Save This Manual for Future Reference
Dual Rotating Rear Tine Tiller
Operator's Manual
MODEL NUMBER
YT4565
SERIAL NUMBER
PURCHASE DATE
Both model number and serial
number may be found on the
main label (see Page 2, Figure 1).
You should record both of them
in a safe place for future use.
FOR YOUR SAFETY
READ AND UNDERSTAND THE ENTIRE MANUAL BEFORE OPERATING MACHINE
Tame the Great Outdoors
TM
Advertisement
Table of Contents
Related Manuals for YARDMAX YT4565
Summary of Contents for YARDMAX YT4565
-
Page 1: For Your Safety
Save This Manual for Future Reference Dual Rotating Rear Tine Tiller Operator’s Manual MODEL NUMBER YT4565 SERIAL NUMBER PURCHASE DATE Both model number and serial number may be found on the main label (see Page 2, Figure 1). You should record both of them in a safe place for future use. - Page 2 Up for the job? YARDMAX is. When looking for outdoor power equipment (OPE) to get the job done right, at the right price, YARDMAX delivers the perfect combination of performance and practicality. YARDMAX has a solution that’s right for you.
- Page 3 California to cause cancer and birth defects or other reproductive harm. DISCLAIMER YARDMAX reserves the right to discontinue, change, ENVIRONMENTAL and improve its products at any time without notice or obligation to the purchaser. The descriptions and...
-
Page 4: Specifications
SUPPORT Have questions about your YARDMAX equipment? Call us at 844-YARDMAX, email us at support@yardmax.com, or contact us via your favorite social media site. SPECIFICATIONS Model number YT4565 Engine briggs & Stratton Displacement 208 cc Start Type Recoil Fuel Tank Size .75 gal... -
Page 5: Symbols
Dual Rotating Rear Tine Tiller Operator’s Manual » SYMBOLS The rating plate on your machine may show symbols. These represent important information about the product or instructions on its use. Read these instructions carefully. No smoking, sparks, or flames. Wear eye protection. Do not touch parts that are hot from operation. -
Page 6: Safety
Always keep hands and feet away from all moving parts during fumes are dangerous, containing carbon monoxide, an odorless operation. Moving parts can cut or crush body parts. and deadly gas. Operate this unit only in a well-ventilated outdoor area. Always keep hands and feet away from all pinch points. -
Page 7: Unpacking The Container
Dual Rotating Rear Tine Tiller Operator’s Manual » SPECIFIC SAFETY RULES Thoroughly inspect the area to be tilled, and remove all debris Use extreme caution when in reverse or pulling the machine and hard or sharp objects such as stones, sticks, glass, wire, bones, towards you. -
Page 8: Contents Supplied
COnTEnTS SUPPlIED Your YARDMAX rear tine tiller comes partially assembled and contains the following: HARDWARE KIT 1. Main Machine 7. Hardware Kit, Including: 2. Operation Handle × 2 3. Shift Rod M8 × 25 × 1 4. Depth Stake × 1 5. -
Page 9: Assembly
Dual Rotating Rear Tine Tiller Operator’s Manual » ASSEMblY This rear tine tiller was partially assembled at the factory. To assemble your machine follow the below instructions. OPERATION HANDLE The M8×75 bolts and nuts have been fixed in the guide bracket for Shift Lever Indicator shipping. -
Page 10: 1 | Introduction
DEPTH STAKE 6. Adjust the depth stake to the desired depth of tilling. (See Figure 5b) 1. Hold the machine leaning forward. (see Figure 5a, Illustration 1) 2. Pull the pin lever to unlock position. (see Figure 5a, Illustration 2) Limiter 3. -
Page 11: Know Your Machine
Dual Rotating Rear Tine Tiller Operator’s Manual » KnOW YOUR MACHInE FEATURES AND CONTROLS Throttle Control Shift Lever Drive Control Bar Operation Handle Handle Height Adjustment Drag Bar Depth Stake Outer Side Shield Tines Leveling Shield Recoil Starter Handle Throttle Control Choke Control Fuel Shut-Off Valve Know Your Machine... - Page 12 SHIFT LEVER DRIVE CONTROL BAR Used to engage tines and/or traction drive. The shift lever has 5 positions: 3 for transport only (no tine rotation) and 2 for operating the tines in forward (F) or reverse (R): . HANDLE HEIGHT ADJUSTMENT LEVER Unscrew this lever, move the handle up or down.
