- Page 1 RovoRx UltraHD HDBaseT Receiver Installation and Operation Guide Version 1.0r1 Published June 9, 2017...
-
Page 2: Notices
AJA® and Because it matters.® are registered trademarks of AJA Video Systems, Inc. for use with most AJA products. AJA™ is a trademark of AJA Video Systems, Inc. for use with recorder, router, software and camera products. Because it matters.™ is a trademark of AJA Video Systems, Inc. - Page 3 Copyright ..........2 Contacting AJA Support ........2 Chapter 1 –...
-
Page 4: Chapter 1 – Rovorx Introduction
RovoRx-SDI includes a frame sync function which supports using a RovoCam camera feed in a video production environment. RovoRx-HDMI and RovoRx-SDI can also be used with any compatible HDBaseT transmitter, not just RovoCam. NOTE: The HDBaseT format uses RJ-45 connectors but does not support Ethernet. - Page 5 HDBaseT (Video, Audio, Power, RS-232 Control) Computer with HDMI VISCA Control App RS-232 RovoRx-HDMI Audio Out (Left Right Analog) RovoCam can receive power from the RovoRx over a Cat5e/6 cable (Figure 1), or powered locally using its 12VDC connector (Figure Figure 2.
-
Page 6: Pairing Rovorx With Hb-T Transmitters
HDBaseT transmitters. Examples include AJA’s HB-T-HDMI and HB-T- SDI model Mini-Converters. An AJA RovoRx device may work with other HDbaseT sources, although it was primarily designed to receive signals from RovoCam. This manual focuses only on using RovoRx with RovoCam. -
Page 7: Features
• 48VDC power supply with AC cable • (RovoRx-SDI only) standard USB to USB micro cable In addition the following item is available from AJA as part of the HB-CABLE-KIT: • 3.5mm TRS to DB9 adapter cable NOTE: This cable is also widely available for purchase from other sources. -
Page 8: In This Manual
In This Manual Chapter 1 - Introduces the RovoCam system, briefly describing the components, features, box contents, and system requirements. Chapter 2 - Describes the RovoRx-HDMI hardware, connections, and system installation. Chapter 3 - Describes the RovoRx-SDI I hardware, connections, system installation, and configuration using Mini-Config. -
Page 9: Chapter 2 – Rovorx-Hdmi Receiver
The simple and economical RovoRx-HDMI is designed to pair with the AJA RovoCam camera, to provide video, audio, control and power transmission using a single CAT cable. RovoRx-HDMI can also be used with any compatible HDBaseT transmitter, including AJA’s HB-T-HDMI and HB-T-SDI Mini-Converters. -
Page 10: Rovorx-Hdmi I/O Connections
2. Connect the RovoCam HDBaseT RJ-45 output to the HDBaseT RJ-45 input connector with an approved CAT cable type and length. 3. Connect the RovoRx-HDMI output to the HDMI input of a destination device (in this example, an HDMI monitor) with an HDMI cable. -
Page 11: Rovorx-Hdmi Rack Mounting
This will effectively tie the camera to earth ground and eliminate the unwanted noise. RovoRx-HDMI Rack Mounting The RovoRx-HDMI can be mounted to a rack using AJA's optional RMB bracket. The threaded holes in the case can also be used for mounting without the bracket, using 1/4 inch 440 thread screws. -
Page 12: Chapter 3 – Rovorx-Sdi And Mini-Config
RovoCam signal to a facility reference for use in a production facility. RovoRX-SDI is designed to pair with the AJA RovoCam camera, to provide video, audio, RS-232 control and power transmission using a single CAT cable. Video and audio can be received by this device over distances up to 328 feet/ 100 meters on Cat 6a cable, to drive displays or ingest into an SDI production environment. -
Page 13: Rovorx-Sdi Block Diagram
Input Left Analog Audio RCA Output Power LED NOTE: The LINK LED, when green, indicates an active HDBaseT connection. NOTE: The LOCK LED, when blinking green, indicates a lock to a valid video source. RovoRx UltraHD HDBaseT Receiver v1.0r1 www.aja.com... -
Page 14: System Installation
8. Install and configure RovoControl (or a third-party control application) for operation with the RovoCam system. 9. For advanced features (for example, DA output) and specific SDI output configuration, download and install AJA’s Mini-Config application onto a PC or Mac (see "USB Control and Setup—Using AJA Mini-Config" on page... -
Page 15: Rovorx-Sdi Rack Mounting
RovoRx-SDI Rack Mounting The RovoRx-SDI is too large to be mounted into AJA's DRM frame, and the location of the unit's threaded holes are incompatible with AJA's RMB bracket. The threaded holes in the case of the RovoRx-SDI can be used for mounting, using 1/4 inch 440 thread screws. -
Page 16: Installing Aja Mini-Config
To download the latest AJA Mini-Config package, which includes the AJA Mini- Config application, Mini-Converter firmware, and documentation, go to: https://www.aja.com/en/products/mini-converters/mini-config-software Select either the Windows or Mac icon to download the desired version. Mini-Converter Documentation Included with the AJA Mini-Config package is a complete set of documentation for all Mini-Converters supported by AJA Mini-Config. - Page 17 AJA Mini-Config application in the AJA folder in the Programs listing. NOTE: If the AJA Mini-Config application already exists on the PC, a different Setup Wizard appears. Figure 6. AJA Mini-Config Setup Wizard, Reinstallation...
