MV2 42 CDMA 1xEV-DO Rev. A USB Modem CDMA 1xEV-DO Rev. A USB Modem MV242 User Manual Axesstel Inc.
Page 2
CDMA 1xEVDO Rev. A USB Modem User Manual Thank you for choosing Axesstel EVDO wireless network USB modem. No matter where you are, this product can meet your multiple requirements at any time, such as surfing on line with high-bit-rate, sending and receiving short message, phonebook management, and voice.
Page 3
CDMA 1xEVDO Rev. A USB Modem User Manual loss may occur, we will not undertake the responsibility and the indemnity for damage. Axesstel Inc.
Page 4
CDMA 1xEVDO Rev. A USB Modem User Manual Contents Overview ......................1 Software Installation and Uninstallation ............. 2 Installing the Software ..............2 Uninstalling the Software ..............2 Description of Terminal GUI ................2 Logging In to the Terminal .............. 2 GUI Introduction ................
Page 5
CDMA 1xEVDO Rev. A USB Modem User Manual Copying Phonebook Records to Local or (U) SIM Card ....8 Searching a Contact ............... 8 Phone ........................ 9 Phone Management Interface ............9 Outgoing calls ................. 9 Incoming calls ................10 Setting......................
Page 6
CDMA 1xEVDO Rev. A USB Modem User Manual 13.2 RF Exposure Information (SAR) ........... 19...
EVDO USB Modem User Manual 1 Overview The wireless network USB modem is a high-bit-rate data card, which is applicable to network connection applications of CDMA 1xEV-DO Rev. A, and backward compatible to CDMA 1 xEV-DO Rev.0 and CDMA 1x. This wireless network card provides the following functions: ...
EVDO USB Modem User Manual 2 Software Installation and Uninstallation 2.1 Installing the Software Software installation is “Plug and Play”. Please follow the on-screen instructions to finish the software installation. To install the software, do as follows: Step1 Insert the wireless network card into the USB interface, and the following page for selecting languages automatically appears.
EVDO USB Modem User Manual When you are required to enter the Personal Identification Number (PIN) code, enter the correct PIN and click OK. If you fail to enter the correct PIN or PIN Unblocking Key (PUK) code, the network-related functions would be unavailable.
EVDO USB Modem User Manual 4.2 Traffic Information You can use the statistical function to check the network traffic. To view the traffic information, do as follows: Step1 Click the traffic icon to display the traffic interface. Step2 View the current connection information: You can view the duration of the current connection, uploaded/downloaded speed and data of the current connection.
EVDO USB Modem User Manual Click the Send to button to display the interface for selecting phone numbers. You can select a contact or press the Ctrl key or the Shift key to select multiple contacts in the phonebook list, and then click the OK button. Click the Send button to send the message.
EVDO USB Modem User Manual Step2 Edit the message content, and then click the Save button or the Send button. 5.6 Deleting a Message To delete a message, do as follows: Step1 Select a message in the message list, or press the Ctrl key or the Shift key to select multiple messages.
EVDO USB Modem User Manual in the searched group are displayed. No result is displayed when no matched message is found. 6 Phonebook You can manage contacts in the phonebook conveniently with the terminal. 6.1 Phonebook Management Interface Click the phonebook icon to display the phonebook management interface.
EVDO USB Modem User Manual content. 6.4 Deleting a Contact To delete a contact, do as follows: Step1 In the phonebook list, select a contact or press the Ctrl key or the Shift key to select multiple contact records. Step2 Click the Delete button in the shortcut menu bar.
EVDO USB Modem User Manual To search a contact, do as follows: Step1 Click Step2 Enter the key words of phonebook in the blank field of the shortcut menu bar. Phone 7.1 Phone Management Interface In the main interface, you can click to open the telephone management interface.
EVDO USB Modem User Manual 7.3 Incoming calls When there is an incoming call, If the telephone visual prompt function has been set up, the pop box as below will appear in the lower right corner, then click “Answer” or in the interface to answer the call, and click “Hang up”...
EVDO USB Modem User Manual Choose Tools > PIN Manage to select Enable/Disable PIN in the drop-down list. To enable or disable PIN code, do as follows: Step1 Enter the correct PIN code. Step2 After clicking the OK button, it will remind you to enable or disable PIN code.
EVDO USB Modem User Manual Step2 Enter the correct PUK code. Step3 Enter the new PIN. Step4 Click the OK button. The (U) SIM card is unlocked and the PIN is changed. 8.6 Options Choose Tools > Option to set other parameters. ...
EVDO USB Modem User Manual Step2 Click the Delete button and confirm the deletion operation. Setting the Default Profile Step1 Select a profile in the list. Step2 Click the Set as default button to set the selected profile to be the default one.
EVDO USB Modem User Manual 10 Mac OS X Installation 10.1 Installing the Application Connect the data card to your PC, and then system automatically displays the corresponding CD. After opening the CD, double-click the application, and follow the on-screen instructions to finish the installation. Step1 Click the Continue button in the welcome page.
EVDO USB Modem User Manual 11 Function Fields and Operation Introduction of Mac OS X 11.1 GUI Introduction The application interface of Mac PC includes function button field, and system information field. You can realize the corresponding function in the corresponding field.
EVDO USB Modem User Manual If Modem connects to the Internet, you can view the Web pages. Internet If you want to connect to the Internet, do as follows: Step1 Click the Internet icon. Step2 In order to connect modem to the Internet correctly, you had better configure the user network information first.
EVDO USB Modem User Manual Dial Record Click the Dial Record icon to display the Dial Record page. In this page, you can view the related information about user operation, such as ConnectName, StartingTime, DisconnectTime, Duration, Data Transport, and Data Receive. 11.3 Settings 11.3.1...
Page 24
EVDO USB Modem User Manual This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. This USB Dongle complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired...
Page 25
EVDO USB Modem User Manual -Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Page 26
EVDO USB Modem User Manual The highest SAR value for the device as reported to the FCC when tested for body, as described in this user guide, is 0.349 W/kg for CDMA2000 BC0 band , 0.788 W/kg for CDMA2000 BC1 band. While there may be differences between the SAR levels of various USB Dongles and at various positions, they all meet the government requirement.
Page 27
EVDO USB Modem User Manual not be collocated or operating in conjunction with any other antenna or transmitter.
