- Page 1 IPC Series FLAT PANEL DISPLAY Aluminium-Face Type (AC Wide,10.4"-TFT,Analog) FPD-M21VT-AC (AC Wide,12.1"-TFT,Analog) FPD-L21ST-AC (AC Wide,15.0"-TFT,Analog) FPD-H21XT-AC User’s Manual CONTEC CO.,LTD.
- Page 2 Ferrite Core fixed clamp Product guide (this sheet) Purchase user’s manual and individual connection cables as they are not bundled with this equipment. For more details on the latest information of user’s manual, refer to the CONTEC’s Web site. Ferrite core fixed clamp...
- Page 3 No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document.
- Page 4 Table of Contents Check Your Package..........................i Copyright ............................ii Trademarks ............................ii Table of Contents..........................iii INTRODUCTION About the Product ..........................1 Features ............................1 Customer Support ..........................2 Web Site............................2 Limited One-Year Warranty....................... 2 How to Obtain Service ........................2 Liability...............................
- Page 5 CONNECTION TO THE HOST COMPUTER Analog RGB Connection ........................23 Touch Panel Data Communications ....................24 POWER SUPPLY CONNECTION Power Supply Connector ........................25 SCREEN ADJUSTMENT AND A SETUP Menu Screen ............................. 27 Direct Key............................30 Memory of a Setting Value....................... 30 LED INDICATORS TOUCH PANEL USB Multi-Touch Panel ........................
-
Page 6: Introduction
This product is a panel-mounted, analog RGB input type flat panel display for use with host computers such as the CONTEC IPC series and SBCs (single board computers). Uses a high-intensity LCD with a wide viewing field and touch panel operation via either RS-232C or USB. -
Page 7: Customer Support
You can download updated driver software and differential files as well as sample programs available in several languages. Note! For product information Contact your retailer if you have any technical question about a CONTEC product or need its price, delivery time, or estimate information. Limited One-Year Warranty CONTEC Products are warranted by CONTEC CO., LTD. -
Page 8: Safety Information
Protect the touch panel against shock to prevent damage. CONTEC is not liable for a product that has been modified by the user. When the surface or frame of the touch panel has become dirty, wipe it with neutral detergent. Do not wipe the touch panel with thinner, alcohol, ammonia, or a strong chlorinated solvent. - Page 9 1. Introduction A characteristic of analog touch panels is that the detected position may vary due to changes in the ambient environment (temperature and humidity) and changes in resistance values over time. In such cases, the touch panel should be recalibrated and the calibration data updated. Regular maintenance is necessary for the backlight on the touch panel and the display for the longevity parts.
- Page 10 Connecting to a host with an existing touch panel function such as a CONTEC panel computer. This touch panel cannot be used with a touch panel mounted in the host computer. In this case, the touch panel function will be unavailable but screen display will still work normally.
- Page 11 1. Introduction FCC PART 15 Class A Notice (Excluding the FPD-H21XT-AC) NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in commercial environment.
-
Page 12: Specifications
2. Specifications 2. Specifications Function Specifications Table 2.1. Function Specifications Specification Item FPD-M21VT-AC FPD-L21ST-AC FPD-H21XT-AC Screen Assembly type Panel mounted Screen size 10.4 inches 12.1 inches 15 inches Number of pixels 800 x 600 dots 1024 x 768 dots 640 x 480 dots... -
Page 13: General Specifications
2. Specifications General Specifications Table 2.2. General Specifications Specification Item FPD-M21VT-AC FPD-L21ST-AC FPD-H21XT-AC Environment Operating 0 - 50ºC temperature Storage -10 - 60ºC temperature Operating humidity 10 - 90%RH (No condensation) Floating dust Normal Corrosive gas None AC line: 2 kV, Signal line: 1 kV... -
Page 14: Optical Display Specifications
2. Specifications Optical Display Specifications Table 2.3. Optical Display Specifications Specifications (25ºC Typ. Value) Item Condition FPD-M21VT-AC FPD-L21ST-AC FPD-H21XT-AC Visual angle φ= 180° 50deg 50deg 50deg (vertical) φ= 0° Display in 70deg 70deg 70deg CR ≥ 10 monochrome Visual angle φ= +90°... - Page 15 3. Outside Dimensions and Part Names ユーザーズマニュアル...
