- Page 1 USER MANUAL ENGLISH Version 1.0 ME700P QMAXZ Lighting 2009, © all rights reserved www.qmaxz.com...
- Page 2 QME700P v1.0 - 1 - QMAXZ 2009...
- Page 3 Page 7 6.4 Fixture start up Page 9 7. Fixture function menu Page 10 7.1 Function menu navigation Page 10 7.2 Function menu QME700P Page 11 7.3 Menu Functions Page 19 7.4 Function overview Page 21 8. Gobo and gobo size Page 22 8.1 Fixed metal gobos...
-
Page 4: Introduction
For the latest updates of product documentation, please visit the user support area of the QMAXZ website at www.qmaxz.com NOTE: Information and Specifications in this document are subject to change without notice. QMAXZ Lighting assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. 2. UNPACKING... -
Page 5: Rigging The Fixture
10 times the weight of the fixture. To un-mount the brackets turn the twist lock by 90 degrees counter clockwise and release the brackets from the fixture base. QME700P v1.0 - 4 - QMAXZ 2009... -
Page 6: Lamp Replacement
5. Insert the new lamp into the socket. Make sure that the lamp is installed tightly into the lamp socket. 6. Close the lamp housing back cover and fasten the 2 screws again. QME700P v1.0 - 5 - QMAXZ 2009... -
Page 7: Lamp Adjustment
Check that the power supply voltage and frequency are corresponding with the AC mains supply needed by the fixture (check AC mains panel on the fixture). Before switching on the fixture verify that the pan & tilt lock is released. QME700P v1.0 - 6 - QMAXZ 2009... -
Page 8: Fuse Replacement
There are also two fuses on the main PCB board inside the fixture, for how to replace this please contact your dealer. 6.3 Signal Connections The QMAXZ QME700P fixtures have both 5 pin XLR and Ethercon RJ45 sockets. For the pin-layout see the following table. Pin-Layout... -
Page 9: Dmx512 Connection
Do not overload the link. A maximum of 10 devices may be connected on a serial link. Insert a male 120Ω XLR termination plug, in the last fixture. This to avoid signal reflection and interference. DMX Terminator DMX connection panel QME700P v1.0 - 8 - QMAXZ 2009... -
Page 10: Fixture Start Up
Always use a professional Ethernet Switch 10/100Mbit (for example ELC lighting type switch8LX) and set Broadcast storm protection to off, the QME700P fixtures are auto MDIX so do not use “crossed” cables. The fixtures DMX-address, Art-Net universe and Network address can be set in the Fixture Function Menu (see chapter 7). -
Page 11: Fixture Function Menu
When no button on the control panel is touched for more then 30 seconds the display will turn off and the menu will go back to the DMX start address, to turn it on simply press a button and repeat the above steps to enter the menu. QME700P v1.0 - 10 - QMAXZ 2009... -
Page 12: Function Menu Qme700P
7.2 Function Menu QME700P. QME700P v1.0 - 11 - QMAXZ 2009... - Page 13 QME700P v1.0 - 12 - QMAXZ 2009...
- Page 14 QME700P v1.0 - 13 - QMAXZ 2009...
- Page 15 QME700P v1.0 - 14 - QMAXZ 2009...
- Page 16 QME700P v1.0 - 15 - QMAXZ 2009...
- Page 17 QME700P v1.0 - 16 - QMAXZ 2009...
- Page 18 QME700P v1.0 - 17 - QMAXZ 2009...
- Page 19 QME700P v1.0 - 18 - QMAXZ 2009...
-
Page 20: Menu Functions
When the address of the first fixture is 001, the start address of the next fixture depends on the number of DMX channels used by the previous one. QME700P fixtures are 24 channels@16Bit in “Normal” mode and 26 channels@16Bit in “Extended” mode, default the fixture is in “Normal” mode, “Extended” mode can be set in the “Operating mode”... - Page 21 Setting the individual motor calibration, use [UP] or [DOWN] buttons to scroll the list, [ESC] to exit, press [MENU] to highlight the value, use [UP]/[DOWN] to set the value, after setting press first [MENU] then [ESC] to store configuration(display will show “Storing Configuration”) . Default value is “0”. QME700P v1.0 - 20 - QMAXZ 2009...
-
Page 22: Function Overview
Iris √ √ Dimmer Fine √ Zoom √ √ Color wheel √ √ Focus √ √ Cyan √ √ Frost √ √ Magenta √ √ Control √ √ Yellow √ √ √ √ QME700P v1.0 - 21 - QMAXZ 2009... -
Page 23: Gobo And Gobo Size
Optional gobo’s: QGM9 QGM10 QGM11 QGM12 QGM13 8.2 Rotating / Glass Gobos overall size 28mm, image size 21,5mm Standard factory installed: QGG1 QGG2 QGG3 QGG4 QGG5 QGG6 Optional gobo’s: QGG7 QGG8 QGG9 QGG10 QGG11 QME700P v1.0 - 22 - QMAXZ 2009... -
Page 24: Gobo Positions
7. Put back the gobo holder by sliding it into the pressing clamp and then press it towards the wheel lock into the snaps. 8. Attach the safety cable of the cover again, and put the cover back on, tighten the 4 screws. QME700P v1.0 - 23 - QMAXZ 2009... -
Page 25: Maintenance
Teflon-based grease that can be reapplied by you’re dealer. Check main power plug regularly, for connection and mechanical liability. 10.1 Technical Data Model QME700P Channels (normal) Channels (extended) DMX Protocol DMX 512 & Art-Net... -
Page 26: Photometric Data
10.2 Photometric Data QME700P: QME700P v1.0 - 25 - QMAXZ 2009... -
Page 27: Dmx Protocol
11. DMX PROTOCOL 11.1 QME700P CHANNEL LIST QME700P DMX Protocol Operating Mode DMX value Function Function Descriptions Normal Extended Default Range 0-255 Pan Fine 0-255 Tilt 0-255 Tilt Fine 0-255 Move Speed 0-255 Shutter 0-15 Closed 16-31 Open(Dimmer doors mode) 32-95 Strobe(Fast>>Slow) -
Page 28: Dmx Protocol
QME700P DMX Protocol Operating Mode DMX value Function Function Descriptions Normal Extended Default Range ° Gobo Rotation 0-127 Index 0-360 128-190 Rotate CW (Fast>>Slow) 191-192 Stop 193-255 Rotate CCW (Slow>>Fast) Gobo Rotation Fine 0-255 Prism Open 4-19 ° 20-127 Manual rotation 360 128-189 Rotate CW (Fast>>Slow) -
Page 29: Dimensional Drawings
10.3 Dimensional Drawings QME700P v1.0 - 26 - QMAXZ 2009... -
Page 30: Troubleshooting
Disconnect the mains power supply and replace the Lamp has reached the end of his lamp (see chapter 5). lifetime cycle. QME700P v1.0 - 29 - QMAXZ 2009... -
Page 31: Info
QMAXZ lighting Mr. Strikstraat 8 5708 GB Helmond, The Netherlands Tel: +31 492 564 144 Fax: +31 492 526 285 info@qmaxz.com QME700P v1.0 - 30 - QMAXZ 2009...
