  • Page 5: Introduction

    The PCI302 (Process Control Interface) is a high performance Fieldbus interface that combines advanced process control with multiport communications management. PCI302 is a card designed to work inside industrial or commercial PCs. Featuring independent Fieldbus H1 (31.25Kbps) master ports and powered by a 32-bit RISC CPU. Directly connected to the PC bus (through PCI bus or ISA bus), it provides a fast communication path between the Fieldbus and PC applications.
  • Page 6: General Features

    The PC’s plug and play system allocates the addressing resources for the board operation. The PCI302 ISA bus version can also be easily installed on the ISA or EISA bus of any AT- compatible PC. Unique hardware design allows the installation of up to eight PCI302 cards (depending on the number of free ISA slots) on one PC bus, sharing the same I/O port and interrupt.
  • Page 7: Hardware Overview

    Figure 2 - Fieldbus Typical Application using PCI302 cards. Remarks • 1 to 8 PCI302 cards can be installed in the same PC Server. • Up to 4 ports in each PCI302 Fieldbus line connected. • Redundant operation (1 to 4 PCI302s on each Fieldbus, distributed on different PCs).
  • Page 8: Cpu (Central Processing Unit)

    MODEMs), and the DP arbitration mechanism. PC Bus (Computer Expansion Bus) A PCI bus (specification v2.1) (*), 16-bit ISA or 32-bit EISA bus, on which the PCI302 cards are plugged. It provides power and PC access to the card. Local Bus (High Speed Wide Bus) A 32-bit internal bus that interconnects the CPU to fast devices (RAM, NVRAM, FLASH and DP).
  • Page 9: Software Overview

    Specific hardware driver for Windows NT and 2000 Operating System, implementing effectively the access to local PCI302s. DP (Dual Port RAM) Memory shared by the PCI302 and PC, at hardware and software levels, which contains all structures required for data and command transfer between them. (PCI302 Fieldbus ports 0 - 63) 0 - 63 The card independent ports, running inside the PCI302.
  • Page 10: Pci302 Technical Specifications

    PCI302 - Operation & Maintenance Instructions Manual PCI302 Technical Specifications PC Bus PCI302 Version 1.xx PCI302 Version 2.0 Type ISA (16-bit slot) or EISA PCI (specification v2.1) (*) Hardware Interrupt IRQ 5, 10, 11, 12 or 15 none I/O Port Base...
  • Page 11: Appendix A

    The switch W6 (NVRAM BATTERY) is factory set to the OFF position in order to avoid energy loss while the card is at Smar`s stock or on the Customer’s shelf. BEFORE USING THE PCI302 V1.xx, THE DIP6 SHOULD BE TURNED ON.
  • Page 12: Appendix B

    Appendix B Physical Dimensions PCI302 Version 1.1x Figure 5 - PCI302 card V1.1x Physical dimensions (mm). PCI302 Version 1.2x Figure 6 - PCI302 card V1.2x Physical dimensions (mm).
  • Page 13: Pci302 Version 2.0

    PCI302 - Operation & Maintenance Instructions Manual PCI302 Version 2.0 Figure 7 - PCI302 card V2.0 Physical dimensions (mm)
  • Page 14: Appendix C

    Appendix C SC71 Cable Specification PIN Description Signal 0DATA+ 0DATA- 1DATA+ 1DATA- 2DATA+ 2DATA- 3DATA+ 3DATA- GND (shield) Table 1 - SC71 Pin Description Figure 8 - SC71 Pin view.
  • Page 15: Appendix D

    IMPORTANT All of the PCI302 cards installed in the PC bus must be set with the same I/O port and same IRQ, but each one of them with a different card number. The I/O and IRQ of the PCI302 must not conflict with all the other cards (besides PCI302s) already installed in the PC.
  • Page 16: Hardware Installation

    (16 bits slots) or EISA of every commercial or industrial PC. Refer to the computer manual for instructions on how to install and remove ISA cards. Turn off the PC before inserting or removing the PCI302s from the bus. There is a limit of up to 8 PCI302 cards in the PC bus. NOTES For appropriate refrigeration to the PCI302 cards.
  • Page 17: Updating The Firmware

    Updating the firmware ATTENTION While downloading a PCI302 firmware, all fieldbus activities in the PCI302 will stop. After the firmware download is done, it will be necessary to download the PCI302 configuration via Syscon. 1. Launch the FBTools Wizard, located in the Start menu...
  • Page 18 PCI302 - Operation & Maintenance Instructions Manual 4. Click the Browse... button to select the firmware file to be downloaded (PCI*.abs file). 5. After selecting the firmware file, the Download button will be enabled. Click on it to initiate the firmware download.
  • Page 19 PCI302 - Operation & Maintenance Instructions Manual 7. The progress bar at the bottom of the dialog box will show the progress of the operation. 8. When the download is complete, a dialog box will appear confirming that the program was downloaded successfully.
  • Page 20 PCI302 - Operation & Maintenance Instructions Manual NOTE (*) PCI302 v2.0 card follows PCI bus specification version 2.1. However it is recommended to be used on PCI bus specification version 2.2 systems. To operate on a PCI v2.1 specification system, the 5 volts keyed PCI connectors must provide 3.3 volts power.
  • Page 21 Appendix E SRF – Service Request Form smar Proposal Nº: PCI302 – Process Control Interface COMPANY INFORMATION Company: _____________________________________________________________________________________________________ Unit: ________________________________________________________________________________________________________ Invoice: _______________________________________________________________________________________________________ COMMERCIAL CONTACT Full Name: ____________________________________________________________________________________________________ Phone: _________ _________________________ _________ _________________________ Fax: _______________________ E-mail: _______________________________________________________________________________________________________ TECHNICAL CONTACT Full Name: ________________________________________________________________________________________________...
  • Page 22 PCI302 - Operation & Maintenance Instructions Manual...
  • Page 23 Appendix F SMAR WARRANTY CERTIFICATE SMAR guarantees its products for a period of 24 (twenty four) months, starting on the day of issuance of the invoice. The guarantee is valid regardless of the day that the product was installed. SMAR products are guaranteed against any defect originating from manufacturing, mounting,...
  • Page 24 13. It is the customer’s responsibility to clean and decontaminate products and accessories prior to shipping them for repair, and SMAR and its dealer reserve themselves the right to refuse the service in cases not compliant to those conditions. It is the customer’s responsibility to tell SMAR and its dealer when the product was utilized in applications that contaminate the equipment with harmful products during its handling and repair.
