- Page 1 Infrared Model IR-B02 User Manual for Short Wave Infrared Paint Curing Equipment...
- Page 2 All of our manufactured or assembled parts conform to the listed regulations. If you change the machine without our explicit agreement, this declaration will be herewith invalidated. Product type: Painting- and drying equipment (paint dryer) Type designation: IR-B02 Serial-#: Construction year: 2015...
- Page 3 Table of Contents 1. Important Information ..........................4 2. Safety Regulations and Maintenance Advice ................... 4 2.1 Work Area ............................5 2.2 Use ..............................5 2.3 Maintenance and Care ........................5 2.4 More Information ..........................5 3. Technical Description of the Machine ...................... 6 3.1 Technical Information ........................
-
Page 4: Important Information
1. Important Information Thank you for purchasing this B-Tec infrared paint curing unit IR-B02. Please note, the unit has a rating plate attached which includes the model and serial number. Should you ever need service or parts, please provide that information when calling B-Tec System, or your distributor. -
Page 5: Work Area
2.1 Work Area Do not use this equipment in an explosive or combustible environment; otherwise it may lead to fire. Use caution when moving the equipment over uneven floors to avoid tipping over or damage to the emitters. ... -
Page 6: Technical Description Of The Machine
1 - 35 min 28” x 61” x 24” Dimension: (W x H x L) Ultrasonic distance measurement 3.2 Wiring Diagram Diagram Main Switch Control Board ultrasonic emitter - B-Tec Systems reserves the right to make technical changes without notice -... -
Page 7: Spare Parts
Large Reflective U-shaped Support bracket B01-B-7 B03-22 Panel Transformer Control Box B02-1 B01-9 220V/6W Locking Ring B01-22 Relays 10A B03-30 Bent Panel B03-18 Lid Control Box B01-11 - B-Tec Systems reserves the right to make technical changes without notice -... -
Page 8: Assembly / Installation
4. Assembly / Installation 1. Insert the upper section ③ of the vertical bar into the lower section ②. 2. Take out the pedestal ①, insert the vertical bar into the pedestal ① and fasten the screws. 3. Install the support bracket ④ onto the vertical bar. Attach the cassette assembly to the support bracket facing forward as in diagram below and fasten the handle. -
Page 9: Operating Instructions
Filler/Stopper Primer Hi-build 10-12 Solid-color Clear coat Waterborne primer 8-10 Note: We suggest that 5 minutes half power / flash time is added when curing high build primers and dark colors. When possible consult a B-TEC paint curing data sheet. -
Page 10: Replacement Of Emitter Lamp Tube
6. Replacement of Emitter Lamp Tube Un-plug the power supply, before replacing the infrared emitter / tube. 1. Remove the side panel. 2. Release the radiating panel / reflector. 3. Disconnect the two leads to the emitter /lamp. 4. Remove the protective grill on the front of the cassette. 5. -
Page 11: Troubleshooting
IF IN ANY DOUBT ABOUT ASSEMBLY OR OPERATION OF THE UNIT PLEASE DO NOT HESITATE TO CONTACT YOUR DISTRIBUTOR OR THE B-TEC SERVICE DEPARTMENT AT (480) 621-5304. Above specifications and diagrams are subject to revision. B-TEC reserves the right to make any changes without notification.