-
Page 16: Outside Dimensions And Part Names
CONTEC CO., LTD. MADE IN # # ## ## 2-M3 TAP (216.2) (Maximum tapping length : 5mm) [mm] Figure 3.1. Outside Dimensions of Main Unit (FPD-M21VT-AC) FPD-L21ST-AC 8-M4 TAP (Maximum tapping length : 5mm) CAUTION! ************* ******0.6N*m*** The screw bolting torque of attachment m ust be 0.6N-m*MAX*. - Page 17 3. Outside Dimensions and Part Names FPD-H21XT-AC CAUTION! ************* ******0.6N*m*** The screw bolting torque of attachme nt must be 0.6N-m*MAX*. 8-M4 TAP (Maximum tapping MODEL : XXXXXXXXXXXXXXXXXX length SERIAL No. : XXXXXXXXXXXXX IN PUT : XXXXXXXXXXXXXXXXXXXXXX : 5mm) MENU CO N TEC C O., LT D. MADE IN # ##### 2-M3 TAP (310)
-
Page 18: Part Names
3. Outside Dimensions and Part Names Part Names Screen & Touch panel Power LED MEN U Screen adjustment switch Right side Back Left side CAUTION! ************* ******0.6N*m*** The screw bolting torque of attachment must be 0.6N-m*MAX*. Power connector Analog RGB connector USB touch panel connector RS touch panel connector Backlight ON/OFF connector... -
Page 19: Analog Rgb Connector
3. Outside Dimensions and Part Names Analog RGB Connector Table 3.1. Analog RGB Connector Connector type 15 pin HD-SUB (FEMALE) Pin No. Signal name Pin No. Signal name N.C. GREEN BLUE N.C. N.C. DDC DATA HSYNC R-GND VSYNC G-GND DDC CLK B-GND RS Touch Panel Connector This connector is RS-232C compliant to be used for touch panel data communication with the host... -
Page 20: Usb Touch Panel Connector
3. Outside Dimensions and Part Names USB Touch Panel Connector The USB connector for communication between the host computer and touch panel. Table 3.3. USB Touch Panel Connector Connector type USB Type B(Receptacle) Pin No. Signal name Pin No. Signal name DATA+ DATA- ユーザーズマニュアル... -
Page 21: Dip Switch
3. Outside Dimensions and Part Names Dip Switch A DIP switch is located on the left side of the unit. Switches 1 to 3 are used as the ID setting when connecting multiple touch panels via USB. See Chapter 9 for details on connecting multiple touch panels via USB. CAUTION When connecting via RS-232C or a single USB connection, set switches 1 to 3 to OFF. -
Page 22: Backlight On/Off Connector
3. Outside Dimensions and Part Names Backlight ON/OFF Connector The equipment has a backlight ON/OFF connector on the back. Given below are the pin assignment of the connector and its applicable example. Table 3.6. Remote Control Cable Connector Connector type S2B-XH-A (mfd. - Page 23 3. Outside Dimensions and Part Names ユーザーズマニュアル...
-
Page 24: Setting The Display
4. Setting the Display 4. Setting the Display Installation Requirements Please mount the display with an upright orientation. To maintain the ambient temperature within the installation environment requirement range, provide a gap of 30mm or more between the main unit and any adjacent equipment. Side view Panel 30mm or more(above) -
Page 25: Panel Cut
R1 or less Panel thickness range: 1.6 to 7mm [mm] Figure 4.2. FPD-M21VT-AC [10.4inch] Panel Cut Dimensions R1 or less Panel thickness range: 1.6 to 7mm [mm] Figure 4.3. FPD-L21ST-AC [12.1inch] Panel Cut Dimensions and Stud Hole Positions R1 or less Panel thickness range: 1.6 to 7mm... -
Page 26: Attaching The Fitting Used To Attach To The Main Unit
4. Setting the Display Attaching the Fitting Used to Attach to the Main Unit (1) Hold the main unit from the outside of the panel. Figure 4.5. Attaching the Fitting Used to Attach to the Main Unit < 1 / 2 > (2) Hold the attach from the inside of the panel. -
Page 27: How To Mount The Attachment Fittings
4. Setting the Display How to Mount the Attachment Fittings The “Cable fixed clamp” is bundled with this product. The system unit has three holes for accepting cable ties. Using a cable clamp for a cable with lock-less connector, such as the USB cable, prevents the connector from being unplugged. Use the cable ties and cable clamps appropriately according to the connecting states and wiring directions of cables. -
Page 28: Connection To The Host Computer
5. Connection to the Host Computer 5. Connection to the Host Computer Purchase individual connection cables as they are not bundled with this equipment. Analog RGB Connection This connection inputs analog RGB display signals to the equipment. Connect the cable to the analog RGB connector on the host computer. -
Page 29: Touch Panel Data Communications
CONTEC CAUTION Touch panel driver software is required to use the touch panel. Purchase optional driver software [IPC-SLIB-01 for windows] or download one from the CONTEC’s web site (http://www.contec.co.jp/download/). Please use the driver for "IPC-DT/M20V(PC)T, IPC-DT/L20S(PC)T, IPC-DT/H20X(PC)T" when using it with V1.49 or less of IPC-SLIB-01. Moreover, please use it with V1.20 or more of IPC-SLIB-01 when you use the touch panel driver software for USB. -
Page 30: Power Supply Connection
6. Power Supply Connection 6. Power Supply Connection This product operates from an AC power supply. The unit includes a terminal block for connecting the power supply. Please connect a black line of the AC power cable with L, connect the white line in N similarly, and connect a green line with FG. - Page 31 6. Power Supply Connection ユーザーズマニュアル...
