Page 3
Attaching Jabra Triton to your desk phone Loosen the screws...
Page 4
XXXXXXXX. Slide the attachment fully open, and retighten the screws. XXXXXXXX. Attach the dock to the back of the phone. XXXXXXXX. Insert the screw and tighten it.
Assembling the headset 1. Align the headset and the headband attachment, as illustrated, and press firmly together until they click into place (snap-to-click). 2. Rotate the microphone boom arm for left or right ear use. 3. Adjust the length of the headband for the optimal fit. CLICK Charging the headset Dock the headset in the base.
Using the headset Answer/end buttton Speaker volume up Mute Speaker volume down LED indicator Using the base LED Status Battery charging (slow flash) Full battery Medium battery Low battery Very low battery (fast flash) Microphone muted Active audio link between headset and base Searching for headset...
Page 7
Loosen the screws Slide the attachment and retighten...
Page 8
Attach the dock Insert the screw and tighten...
