OWNER'S MANUAL & INSTALLATION GUIDE
TITAN-Ox™ Arsenic and Heavy Metal Reduction Filters
highly effective and economical treatment for the removal of arsenic,
uranium, lead, and other heavy metals!
APPLICABLE MODELS: TOx-5810XTR2 Series
PLEASE READ THIS MANUAL CAREFULLY BEFORE
ATTEMPTING INSTALLATION. FAILURE TO FOLLOW THESE
INSTRUCTIONS MAY AFFECT THE PERFORMANCE OF YOUR
SYSTEM, VOID YOUR WARRANTY, AND RESULT IN
PROPERTY DAMAGE.
Advertisement
Table of Contents
Related Manuals for Titan TOx-5810XTR2-10-54
Summary of Contents for Titan TOx-5810XTR2-10-54
- Page 1 OWNER’S MANUAL & INSTALLATION GUIDE TITAN-Ox™ Arsenic and Heavy Metal Reduction Filters highly effective and economical treatment for the removal of arsenic, uranium, lead, and other heavy metals! APPLICABLE MODELS: TOx-5810XTR2 Series PLEASE READ THIS MANUAL CAREFULLY BEFORE ATTEMPTING INSTALLATION. FAILURE TO FOLLOW THESE...
- Page 2 The brain of your TITAN-Ox™ system is the Fleck 5810XTR2 control valve. It is manufactured by one of the world’s premier water treatment companies. The Fleck 5810 control valve is well respected for its reliability, serviceability, simple operation, and value.
- Page 3 Table of Contents: GENERAL WARNINGS ……………………………………………………………………………………………...….. …….. OPERATING CONDITIONS …………………………………………………………………………………………….…... INSTALLATION ………………………………………………………………………………………………………….…..…..….. Step 1 – Pre-Installation Inspection ……………………………………………………………..……… Step 2 – Selecting an Installation Location ………………………………………………..…..Step 3 – Prepare Treatment Tank ………………………………………………………………..……… Step 4 – Turn off the Water & Electric Water Heaters ………………………………….… Step 5 –...
-
Page 4: General Warnings
GENERAL WARNINGS Do not allow children or pets to play on or around the water filter. Do not install or store this filter system where it will be exposed to freezing temperatures. Do not tamper with controls. Do not repair, replace, or attempt to service any part of the system unless specifically instructed to in this manual and you have the understanding, tools, and skills necessary to carry out the procedure. -
Page 5: Operating Conditions
8.3. If pH exceeds this level, pH correction should be undertaken prior to the TITAN-Ox™ system. Elevated levels of silica and/or sulfate may reduce media life depending on other water chemistry conditions (particularly if the water is soft). - Page 6 * While the TITAN-Ox™ system is built to withstand pressures exceeding 90 PSI, if your water pressure is greater than 70 PSI, we recommend that you have a certified plumber install a pressure reducing valve ahead of the TITAN-Ox™ system.
-
Page 7: Installation
INSTALLATION WE RECOMMEND THAT YOU READ THIS ENTIRE MANUAL BEFORE STARTING THE ACTUAL INSTALLATION. WHILE WE STRONGLY RECOMMEND THAT A LICENSED PLUMBER PERFORM ALL INSTALLATION WORK, A MECHANICALLY-INCLINED HOMEOWNER WITH SUITABLE PLUMBING KNOWLEDGE CAN INSTALL THIS SYSTEM. IN ALL CASES, IT IS CRITICAL THAT THE INSTALLATION BE DONE IN ACCORDANCE WITH THESE INSTRUCTIONS AND ALL APPLICABLE PLUMBING AND ELECTRICAL CODES. -
Page 8: Step 2 – Selecting An Installation Location
Step 2. – Selecting an Installation Location While exterior installation in warm climate areas is possible, we strongly recommend interior installation only. The system cannot be allowed to freeze or severe system damage could occur. The system should not be exposed to rain and it should not be installed in direct sunlight, as long-term exposure to UV light could damage components of the system. -
Page 9: Step 3 – Prepare Treatment Tank
UL/CSA certified and of an appropriate wire gauge for the application. Step 3. – Prepare Treatment Tank Two types of media are supplied with your TITAN-Ox™ system: gravel which forms the base layer (underbedding) in your treatment tank, and a specialized water treatment media called MetSorb. - Page 10 flush or protruding above the top of the tank, the distributor tube is not nested correctly in the recess at the bottom of the tank. Add enough water to the tank to cover the lower distributor with a minimum of 6 inches of water.
