the file “IPC-330 & IPO-320”-”Browser View”: Click “OCX setup”—“Next”—“Install”—“Finish” Open the file “Search Tool”, copy the “Search Tool” to the desktop and launch it.
- Page 5 Double click the camera IP address in the search tool. A Sign-in interface will be shown in your default browser, like below: Note: User: admin Password: None/blank (Please change the account info for safety after login) After you entered the correct user name and password, this login screen will be displayed. (It supports 6 visitors to view online at the same time) Note: If you use the IE browser, please choose the first sign-in mode (ActiveX Mode) to login.
-
Page 6: Wireless Setting
If you use the IE browser to connect the camera for the first time, maybe no image will be displayed, instead a an ActiveX prompt will appear, please click the prompt and choose Run Add- on, refresh the IE interface, and login the camera again, then you will see the live video. -
Page 7: Ddns Service Settings
Checking the WIFI Signal Connection Status 4. DDNS Service Settings 1). Click on the icon to access to “DDNS Service Settings”. 2). Choose the DDNS server, input the DDNS user name and password. 3). Submit, refresh, then DDNS status will be shown as “DDNS Succeed”. Thus the remote address is http://G1200.vipcam.org. - Page 8 5. Mail Service Settings and Alarm Service Settings 1). The Mail service settings are a requirement for the alarm function. If your camera will be activated it will send you an email with photos attached. For this, you must assure that the mail service is configured correctly and successfully tested.
-
Page 9: Record & Capture Path
Record cover: Delete the old files when the disk capacity is almost depleted. 7. Record Schedule (For IPC-330 with SD card recording function) This section explains the SD card recording settings. If the SD card has been inserted, the capacity of the card will be displayed. - Page 10 Record coverage: Delete old files when the SD card is nearly full. Record time: Create a video file every 10 minutes. Timer recording: Set the time, select all, store recording to the SD card. You can playback the video online with IE browser. Press the “Enter” button, choose the last sign in code:...
- Page 11 8. Upgrade Device Firmware & System Log 1). With this option you may reboot the camera, restore it to the factory settings, and upgrade the system. 2). The Alarm log is provided for administrators to monitor the alarm events...
- Page 12 9. Basic Network Settings & PTZ Settings 1). Through setting to set some PTZ function 2). You may modify the network Settings of IP address and gateway, and the port number...
- Page 13 10. Alias setting & Device Date & Time Setting You can choose any NTP server and click on “Submit” Choose the desired time zone you want and click on “Submit” to activate it The display name of the camera...
- Page 14 11. User Setting & Multi-Device Setting Modification of the user password Refresh the device in LAN search to find add another camera Click on “the 2 device” or any other device Click on the LAN equipment added in the search, enter the user name and password Click on “Submit”...
-
Page 15: Password Forgotten
FAQ: A. Password forgotten Reset your camera. While the power is on, you must press the RESET button for 10 seconds. The button you will find at the bottom of the camera. With outdoor cameras the white reset button is located at the end of the power cord. After the reset is completed, the camera is reset to the factory settings, then the username and the password is "admin". - Page 17 DK-8250 Egaa Denmark www.facebook.com/denverelectronics Hereby, Inter Sales A/S, declares that this tablet DENVER (DENVER IPC-330 and DENVER IPO-320) is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity may be obtained at...
