Allflex RS250-V2 User Manual

Allflex Worldwide Sales Offices:
Allflex Europe
ZI. de Plagué
Route des Eaux, B.P. 90219 Dallas/Ft. Worth Airport
35502 Vitre Cedex, France Texas 75261-2266
Tel 33 (0)2.99.75.77.00 Tel (972) 456-3686
Fax 33 (0)2.99.75.77.29 Fax (972) 456-3882
http://www.allflex-boulder.com
FCC ID: NQY-930040
Note: This equipment has been tested and found to comply with the limits for a Class A digital
device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy, and if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
This device has been tested and meets the Electromagnetic Compatibility (EMC) requirements of
EMC Directive 2004/108/EC and R&TTE Directive 99/5/EC.
This equipment has been designed, constructed, and tested for compliance with FCC
Rules that regulate intentional and unintentional radiators. The user is not permitted to
make any modifications to this equipment or use it in any manner inconsistent with the
methods described in this User Manual, without express approval from Allflex. Doing
so will void the user's authority to operate this equipment.
Trademark Notices
Hyperterminal® is a registered trademark of Hilgraeve, Inc.
MS-Windows® is a registered trademark of Microsoft, Inc.
Configurator® is a registered trademark of Allflex USA, Inc.
Other Agency Certification Notices
Industry Canada EMC Certification No. 4246A- __________
Allflex USA, Inc. Allflex Australasia
P.O. Box 612266 Private Bag 11003
Palmerston North
New Zealand
Tel 64 (06) 356-7199
Fax 64 (06) 358-5982
Caution
12
Allflex ISO Compatible RFID Stick Reader
Model RS250-V2
User Manual
(Revision B - June 2006 / Software V3.05+)
Preparing for Use
Unpacking
The Allflex Stick Reader is shipped in a box with this instruction guide, DC power
plug pigtail cable (for battery connection), and Configurator® diskette. Information
contained in this guide pertains to providing power to the Reader, connecting its
serial data port, setting configuration options using the Reader's serial port, and
operating the Reader. In order to proceed, it is necessary that the user have a suitable
power source (see Page 2 of this guide) and an assortment of ISO transponders.
Stick Reader User Interface
The photograph (Figure 1) below illustrates the Stick Reader's features that comprise
the user interface and are pertinent to its operation.
corresponding functional description of use are described in Table 1.
Figure 1 - Stick Reader Features and User Interface
Antenna
Enclosure
Audible Beeper
DB9F Connector
DC Power Jack
Data/Power Cable
Each feature and its
Red Indicator
Green Indicator
Read Button
Handle Grip
Attachment Ring
Strain Relief
