Dreamline ENIGMA-Z SHEN-623448-## Installation Instructions Manual

Shower enclosure
Hide thumbs

Advertisement

Quick Links

Download this manual
S
HOWER
IMPORTANT
DreamLine
reserves the right to alter, modify or redesign products at any time without prior notice.
®
For the latest up-to-date technical drawings, manuals, warranty information or additional details please
refer to your model's web page on DreamLine.com
Right-hand return panel installation shown
For more information about DreamLine
ENIGMA Z Enclosure Manual Ver 1 Rev 4 04/2017
ENIGMA-Z Enclosure
E
NCLOSURE
Shower Doors & Tub Doors please visit DreamLine.com
®
I
NSTALLATION
©2017 DreamLine. All Rights Reserved
I
NSTRUCTIONS
MODEL #s
SHEN-623448-##
SHEN-623460-##
##=finish
07- Brushed Stainless Steel
08- Polished Stainless Steel

Advertisement

loading
Need help?

Need help?

Do you have a question about the ENIGMA-Z SHEN-623448-## and is the answer not in the manual?

Questions and answers

Related Manuals for Dreamline ENIGMA-Z SHEN-623448-##

Summary of Contents for Dreamline ENIGMA-Z SHEN-623448-##

  • Page 1 ® For the latest up-to-date technical drawings, manuals, warranty information or additional details please refer to your model’s web page on DreamLine.com MODEL #s SHEN-623448-##...
  • Page 2 This model is treated with DreamLine’s exclusive ClearMax Glass technology. This is a specially formulated coating that prevents the build up of soap and water spots. Install the surface with the ClearMax label towards the inside of the shower. Please note that depending on the model, the glass may be coated on either one or both surfaces.
  • Page 3 MANUAL FOR DETAILS REGARDING PROPER INSTALLATION. Roller Wheel Assembly Set Screws THE LATEST VERSION OF THE INSTALLATION must be tightened MANUAL IS AVAILABLE TO VIEW OR PRINT AT DREAMLINE.COM ENIGMA Z Enclosure Manual Ver 1 Rev 4 04/2017...
  • Page 4 Reinforcement for Enigma Series Heavy Glass frameless sliding shower or tub door Install studs OR install 2”x 6” wood blocking between the studs where the Guide Rail Brackets will attach to the wall ” 2 ” S t u ” 2 ”...
  • Page 5 “Detailed Diagram of Shower Door Components”. If the unit has been damaged, has a finishing defect, or has missing parts, please contact our customer support department within 3 business days of the delivery date. Please note that DreamLine ®...
  • Page 6 Right-hand return panel installation Left-hand return panel installation NOTE: The Enigma-Z enclosure is reversible for left or right-hand return panel installation. This manual will show the right-hand return panel installation. For a left-hand return panel installation, simply begin on the opposite wall and reverse the orientation of the parts as necessary.
  • Page 7 Before discarding the carton, check for small hardware bags that may have fallen to the bottom of the box. If any parts are damaged or missing, please contact DreamLine for replacement. The shipping boxes may contain extra parts not used in ®...

  • Page 8: Parts List

    Detailed Diagram of shower door components The glass surface with the ClearMax™ label must be installed to face inside of the shower Parts List Description Description Part# Part# Door stopper 2pcs Guide block Stationary glass Bumper seal strip 2pcs Upper Guide rail Anti-water strip 2pcs Roller...
  • Page 9 Shower Enclosure Plan 34 1/2" 2-3/8” minimum threshold required 34 1/2" 2-3/8” minimum threshold required 56-3/8” min to 60-3/8” max ENIGMA Z Enclosure Manual Ver 1 Rev 4 04/2017...

