Ozito EPP-750 Instruction Manual

Ozito EPP-750 Instruction Manual

Telescopic pole pruner 750w 200mm (8”)

Advertisement

TELESCOPIC
POLE PRUNER
750W 200MM (8")
INSTRUCTION MANUAL
SPECIFICATIONS
Power:
750W
Chain Speed:
11 meters/second
No Load Speed:
6,000/min
Max Cutting Width:
180mm
Guide Bar Length:
200mm (8")
Oil Tank Capacity:
60ml
Telescopic Range:
1.85 – 2.80m
Weight:
3.82kg
ozito.com.au
IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO
Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
WARRANTY
The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from the
original date of purchase and is intended for DIY (Do It Yourself)
use only. If a product is defective it will be replaced in accordance
with the terms of this warranty. Warranty excludes consumable
parts, for example: guide bar, chain and included accessories.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
WHAT'S IN THE BOX
Telescopic Pole Pruner
Chain
Guide Bar
Guide Bar Cover
Shoulder Strap
Additional Handle
EPP-750
0817

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EPP-750 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ozito EPP-750

  • Page 1 Weight: 3.82kg ozito.com.au Shoulder Strap Additional Handle EPP-750 WARRANTY IN ORDER TO MAKE A CLAIM UNDER THIS The benefits provided under this warranty are in addition to other rights and remedies which are available to you at law. WARRANTY YOU MUST RETURN THE PRODUCT...
  • Page 2 KNOW YOUR PRODUCT SETUP & PREPARATION TELESCOPIC 1. CHAIN & BAR POLE PRUNER 1. Chain 2. Guide bar 3. Chain sprocket cover WARNING!: ENSURE THE TOOL IS DISCONNECTED FROM THE POWER SUPPLY 4. Motor housing BEFORE ASSEMBLY. 5. Telescopic shaft lock 6.
  • Page 3 2. TENSIONING THE CHAIN 3. SAW CHAIN LUBRICATION WARNING! NEVER START WORK UNLESS THE CAUTION!: THE CHAIN HAS SHARP EDGES. FOR YOUR CHAIN AND BAR ARE LUBRICATED. OWN SAFETY, PLEASE USE WORK GLOVES. 1. Place the telescopic 1. Loosen the chain cover lock.
  • Page 4 4. HANDLE & CORD RETAINER 5. PREPARATION Fitting the additional handle Adjusting the telescope length 1. Remove the 4 screws from the additional handle, then separate the 1. Unlock the telescopic shaft lock. two halves. 2. Slide the handle loop over the rear handle past the shoulder strap attachment.
  • Page 5 Keep the bucking spikes touching the wood you are cutting. Due to the rotation of the chain, it will pull the pruner into the wood. When the bucking spikes are touching the wood, it will help prevent any sudden jerking or kick-back. EPP-750...
  • Page 6 APPLICATIONS 7. APPLICATIONS 8. SAWING TECHNIQUES Limbing Limbing is the process of removing the branches from a fallen tree. Check the direction in which a branch will bend before cutting it. Always cut on 60° the opposite side to the bending direction so that the guide bar is not pinched in the cut.
  • Page 7: Cleaning And Storage

    Chain Replacement: Reverse the guide bar every 8 working hours to ensure uniform wear. The chain can be purchased through Ozito spare parts or from your Check the guide rails frequently and if necessary remove burrs and local Bunnings Warehouse. The correct chain can be purchased by square up the rails using a flat file.
  • Page 8 Replace the extension lead if damaged Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New or defective.