-
Page 13: Operation
Dual Rotating Rear Tine Tiller Operator’s Manual » OPERATION ADD OIL TO ENGINE IMPORTANT: DO NOT OVERFILL! This equipment and/or its engine may include The engine is shipped without oil. Do not start the evaporative emissions control system components, engine before adding oil. Refer to your engine manual required to meet EPA and/or CARB regulations, that for the proper oil gauge to use. - Page 14 Limiter 3. Move the throttle control Transport Position lever slightly forward to about ¼ of the way (slightly toward Depth Stake Pin Lever the fast position). Shallowest Tilling Throttle Control Lever Deepest Tilling 4. Pull the recoil starter until the engine starts. Return the recoil to the home position after each pull.
- Page 15 Dual Rotating Rear Tine Tiller Operator’s Manual » The type of soil and working conditions will determine the actual up for increasing tilling depth. Place depth stake pin in the hole setting of the tilling depth. In some soils, the desired depth is of the depth stake to lock in position at desired depth.
-
Page 16: Maintenance
1. Move the throttle lever to the SlOW ( ) position. MAInTEnAnCE ADJUSTING CLUTCH Maintaining your YARDMAX rear tine tiller will ensure long life to the machine and its components. If clutch becomes difficult to engage follow these steps to adjust the cable tension. - Page 17 Dual Rotating Rear Tine Tiller Operator’s Manual » REPLACING THE TINES 5. To install a new belt, repeat the above process in reverse. 1. Remove the outer side shield. 2. Remove the whole blade assembly. Swing Nut (×4) Outer Side Shield (×2) Figure 12a Figure 11a...
-
Page 18: Storage
ENGINE MAINTENANCE For information on engine maintenance, refer to the Engine Manual included with your unit. Your engine manual provides detailed information and a maintenance schedule for performing maintenance tasks. STORAGE If the rear tine tiller will not be used for a period longer than 30 Do not use strong detergents or petroleum based days, follow the steps below to prepare your unit for storage. - Page 19 Dual Rotating Rear Tine Tiller Operator’s Manual » Problem Cause Remedy 1. Spark plug wire is loose 1. Connect and tighten spark plug wire 2. Unit running with Choke lever in 2. Move choke lever to OPEn position ClOSE position 3.
-
Page 20: Parts Diagram
PARTS DIAGRAM Parts Diagram YT4565PM02 - 1704... - Page 21 Dual Rotating Rear Tine Tiller Operator’s Manual » Parts Diagram YT4565PM02 - 1704...
-
Page 22: Parts List
PARTS LIST Description Description Description Gear Box Assembly 38 Shaft 2 75 bolt M6×16 blot M8×20 39 Wear-Resisting Gasket 5 76 Engine Flat Washer 8 40 Flat Washer 12 77 Pulley Gear Box Case Weldment (L) 1 41 Spring Washer 10 78 Key b5×4.76×40 Rubber Gasket 42 nut M10... -
Page 23: Yt4565Pm02
Dual Rotating Rear Tine Tiller Operator’s Manual » Description Description Description 112 bending Joint 130 Adjustable Side Shield 2 148 C-Clip 9 113 End Cap 25 131 bolt M10×25 149 Tensioner Pulley 114 Upper Handle Sleeve 132 Spacer 3 150 bushing 115 brake Connecting Plate 133 Screw M5×10 151 Wheel bracket Weldmen... - Page 24 Tame the Great Outdoors 1850 W Winchester Rd, Suite 106 Libertyville, IL 60048 844-YARDMAX info@yardmax.com (844-927-3629)
Need help?
Do you have a question about the YT4565 and is the answer not in the manual?
Questions and answers
where do i put gear oil in tiller
The gearbox of the YARDMAX YT4565 tiller was filled with lubricant at the factory, and additional lubricant is not required unless there is evidence of leakage or service has been performed. If needed, gear oil should be added to the gearbox.