  • Page 10: Installation Steps

    Installation steps This shower enclosure requires a minimum 2-3/8” wide threshold, shower base, or installation space. Compare the overall outside dimensions of the shower enclosure model size (as shown on the “Shower Enclosure Plan”) with your finished threshold. (Fig. 1) threshold 2-3/8”...
  • Page 11 Place the Return Panel Glass (#22) < 48”or < 60” on the pre-installed shower base or threshold. Position the panel up against the wall and level it vertically (plumb). Make sure the Return Panel Glass (#22) is aligned with the shower base or threshold and will create an opening that is within the model dimensions of the door section: <48”...
  • Page 12 Drill the holes in the wall using a Ø5/16” drill bit and insert the Wall Anchors (#9b) for the two Wall Brackets (#19). Mount the Wall Brackets (#19) to the wall using the Truss Head Screw ST4.2×55 (#18). For installation into an Acrylic Base: Drill a hole in the shower base threshold using a Ø1/8” drill bit and mount the remaining Wall Bracket (#19) to the threshold using the Round Head Screw ST4.2×25 (#17).
  • Page 13 Measure the distance from the finished wall to the inside surface of the installed Return Panel Glass (#22). This distance will represent the finished opening size “W” that will be used to calculate the finished cut dimension for the Upper Guide Rail (#03). (Fig. 7) The Upper Guide Rail (#03) has been precut for your model width of: 48”...
  • Page 14 Attach the Upper Guide Rail (#03) to the Stationary Glass (#02) with the Glass Brackets (#07) and tighten the bolts into the pre-drilled holes in the Upper Guide Rail (#03). Make sure both adjustment disks are installed in the same direction with the high spot facing towards the door end (see *NOTE below).
  • Page 15 Place the Stationary Glass (#02) with the Upper Guide Rail (#03) onto the threshold and position it against the wall. Fasten the Upper Guide Rail (#03) to the Return Panel Glass (#22) using the Glass Connector (#21). Tighten the set screws to secure the guide rail bracket sleeve to the Glass Connector (#21).
  • Page 16 . Once the Upper Guide Rail (#03) is leveled, mark the position of the Wall Bracket (#19) and the Guide Rail Bracket (#08) on the wall. (Fig. 13) Fig. 13 Mark the Guide Block (#12) position and the holes for drilling on the threshold. (Make sure the Guide Block (#12) is square to the Stationary Glass (#02)).
  • Page 17 Carefully set the Stationary Glass (#02) and Upper Guide Rail (#03) aside, along with the Guide Block (#12) and Anti-Splash Guard (#15). Remove the Guide Rail Brackets (#08) from the Upper Guide Rail (#03) (as shown below) and the Wall Bracket (#19) from the Stationary Glass (#02). Place the Wall Bracket (#19) and Guide Rail Bracket (#08) back to the outlined positions and mark the holes for drilling.
  • Page 18 protective NOTE: Before you install the Stationary Glass (#02), padding bring the Door Glass (#05) into the shower and lean it against the wall. Make sure the door is facing in the right direction for installation with the handle holes on the correct side. After the Stationary Glass (#02) is installed, it may not be possible to easily get the door glass into the shower or to turn it around.
  • Page 19 18 . Carefully p lace the Stationary Glass (#02) with the Upper Guide Rail (#03) onto the threshold with the notch fitting into the Guide Block (#12). Position the Stationary Glass (#02) against the wall. (Please note that the Stationary Glass (#02) installs on the outside and the Upper Guide Rail (#03) goes on the inside of the shower).
  • Page 20 . Fasten the Guide Block (#12) to the threshold with the Countersunk Ø1/8" Screws ST4.2×25 (#17). (Fig. 21) Fig. 21 TIP: Level the installed Upper Guide Rail (#03) as necessary using the Guide Rail Brackets (#08) first and then the Glass Brackets (#07). Start adjustments from the door end. (Fig. 22 and Fig. 23) Door end Panel end Guide Rail Bracket...
  • Page 21 Use the Roller Installation Tool to install the Roller Assemblies (#04) onto the Door Glass (#05). (Fig 24.1) Suspend the door by hanging the Roller Assemblies (#04) onto the Upper Guide Rail (#03) and sliding the bottom edge of the Door Glass (#05) into the groove of the Guide Block (#12).
  • Page 22 . If necessary, the door glass can be adjusted to create a better seal with the wall. The Bumper Seal Strip (#13) must be installed on the Door Glass before making any adjustments. Use the set screws to raise or lower the wheels. Fully Tighten all set screws after all adjustments are made.
  • Page 23 Adjust both Door Stoppers (#01) to ensure that they are positioned upright and the Door Glass (#05) is in its maximum opening and closing range. Apply Thread Lock Adhesive (#20) to the set screws and tighten the set screws to fasten them in place. (Fig. 21) Adjust the Roller Guards (Fig.
  • Page 24 Apply Waterproof silicone at both ends of the Anti-Splash Guard (#15), around the Guide Block (#12) and around the Anti-Splash Guard Cap (#16). (Fig. 29) Waterproof Waterproof silicone silicone Fig. 29 Apply a good quality mildew-resistant silicone sealant along the connection of the panel glass with the wall and the threshold.
  • Page 25 NOTE: To maximize the life of your door, it is important to regularly inspect the glass and other hardware for misalignment, proper attachment, and/or damage. Contact DreamLine with any questions or concerns. ®...
  • Page 26 TEL: 866-731-2244 FAX: 866-857-3638 DREAMLINE.COM For more information on DreamLine Shower Doors and Enclosures please visit DreamLine.com ® ©2017 DreamLine. All Rights Reserved...

This manual is also suitable for:

Enigma-z shen-623460-##