- Page 11 Once this is complete, add the MetSorb media in the same manner. Use all of the media provided. Depending on the capacity of the system, there will only be enough media to fill the tank to about 1/2 to 3/4 full. This is normal. The media tank should never be filled to the top of the tank as the remaining space, known as the “freeboard,”...
-
Page 12: Step 4 – Turn Off The Water & Electric Water Heaters
for leverage and do not use tools. A firm grasp with both hands at the base of the valve will work. Do NOT use pipe cement (“pipe dope”) or Teflon® tape on the threads. Step 4. – Turn off the Water & Electric Water Heaters FAILURE TO FOLLOW THIS PROCEDURE COULD RESULT IN SERIOUS, PERMANENT DAMAGE TO THE HEATING ELEMENTS IN YOUR WATER HEATER. - Page 13 Key Control Valve Components: 1. Control Valve Body 2. Bypass Valve 3. 1” NPT (Male) Connector Yokes 4. Drain Line Flow Control (DLFC) 5. Valve Cover 6. DLFC Retention Clip 7. Flow Restrictor TEFLON® TAPE IS THE ONLY SEALANT TO BE USED ON THE 1”...
- Page 14 the piping connections and relieves stress on the valve. The 1” NPT connector yokes are connected to the bypass in the same manner (they are normally shipped to you pre- connected to the bypass, but you can separate them to make the plumbing to your main water lines easier if you want).
-
Page 15: Step 6 – Drain Line Installation
LOCAL CODES. THE DRAIN LINE SHOULD NOT BE EXPOSED TO FREEZING TEMPERATURES. During the backwash cycle, your TITAN-Ox™ will send captured contaminants out the drain port. This port needs to be connected to a suitable household drain, ideally within 20 feet of your media tank. -
Page 16: Step 7 – Control Valve Set-Up
MINIMUM Drain Line Diameter: Model 40F Water Temp 70F Water Temp TOx-5810XTR2-10-54 1/2" 1/2" TOx-5810XTR2-12-52 1/2" 3/4" TOx-5810XTR2-13-54 3/4" 3/4" TOx-5810XTR2-14-65 3/4" 3/4" Polyethylene tubing, PEX, PVC, CPVC, or copper pipe are all acceptable material choices for the drain line. If you are using flexible tubing, be sure that there are no “kinks” or “crimps” in the tubing after installation that may cause a flow restriction. - Page 17 and of an appropriate wire gauge for the application. Plug the other end of the power cord into the electrical port on the control valve. Note: The electrical port on the control valve is located on the right side of the valve (when you are facing the control panel), just behind the tab used to remove the valve cover.
- Page 18 In the middle of the screen is the regeneration cycle wheel which indicates the current valve cycle (indicated in green), and other applicable cycles (in black). The bottom menu bar provides the following options: Vacation: Select this icon to set your water filter system to vacation mode. This mode can be used if you will be away for an extended period of time and will not be using water.
- Page 19 To cancel your changes and return to the home screen, press the “X” icon at any time. Your TITAN-Ox™ has been pre-programmed to backwash every 10 days or 3,000 gallons (whichever occurs first) and to perform the backwash process at 12:30am in the morning when it is very unlikely that water will be required in the building.
-
Page 20: Step 8 – Initial Start-Up And Leak Testing
Step 8 – Initial Start-up and Leak Testing Ensure that the bypass is in the bypass position. Turn on the main water supply. Open a cold water tap nearby and let the water run for a few minutes or until the system is free of foreign material (usually solder) and air that may have resulted from the installation. -
Page 21: Performance Monitoring
When the system returns to service mode, slowly open a nearby cold water tap (after the TITAN-Ox™ system) and let the water run for 5 to 10 minutes until the system is purged of all air that may have resulted from the installation, and the water is running clear. Repeat for other faucets in the building starting at the highest elevation and working down to the lowest point until all air is purged. -
Page 22: Backwash
Test 2: 25 days after installation Test 3: 50 days after installation Test at least every 2 to 3 months thereafter. Increase your testing frequency to monthly if contaminant levels begin to approach the maximum levels permitted by the U.S. EPA or Health Canada. - Page 23 Step 2: Rapid Rinse: factory pre-set for 3 minutes Unless directed by a water treatment professional familiar with this system, we do not generally recommend that you alter the duration of any cycles, however, you can adjust the duration of both cycles based on your water conditions through the Master Settings Mode (see below).
