- Page 1 HDMI T RANSMITTER YSTEM BCI reserves the right to make changes to the products described herein without prior notice or consent. No liability is assumed as a result of their use or application. All rights reserved. ©2013 Broadata Communications, Inc.
- Page 2 LBC-HDBT User’s Manual Link Bridge HDbaseT HDMI Transmission System SAFETY INSTRUCTIONS AND COMPLIANCE DECLARATIONS PLEASE OBSERVE THE FOLLOWING SAFETY PRECAUTIONS SURGE PROTECTION DEVICE RECOMMENDED This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc.
- Page 3 4.0 MAINTENANCE AND TROUBLESHOOTING ....10 4.1 MAINTENANCE ............. 10 4.2 TROUBLESHOOTING ..........10 5.0 SPECIFICATIONS ............12 6.0 SERVICE PROCEDURE ..........13 6.1 REPLACEMENT POLICY ..........13 6.2 RETURN AND REPAIR SERVICE ......... 13 7.0 LIMITED WARRANTY ............ 14 Broadata Technical Support, (800) 214-0222...
-
Page 4: Product Description
LBC-HDBT User’s Manual Link Bridge HDbaseT HDMI Transmission System 1.0 PRODUCT DESCRIPTION The LBC-HBT-Tx/Rx with HDMI video and RS-232 over Single CAT5e/6 transmitter and receiver set can send uncompressed audio/video over a single run of CAT5e/6 cable up to 100 m with PoC (Power over cable) feature and the added benefit of control through the built-in RS-232 and IR ports and a bi-directional LAN connection. -
Page 5: Operation Controls And Functions
Place the IR blaster in direct line-of-sight of the equipment to be controlled. 7. IR 2 Extender: Connect to the supplied IR receiver cables for IR signal reception. Ensure that remote being used is within the direct line-of-sight of the IR extender. Broadata Technical Support, (800) 214-0222... -
Page 6: Receiver Front And Rear Panels
LBC-HDBT User’s Manual Link Bridge HDbaseT HDMI Transmission System 8. Link LED: The yellow LED will illuminate when both the input and output signals are connected. 9. CAT5e/6 Out: Connect to the reciever unit with a Single CAT5e/6 cable for tranmission of all data signals. -
Page 7: Serial Control
9. CAT5e/6 In: Connect to the transmitter unit with a Single CAT5e/6 cable for tranmission of all data signals. 3.0 SERIAL CONTROL 3.1 D-Sub Pin Assignment Define TX/RX TxD/RxD RxD/TxD Broadata Technical Support, (800) 214-0222... -
Page 8: Ir Blaster Cable Pin Assignment
LBC-HDBT User’s Manual Link Bridge HDbaseT HDMI Transmission System 3.2 IR Blaster Cable Pin Assignment IR Blaster Power 5V IR Blaster Signal 3.3 IR Receiver Cable Pin Assignment IR Receiver IR Signal Power 5V Grounding Broadata Technical Support, Sales@Broadatacom.com... -
Page 9: Maintenance And Troubleshooting
However, observe the following light indicators to make sure that the unit is working properly: 4.2 Troubleshooting If the LBC-HDBT units do not operate properly after installation, check for possible cable breaks, loose connections, and incorrect cable connections. If problems persist that may be fiber related, contact BCI at 1-800-214-0222 for further assistance. - Page 10 LBC-HDBT User’s Manual Link Bridge HDbaseT HDMI Transmission System 3. If the POWER indicator and Link indicator are ON, but the channels are not operating, then: a. Check to see that the attached user equipment is turned b. Both ends of the link are connected to the corresponding equipment and to the same corresponding channel port.
-
Page 11: Specifications
Number of Cables Connector/ Distance RJ-45 / Up to 100m PHYSICAL Dimensions Standalone 4.03”(W) x 3.95”(D) x 0.98”(H) Power Consumption +24VDC @ 1.25 Amps (Max.) Operating Temperature 0 to +40 Humidity 20 to 90% RH, Non-Condensing Broadata Technical Support, (800) 214-0222... -
Page 12: Service Procedure
U.S. Please call Customer Service at 800-214-0222 for information. 6.2 Return/Repair Service The LBC-HDBT System contains no user serviceable components. If you have a problem with your unit, please contact the Customer Service Department. To facilitate our return/repair processing please contact Broadata Communications, Inc. -
Page 13: Limited Warranty
HDbaseT HDMI Transmission System 7.0 LIMITED WARRANTY Broadata Communications, Inc. (BCI) warrants, for a period of one year from date of shipment, each product sold shall be free from defects in material and workmanship. BCI will correct, either by repair, or at BCI’s... - Page 14 LBC-HDBT User’s Manual Link Bridge HDbaseT HDMI Transmission System Broadata Technical Support, Sales@Broadatacom.com...
- Page 15 LBC-HDBT User’s Manual Link Bridge HDbaseT HDMI Transmission System Broadata Technical Support, (800) 214-0222...
- Page 16 Broadata Communications, Inc. 2545 West 237th Street, Suite K Torrance, CA 90505 1-800-214-0222 (310) 530-1416 (310) 530-5958 (Facsimile) e-mail: CustomerService@Broadatacom.com Website: www.broadatacom.com 60000-LBC-HDBT...
