Summary of Contents for Yamaha TSX-B15
- Page 1 OWNER'S MANUAL...
-
Page 2: Important Safety Instructions
– and, most importantly, without affecting your sensitive hearing. Since hearing damage from loud sounds is often undetectable until it is too late, Yamaha and the Electronic Industries Association’s Consumer Electronics Group recommend you to avoid prolonged exposure from excessive... - Page 3 “OFF” requirements. Modifications not expressly approved and “ON”, please try to eliminate the problem by by Yamaha may void your authority, granted by the using one of the following measures: FCC, to use the product.
- Page 4 Comme les sons trop forts causent des lésions auditives qui ne peuvent être détectées qu’à long terme, lorsqu’il est trop tard, Yamaha et le Groupe des Entreprises Électroniques Grand Public de l’Association des Industries Électroniques vous déconseillent l’écoute prolongée à des volumes...
- Page 5 être déterminé en Toute modification non approuvée expressément par “ÉTEIGNANT” et en “RALLUMANT” le produit, Yamaha peut invalider l’autorisation, accordée par la l’utilisateur est invité à essayer de corriger le problème FCC, d’utiliser ce produit.
- Page 6 14 Ne tentez pas de modifier ni de réparer l’appareil. l’humidité et du froid. Pour une aération correcte, Consultez le service Yamaha compétent pour toute tenez compte des distances minimales suivantes. réparation qui serait requise. Le coffret de l’appareil Au-dessus : 15 cm ne doit jamais être ouvert, quelle que soit la raison.
- Page 7 – Supplying power to smartphones, tablets, etc. via USB port on the rear panel. – Rich sound by 5cm full-range custom speaker and DSP (Digital Signal Processor) made by Yamaha. – Enhanced treble and thick mid/bass, even when playing compressed audio source, such as MP3, etc.
-
Page 8: Names Of Parts And Their Functions
NAMES OF PARTS AND THEIR FUNCTIONS ■ Top panel Press to turn the system on/off. Time is displayed even when the system is off. Standby mode • Press and hold for more than 3 seconds to set the system to standby mode. -
Page 9: Rear Panel
NAMES OF PARTS AND THEIR FUNCTIONS ■ Rear panel J CHARGING Supplies 5 V/1 A to a portable device, such as a smartphone, when it is connected with a USB cable. (☞ P. 7) K 12 V M FM ANT Connect the supplied L INPUT FM antenna terminal. -
Page 10: Basic Functions
OPERATION BASIC FUNCTIONS Adjusting the clock A Press and hold CLOCK. The display flashes. A / C B Adjust the time with TUNING. C Press CLOCK. If you want to cancel alarm setting mode, press If you press PRESET in step 2, you can select the time display format (12 hours/24 hours). - Page 11 BASIC FUNCTIONS ■ Switching the alarm on/off Press ALARM. When the alarm is on, the alarm indicator ( lights and alarm time is displayed for a while. Alarm indicator ( Operations during playing back alarm sound At the set time, alarm sound plays back. During playback, operations below are available. ■...
-
Page 12: Listening To Fm Stations
LISTENING TO FM STATIONS Tuning radio stations A Press SOURCE to select RADIO. The RADIO indicator lights. B For automatic tuning, press and hold TUNING. For manual tuning, press TUNING repeatedly. Note If you tune to a station manually, the sound is monaural. Presetting radio stations You can store up to five favorite FM radio stations with the preset function. -
Page 13: Charging With The Usb Port
• This unit does not function as memory storage. Rear panel • Yamaha will not be held responsible for any damage to the portable device or data loss occurred while using this unit. • Disconnect the USB cable immediately after charging completes, since power continues to be supplied to the connected device. -
Page 14: Listening To Music From Your Bluetooth Component
LISTENING TO MUSIC FROM YOUR Bluetooth COMPONENT This unit provides Bluetooth functionality. You can enjoy wireless music playback from your Bluetooth component (smartphone, digital audio player, etc.). Please also refer to the owner’s manual of your Bluetooth component. Installation Install in a stable place, being careful of the following points: •... - Page 15 B Perform Bluetooth pairing on the other component. For details, refer to the owner’s manual of the other component. C From the Bluetooth connection list of the other component, choose this unit (TSX-B15 Yamaha). When pairing has been completed, the Bluetooth indicator ( ) will light in blue.
-
Page 16: Listening To A Bluetooth Component
■ Connecting from the other component A In the Bluetooth settings of the other component, turn Bluetooth on. B From the Bluetooth connection list of the other component, choose this unit (TSX-B15 Yamaha). The Bluetooth connection will be established, and the Bluetooth indicator ( ) will light in blue. -
Page 17: Troubleshooting
Refer to the table below if the unit does not operate properly. If the problem you are experiencing is not listed below, or if the instruction below does not help, turn off the unit, disconnect the power cable, and contact the nearest authorized Yamaha dealer or service center. General... -
Page 18: Resetting The Unit
TROUBLESHOOTING Bluetooth Problem Cause Solution Cannot make this unit The other component does not support Perform pairing operations with a component A2DP. which supports A2DP. paired with the other component. A Bluetooth adaptor, etc. that you want to Use a Bluetooth adaptor, etc. whose password pair with this unit has a password other is “0000”. -
Page 19: Specifications
2.4 GHz frequency band, a band which can be used without a license. • Bluetooth is a registered trademark of the Bluetooth SIG and is used by Yamaha in accordance with a license agreement. Handling Bluetooth communications • The 2.4 GHz band used by Bluetooth compatible devices is a radio band shared by many types of equipment. - Page 20 © 2014 Yamaha Corporation Printed in China ZN35280...