-
Page 24: Changing Time Of Day
CHANGING TIME OF DAY The current day of the week and time is displayed in the top left corner of the home screen. It is important that the day and time be accurate so that the flush cycle(s) will occur at the correct time of the day and so that the diagnostic and data gathering functions of the control valve will be accurate. -
Page 25: Changing Basic Settings
CHANGING BASIC SETTINGS The Settings Mode allows you to set the frequency of the back flush and the time of day that the flush cycles will take place. You can also adjust the brightness of the touch screen display. To enter the Settings Mode, touch the SETTINGS ICON in the main menu at the bottom of the home screen. -
Page 26: Diagnostics
decrease the brightness to suit your preferences. Each time you press one of the blue arrows, the screen brightness will change accordingly. When you are satisfied with the brightness level, press the CHECKMARK ICON in the bottom right corner of the screen. To cancel your changes and return to the home screen, press the “X”... -
Page 27: Master Settings Mode
Totalizer: This is the total volume of water in gallons (U.S.) that have been treated by the system since the totalizer meter was last reset. To reset the totalizer meter, touch “totalizer” and then select the icon in the bottom right corner of the next screen. The totalizer meter will be reset to zero. - Page 28 FORMAT Parameter Setting language english units hardness units VALVE Parameter Setting system valve 5810 regen. type filter mtr. delayed day override / time driven regen. time 12:30 am vol override / volumetric 3000 G REGEN. Parameter Setting regen flow filter step # 1 backwash time 1...
-
Page 29: Operation During A Power Failure
backwash draw tank refill pause METER Parameter Setting meter type 1.25” turbine generic plumbing leak detect OPERATION DURING A POWER FAILURE The 5810XTR2 valve/controller includes integral power backup. In the event of power failure, the control shifts into a power-saving mode. The display and motor shut down, but it continues to keep track of the time and day for a minimum of 48 hours. -
Page 30: Maintenance & Troubleshooting
THE DRAIN LINE PLUMBING CONFIGURATION SHOULD INCLUDE ALL REQUIRED SAFETY COMPONENTS TO PREVENT OVERFLOWS RESULTING FROM A POWER FAILURE DURING REGENERATION. MAINTENANCE & TROUBLESHOOTING THE CONTROLLER MUST BE DEPRESSURIZED BEFORE REMOVING ANY QUICK CONNECTION CLIPS OR THE VALVE ITSELF FOR SERVICING. THE CONNECTOR SHOULD BE PUSHED TOWARD THE CONTROL VALVE WHILE REMOVING CLIPS. -
Page 31: Warranty Information
WARRANTY INFORMATION TITAN-Ox™ systems are backed by a comprehensive warranty program. The Fleck 5810XTR2 control valve and related bypass assembly and media tank are manufactured by Pentair LLC and are subject to Pentair LLC’s Limited Warranty. See Pentair’s Limited Warranty for details. - Page 32 Subject to the limitations noted below, all other components of the TITAN-Ox™ system are warranted by HomePlus Products Inc. to be free of defects in material and workmanship for a period of 1 year except as noted**. **Note: Due to the wide variety of potential feed water conditions, there is no warranty on the MetSorb media or underbed gravel.
- Page 33 storage; incorrect supply of water; tampering or alteration; fire, freezing; act of God; or any cause beyond the control of HomePlus Products Inc. The original warranty period does not change in the event of part replacement by HomePlus Products Inc. This warranty is issued exclusively to the original consumer purchaser of record so long as the product remains installed in the original location of installation, and is not transferable.
- Page 34 MANUFACTURED BY: HomePlus Products Inc. 5-1490 Pearson Place Kamloops, BC V1S 1J9 Canada Phone: 250-374-2690 Fax: 250-374-2692 www.homeplusproducts.com...
