HPM D817/2DP Instruction Manual

1 Specifications
Supply voltage
240V a.c. 50Hz
2

Please Read Carefully

• Read through these instructions completely before setting/using the timer. Retain for future use.
• When you first receive the timer, it will be in sleep mode. The LCD screen will display 12:00.
• To exit sleep mode, press any button (except the RESET button).
• If the LCD screen is blank, the battery may be flat. To recharge, plug the timer into a power source. Refer to section 11 for more
information on the battery.
3

Time Display

To change from 12-hour display to 24-hour display, or vice versa, press the CLOCK button and hold it until the LCD display changes.
Please note that you can reset this digital timer at any stage by pressing the RESET button.
4

Setting the Day and Time

Step 1: Press and hold the SET button until the day shown on the LCD flashes.
Step 2: Use the and buttons to select the day of the week. When correct, press SET to confirm the selection. The hour figure on the
display will flash.
Step 3: Use and to select the correct hour. Press SET to confirm your selection, and the minutes figure will flash.
Step 4: Use the and to set the minutes. Press SET to finish setting the time.
Step 5: The clock can be reset at any time by repeating steps 1 - 4. When setting the clock remember to use standard time. See Daylight
Saving (Summer Time) section for details on easily switching between daylight savings (summer) time and standard time.
AM
LCD Display
ON
OFF
CLOCK Button
CLOCK
DELAY Button
S
SET Button
SET
Button
S
Summer Time
Switching Current
10A max
M T W T F S S
O U E H R A U
ON AUTO OFF
DELAY RND MODE
RND Button
MODE Button
RESET Button
RESET
Button
Red
LED Light
Socket
& Plug
Maximum Load
2400W
7 Day Digital Timer
Cat. D817/2DP
Instruction Manual
Battery (built-in)
NiMH rechargeable
