CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USE-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of sufficient magnitude to
constitute a risk of electric to persons.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OF MOISTURE.
POWER SUPPLY:
Connect the supplied adapter to the side of the unit in the slot marked "DC 5V IN" Plug
the two-prong end of the power cord to an AC100-240V outlet. If you have difficulty
inserting the plug, turn it over and reinsert it. If the unit will not the used for a long time,
disconnect the plug from the outlet.
NOTE:
Before plugging the power cord into an AC outlet, make sure that all the connections
have been made.
CAUTION: These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electric shock, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so.
Refer to service manual for servicing instructions. To reduce the risk of fire or electric
shock, do not expose this apparatus to rain or moisture.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Important Safety
Instructions
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Amcor Amigo 4300B
Summary of Contents for Amcor Amigo 4300B
- Page 1 Important Safety Instructions ， CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USE-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric to persons.
- Page 2 Important Safety Instructions NOTES Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a damp cloth. Do not block any of the ventilation openings. Install in accordance with the manufacturer's instructions.
- Page 3 Important Safety Instructions Warning Failure to avoid the following potentially hazardous situations may result in injury or property damage. The unit is designed to provide you with route suggestions. It does not reflect road closures or road conditions, traffic congestion, weather conditions, or other factors that may affect safety or timing while driving.
-
Page 4: Accessories
Accessories ITEM NAME Power Adaptor Car Adaptor Mounting Bracket Mounting cradle Touch Pen Disc NOTE Accessories and their parts numbers are subject to modification without prior notice due to improvements. - Page 5 Contents …………………………………..………..1 Important Safety Instructions ……………………………….…………...4 Accessories ……………………………….…………...6 View of Main Unit ……………………………….……….…..8 System Connections …………………………….……….……..10 Power Supply Preparation ……………………………….…………...12 General Setup …………………………….……………...16 MP4 Player ……………………………….…………...19 Playing Music …………………………….………….…..22 Photo Viewer …………………………….……………...32 Use of the Mount Accessories …………………………….……………...33 Troubleshooting …………………………….……………...35 Specifications...
-
Page 6: View Of Main Unit
View of Main Unit Front View Charge Indicator When charging the battery, it is red. When the battery is fully charged, it turns green. POWER button Speaker Press the power button to enter or exit the standby mode. Microphone Hole LCD Touch Screen... -
Page 7: Power Adaptor
View of Main Unit Side View Card Port Insert the SD card into the port. USB Port Used to connect to the USB device. Volume Control Used to adjust the volume of the headphone and speaker. Headphone Jack DC 5V Input Jack Used to connect to the supplied power adaptor or car adapter. -
Page 8: System Connections
System Connections Always ensure that the unit and any other external device connected to the unit are switched off and unplugged from the power supply before you attempt to connect the unit to any external device. Connecting to External GPS Antenna The unit is designed with GPS antenna jack that allows you to connect external GPS antenna to receive GPS signals in the car when the signal is bad. - Page 9 System Connections Connecting to External USB Device The unit is designed with a USB port that allows you to connect the unit to PC for map updating. See the below figure for details: You should install the driver into your PC first. Turn on the unit.
-
Page 10: Car Adaptor
Power Supply Preparation Using the AC Adaptor The player is supplied with an AC adaptor for powering the unit and charging the battery. Connect AC adaptor to the right side of the player in the jack marked DC 5V IN, as shown on the right. Plug the two-prong end of the power cord into a grounded electrical outlet. - Page 11 Power Supply Preparation About Rechargeable Battery Your portable GPS player comes with a built-in rechargeable battery. Charge the battery fully before initial use. Charging time is normally about 5 hours. A fully charged battery delivers about 3 hours of use. Working conditions and precautions for the rechargeable battery New batteries should be fully charged before initial use.
-
Page 12: General Setup
General Setup General Setup When turn on the unit, the screen will display main menu, as shown below. In the menu, there are six items for selecting, touch the item to enter it. to enter the map view; tap to enter MP4 Player; tap to enter the MP3 player;... - Page 13 General Setup Language in the settings menu to enter language settings menu for language selecting, as shown below: Tap the buttons to select language. Tap button to return. Date & Time in the settings menu to enter Date&Time settings menu for changing to the current time zone, as shown below: Tap the buttons to select the proper Time Zone.
- Page 14 General Setup Backlight in the settings menu to enter the Backlight settings menu for backlight adjusting, as shown below: Tap the buttons to adjust the brightness, tap button to return. Tap the first group buttons to adjust the backlight level. Tap the second group button to adjust the sleep time.
- Page 15 General Setup Calibrate in the settings menu to calibrate, the screen will display as below: This item is used to calibrate the sensitivity of the touch screen. Tap the center of “+” as it moves around the screen. If you touch the center of “+” every time, it will disappear after having moved through a cycle (center→top left corner→bottom left corner→bottom right corner→top right corner).
-
Page 16: Mp4 Player
MP4 Player The unit is designed with SD/MMC/MS card slot and supports MPEG-4 format files playback. You can insert the SD/MMC/MS card with MPEG-4 files in the unit for enjoyment. Note: Do not store MPEG-4 format files in the Flash storage, for the flash storage is used to store map data, any attempt to open the Flash storage may result in the map data missing and lost. - Page 17 MP4 Player button to move up or down the items list; tap to select the item that you want to play; tap to select all the items in the folder; tap to confirm your selection and the player will play the selected item automatically, as shown below: Tap the playback screen to play the file in full-screen mode;...