-
Page 18: Running Aja Mini-Config
PC Startup To run AJA Mini-Config on a PC, double-click on the AJA Mini-Config icon on your desktop, or open the AJA folder in the program list and click on the AJA Mini- Config application located inside the AJA Mini-Config folder. - Page 19 You can choose which Mini-Converter you wish to control using the pulldown menu in the upper right hand corner. If you want to configure multiple Mini- Converters in parallel, you can do it by running multiple instances of the AJA Mini-Config application and have each control a different Mini-Converter.
-
Page 20: Tabbed Screens
Mini-Converter type. When you Click on any of the tab buttons, the pane below the tabs will change to match your tab selection. Any changes you make are immediately applied and will be saved, overwriting previous settings. RovoRx UltraHD HDBaseT Receiver v1.0r1 www.aja.com... -
Page 21: Input Tab Screen
Click on the Input tab to view and make changes to the converter’s input settings. Color Range Selects the Input Video Color Range for RGB signals. Choose from: • Auto (default) • SMPTE • Full RovoRx UltraHD HDBaseT Receiver v1.0r1 www.aja.com... -
Page 22: Output Tab Screen
• HDBaseT Input (default) - Locks to incoming clock. • Ext.Reference - Locks to incoming reference signal.. Mapping Select the UltraHD mapping format: • Quadrant - Square Division • 2SI - Two Sample Interleave RovoRx UltraHD HDBaseT Receiver v1.0r1 www.aja.com... - Page 23 UltraHD LFR video format, and Single 6.0 Gbps is selected here, four 3G signals are required for that bandwidth so all four BNC outputs must be used for that one signal. In this case the DA Function will be disabled. RovoRx UltraHD HDBaseT Receiver v1.0r1 www.aja.com...
-
Page 24: Audio Tab Screen
SDI Out 2, 3, and 4 BNCs. • Suppress - Turns the audio off on the SDI output. Mute Channels 1/2 When checked, mutes the SDI outputs (silent audio is output). RovoRx UltraHD HDBaseT Receiver v1.0r1 www.aja.com... -
Page 25: Update Tab Screen
This indicator bar shows the progress of firmware installation. Software Update Procedure 1. Check the AJA website for new Mini-Config software for your Mini- Converter. If new software is found, download it and uncompress the file archive (zip). Here is the URL to use when checking: http://www.aja.com/en/products/mini-converters/mini-config-software... -
Page 26: Info Tab Screen
Info Tab Screen This screen provides basic information about the Mini-Converter. This information is mostly useful when calling AJA Support for service or technical support. Name This field allows you to give your Mini-Converter a name. This can be useful if you have several Mini-Converters attached to a Mac/PC via USB so you can distinguish between them easily (especially if they’re the same model). -
Page 27: Appendix A – Specifications
Appendix A – Specifications RovoRx-HDMI Tech Spec Video Formats • (UltraHD) 3840 x 2160p 25, 29.97 • (HD) 1080p 50, 59.94 • (HD) 1080i 25, 29.97 • (HD) 720p 50, 59.94 • (SD) 625i • (SD) 525i Video Input • HDBaseT (RJ-45) Video Output •... -
Page 28: Rovorx-Sdi Tech Specs
• 4.03” x 5.2” x 0.94” (102.4mm x 132mm x 23.9mm) Weight • 0.7 lbs (0.4kg) Power • RovoRx-HDMI only: 48V @ 125mA = 6W typical, 48V @ 156mA = 7.5W max • RovoRx-HDMI powering RovoCam: 48V @ 271mA = 13W typical, 48V @ 312mA = 15W max Environment •... - Page 29 RS-232 • 1 x 3.5mm TRS Input for RS-232 bidirectional signals USB Config • 1 x USB for configuration with AJA Mini-Config Size (w x d x h) • 4.66” x 6.97” x 0.94” (118mm x 177mm x 23.9mm) Weight •...