-
Page 32: Screen Adjustment And A Setup
7. Screen Adjustment and a Setup 7. Screen Adjustment and a Setup The equipment has screen adjustment switches [MENU], [+], and [-]. Use these switches to adjust the screen. (For the locations of the switches, see “Outside Dimensions and Part Names” in Chapter 3.) When using the equipment for the first time or after changing the output screen mode of the host computer, execute AUTO ADJUST first on the menu screen. - Page 33 7. Screen Adjustment and a Setup Even when AUTO ADJUST fails to position the screen correctly, you can adjust POSITION : the horizontal and vertical positions of the display screen. Select this item to invoke the submenu, select a desired item using [+] or [-], then press [MENU] to accept the setting made.
- Page 34 7. Screen Adjustment and a Setup When vertical stripes have gone out to the screen, it adjusts it. Press [+] or [-] while WIDTH : checking the screen to optimize the item. TOUCHPANEL : Select this item to adjust the status of the touch panel. Select this item to invoke the submenu, select a desired item using [+] or [-], then press [MENU] to accept the setting made.
-
Page 35: Direct Key
7. Screen Adjustment and a Setup Direct Key BRIGHTNESS The brightness of the backlight can be adjusted by pressing the [+] and [-] keys without the menu screen displayed. INITIALIZATION : All the settings can be reset to the factory defaults by turning on the equipment while holding down the [MENU] key. -
Page 36: Led Indicators
8. LED Indicators 8. LED Indicators The POWER LED on the front face indicates each state of the display as follows: Table 8.1. LED Indicators LED status Description The power supply off or the equipment not started normally Green(ON) Normal operation Green(Flashing) Power save mode Orange(Flashing) Unsupported signal input *1... - Page 37 8. LED Indicators ユーザーズマニュアル...
-
Page 38: Touch Panel
Before the touch panel can be used, touch panel driver software must be installed. Note that the driver software is not bundled with this product. Purchase the one separately or download it from the CONTEC’s web site. For further details, refer to the READ_ME file for each driver. -
Page 39: Usb Multi-Touch Panel
Figure 9.2. Example of connection of a USB multi-touch panel You can use a CONTEC IPC-PT/600 series panel computer as the host PC. In this case, the ID of the touch panel in the panel computer is fixed at ID7. Set the IDs of the external displays in the range USB ID0 - USB ID6 (a maximum of seven external displays can be connected). -
Page 40: Display Mode
10. Display Mode 10. Display Mode This equipment supports the following display modes: Table 10.1. FPD-M21VT-AC Video mode Number of Dot clock (MHz) Horizontal Vertical frequency pixels (dot) frequency (kHz) (Hz) 640 x 350 25.18 31.47 *1, *2 640 x 400 25.18... - Page 41 10. Display Mode CAUTION The number of display pixels of the LCD is 640 x 480 dots on the FPD-M21VT-AC, 800 x 600 dots on the FPD-L21ST-AC, and 1024 x 768 dots on the FPD-H21XT-AC. When the input has a resolution lower than the number of display pixels of each model, the screen display is enlarged automatically.
-
Page 42: Options
: RGB display cable (5m) KU20-2H : USB cable for touch panel (2m) KU20-5H : USB cable for touch panel (5m) Manual FPD-21-HMJ : User’s manual (Japanese) for FPD-M21VT-AC, FPD-L21ST-AC, FPD-H21XT-AC series FPD-21-HMU : User’s manual (English) for FPD-M21VT-AC, FPD-L21ST-AC, FPD-H21XT-AC series ユーザーズマニュアル... - Page 43 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan Japanese http://www.contec.co.jp/ English http://www.contec.com/ Chinese http://www.contec.com.cn/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. [12212007] [12212007] Management No. A-51-517 Parts No. LYHX361...