- Page 18 MP4 Player In the menu, tap button to enter the folders screen for adding files to the playback list; tap to move the selected file upward or downward. Tap to delete the selected file from the playback list. Tap to play the selected file. Tap to select a playback list.
-
Page 19: Playing Music
Playing Music The unit is designed with SD card slot and supports MP3 and WMA format files playback. You can insert the SD card with MP3 or WMA files in the unit for music enjoyment. Note: Do not store MP3 or WWA format files in the Flash storage, for the flash storage is used to store map data, any attempt to open the Flash storage may result in the map data missing and lost. - Page 20 Playing Music Double tap the MMC_Storage icon to open the folder, the songs in the folder will be displayed on the screen. Select the songs that you want to add into the playlist and tap to confirm. The songs selected will be added into the playlist, as shown below: In the playlist, double tap the songs to start playback.
- Page 21 Playing Music During playback, tap button to go to the previous track. During playback, tap button to go to the next track. During playback, tap button to pause playback, or in stop status, tap the button to resume playback. During playback, tap button to stop playback.
-
Page 22: Photo Viewer
Photo Viewer The unit is designed with SD card slot and supports JPEG format files playback. You can insert the SD card with JPEG files in the unit for picture view. Note: Do not store JPEG format files in the Flash storage, for the flash storage is used to store map data, any attempt to open the Flash storage may result in the map data missing and lost. - Page 23 Photo Viewer In the folders menu, tap to move the folders list up or down; tap to return to the previous folders menu. Tap to play the selected picture or to enter the selected folder; you can also realize these functions by double tapping the item you want to play or enter.
- Page 24 Bluetooth Function This unit is designed with bluetooth function. You can use it as hand free for a bluetooth hand phone. In the main menu, tap to enter the bluetooth menu, as shown below: In the Bluetooth menu, tap the button to return to the main menu.
- Page 25 Bluetooth Function Note: Before searching, make sure the bluetooth function of hand phone is turned In the process of searching, if necessary, tap button to stop searching as shown below: In the menu, tap button to search available bluetooth device again; tap the button to delete the selected bluetooth device.
- Page 26 Bluetooth Function In the menu, the icon shows that the unit and the selected hand phone have been paired off successfully. If necessary, tap button to break the bond. Activate the BT profile After having bonded successfully, tap button in the Bluetooth Manager menu to search available bluetooth protocol, and the screen displays as below: In the menu, tap button to activate the Handfree Voice Gateway, as shown below:...
- Page 27 Bluetooth Function You can also use the Shortcut command to display recent connections and make a recent profile active or inactive conveniently. In the Bluetooth Manager menu, tap the Shortcut command and the screen will display as below: In the menu, tap button to activate the selected connection;...
- Page 28 Bluetooth Function In the menu, tap the yellow square to select or cancel these commands; tap button to save your setting; tap button to cancel. Current Active Profiles button in the Bluetooth Manager menu to enter Active Connection menu that displays the current active profiles, as shown below: In the Active Connection menu, tap button to make the selected BT profiles...
-
Page 29: Phone Book
Bluetooth Function Use the keyboard to enter phone number, and then tap button to call; the screen will show as below: In the Talking menu, tap buttons to adjust the volume level; tap button to turn off/on the speaker; tap button to hang up;... - Page 30 Bluetooth Function In the phone book, tap buttons to move up or down the list of phone number; you can select a phone number and tap button to call directly. Tap button to delete the selected phone numbers; tap button to return to the previous menu. button to add a phone number to the list, the screen will show as below: In the menu, double tap the blank on the right of the item you want to edit, for example “Name”, then you will enter a keyboard as shown below:...
- Page 31 Bluetooth Function Call Record In the Bluetooth menu, tap button to display recent call notes, as shown below: In the menu, tap button to display recent received calls; tap button to display recent dialed numbers; tap the button to display recent missed calls. button to delete the selected note;...
- Page 32 Using the Mounting Accessories When using the unit in vehicle, you can use the supplied mount accessories (mount bracket, mount cradle and dashboard mount disk) to mount the unit in the vehicle. Take the following steps to operate: Slide the mounting cradle onto the end of the mounting bracket. Set the bottom edge of the unit on the bottom of the mounting cradle.
-
Page 33: Troubleshooting
Troubleshooting Take steps described in the tables below to solve simple problems before contacting customer service. If you suspect something wrong with the unit, immediately turn the power off and disconnect the power connector from the unit. Never try to repair the unit yourself because it is dangerous to do so. - Page 34 Troubleshooting POSSIBLE SOLUTION POSSIBLE CAUSE PROBLEM Use the adaptor to supply The built-in rechargeable power charge battery is weak. battery. The unit can receive signals The unit may be obstructed Remove the veil. now but can’t veil, such heat then; signals insulation paper.
-
Page 35: Specifications
Specifications TFT screen size 4.3 inches Frequency Response 20Hz～20kHz ≥65dB Audio Signal-to-noise Rate ≤－20dB (1kHz) Audio distortion or noise ≥70dB (1kHz) Channel Separation ≥80dB (1kHz) Dynamic Range AC 100-240V ～ Power 50/60Hz; DC 5V Power Consumption < 8W Dimensions 130mmX74mmX24mm (L*W*D) Weight About 0.25kg DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE...