- Page 30 8-bit RS-232 Cable Option The RS-232 pinout diagram provided below pertains to the AJA cable bundle provided as an optional purchase. This chart depicts the complete RS-232 pinout specification. As noted, only three connections are commonly used today and are supported in the AJA cable option.
-
Page 31: Appendix B – Safety And Compliance
Community throughout this document: AUSTRIA, BELGIUM, BULGARIA, CYPRUS, CZECH REPUBLIC, DENMARK, ESTONIA, FINLAND, FRANCE, GERMANY, GREECE, HUNGARY, IRELAND, ITALY, LATVIA, LITHUANIA, LUXEMBOURG, MALTA, NETHERLANDS, POLAND, PORTUGAL, ROMANIA, SLOVAKIA, SLOVENIA, SPAIN, SWEDEN, UNITED KINGDOM, ICELAND, LICHTENSTEIN, NORWAY, SWITZERLAND RovoRx UltraHD HDBaseT Receiver v1.0r1 www.aja.com... -
Page 32: Declaration Of Conformity
As an electromagnetic wave equipment for office use (Class A), (Broadcasting Communication this equipment is intended to use in other than home area. Equipment for Office Use) Sellers or users need to take note of this. RovoRx UltraHD HDBaseT Receiver v1.0r1 www.aja.com... - Page 33 Aviso! Leia e siga todos os avisos e instruções assinalados no produto ou incluídos na documentação. Avviso! Leggere e seguire tutti gli avvisi e le istruzioni presenti sul prodotto o inclusi nella documentazione. RovoRx UltraHD HDBaseT Receiver v1.0r1 www.aja.com...
- Page 34 Aviso! Desconecte este dispositivo da tomada durante trovoadas ou quando não é utilizado durante longos períodos de tempo. Avviso! Utilizzare soltanto i collegamenti e gli accessori specificati e/o venduti dal produttore, quali il treppiedi e l'esoscheletro. RovoRx UltraHD HDBaseT Receiver v1.0r1 www.aja.com...
- Page 35 Advertência! Não abra o chassi. Não há internamente nenhuma peça que permita manutenção pelo usuário. Abrir o chassi anula a garantia, a menos que a abertura seja realizada por uma central de serviços da AJA ou por um local autorizado. Avvertenza! Non aprire lo chassis. All’interno non ci sono parti riparabili dall’utente.
- Page 36 Avviso! Proteggere il cavo di alimentazione in modo che nessuno ci cammini sopra e che non venga schiacciato soprattutto in corrispondenza delle spine e del punto in cui esce dal dispositivo. RovoRx UltraHD HDBaseT Receiver v1.0r1 www.aja.com...
-
Page 37: Warranty Information
Video parts or supplies, or d) to service a product that has been modified or integrated with other products when the effect of such a modification or integration increases the time or difficulty of servicing the product. -
Page 38: Index
Enable PtoPsF 23 Pairing with HB-T Transmitter 6 RovoRx-HDMI Features 9 RovoRx-HDMI Installation Features with RovoCam 10 RovoRx-HDMI 9 RovoRx-HDMI I/O Connections 10 RovoRx-HDMI Overview 9 RovoRx-HDMI Rack Mounting 11 RovoRx-SDI Installation Genlock 22 with RovoCam 14 RovoRx-SDI I/O Connections...
