Page 3: Compliance Notice Of Fcc
Digital Video Recorder WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"... -
Page 4: Important Safeguards
User’s Manual Important Safeguards 1. Read Instructions 10. Overloading All the safety and operating instructions should be read before the Do not overload wall outlets and extension cords as this can result appliance is operated. in the risk of fire or electric shock. 2. - Page 5 Digital Video Recorder Table of Contents Chapter 1 — Introduction......................1 Feature ..........................1 Technical Overview ......................1 Chapter 2 — Installation ......................3 Package Contents ......................3 Required Installation Tools ....................3 Video Input ........................3 Audio In/Out ........................4 Alarm Input/Output ......................4 Factory Reset Switch .....................4 Video Out........................5 Network Port ........................5 RS232 Port ........................5...
- Page 6 User’s Manual Appendix ..........................13 Error Code Notices ......................13 System Log Notices ......................14 Map of Screens ........................ 15 Troubleshooting ....................... 16 Specifications ........................16...
-
Page 7: Chapter 1 — Introduction
Digital Video Recorder Chapter 1 — Introduction Feature Your color digital video recorder (DVR) provides recording capabilities for 4 camera inputs. It provides exceptional picture quality in both live and playback modes, and offers the following features: Live Monitoring for Each Channel ... - Page 8 User’s Manual Figure 1: Typical DVR installation.
-
Page 9: Chapter 2 — Installation
Digital Video Recorder Chapter 2 — Installation Package Contents The package contains the following: Digital Video Recorder Power Adaptor and Power Cord User’s Manual (This Document) RAS Software CD and User’s Manual USB Mouse Required Installation Tools No special tools are required to install the DVR. -
Page 10: Audio In/Out
User’s Manual Audio In/Out Your DVR can record audio from up to four sources. Connect the audio sources to Audio In 1, Audio In 2, Audio In 3 and Audio In 4 as needed using RCA jacks. Connect Audio Out to your amplifier. NOTE: It is the user’s responsibility to determine if local laws and regulations permit recording audio. -
Page 11: Video Out
Digital Video Recorder Video Out An HDMI (High-Definition Multimedia Interface) connector is provided so that you can use an HDMI monitor as your main monitor. A VGA connector is provided so that you can use a standard, multi-sync computer monitor as your main monitor. -
Page 12: Power Cord Connector
User’s Manual Power Cord Connector Connect the connector of the adaptor to the DVR, and connect the AC power cord to the adaptor and then to the wall outlet. WARNING: ROUTE POWER CORDS SO THAT THEY ARE NOT A TRIPPING HAZARD. MAKE CERTAIN THE POWER CORD WILL NOT BE PINCHED OR ABRADED BY FURNITURE. -
Page 13: Chapter 3 — Configuration
Digital Video Recorder Chapter 3 — Configuration NOTE: Your DVR should be completely installed before proceeding. Refer to Chapter 2 — Installation. Front Panel Controls Figure 3: DVR front panel. Camera Buttons HDD LED Alarm LED Arrow Buttons Play/Pause Button Menu Button PTZ/Zoom Button Group/Sequence Button... -
Page 14: Arrow Buttons
User’s Manual Arrow Buttons These buttons are used to navigate through menus and GUI. You can also use them to change numbers by highlighting a number in the menu and using the Up and Down arrow buttons to increase or decrease the number’s value. These buttons are also used to control Pan and Tilt when in the PTZ mode. -
Page 15: Search Button
Digital Video Recorder Search Button Pressing the button enters the search mode, and pressing the button again exits the search mode. When entering SEARCH the search mode, video is paused. Pressing the (Play/Pause) button plays back video at regular speed. The screen displays when the DVR is in the Pause mode and the screen displays when the DVR is playing back video. -
Page 16: Remote Control Buttons
User’s Manual Remote Control Buttons ID Button Camera Buttons Sequence Button Freeze Button Arrow Buttons Menu Button Playback Buttons Panic Button Layout Button Zoom Button PTZ Button Enter Button Alarm Button PTZ Control Buttons Back Up Button Calendar Button Figure 4: Infrared remote control. NOTE: For simplicity, the button descriptions in this manual refer to the front panel buttons. -
Page 17: Arrow Buttons
Digital Video Recorder Arrow Buttons These buttons are used to navigate through menus and GUI. You can also use them to change numbers by highlighting a number in the menu and using the Up and Down arrow buttons to increase or decrease the number’s value. These buttons are also used to control Pan and Tilt when in the PTZ mode. -
Page 18: Alarm Button
User’s Manual Alarm Button button resets the DVR’s outputs including the internal buzzer during an alarm. Pressing the ALARM PTZ Control Buttons While in the PTZ mode, the buttons are used to save Presets and load a Preset View, the buttons are used PRESET ZOOM... -
Page 19: Appendix
Digital Video Recorder Appendix Error Code Notices System Upgrade Related Clip Copy Related Description Description Unknown error. Unknown error. File version error. Device error. Operating system version error. Mounting failed. Software version error. No media. Kernel version error. Invalid media. Upgrade device mounting failed. -
Page 20: System Log Notices
User’s Manual System Log Notices Boot Up Clear All Data Shutdown Clear Disk Restart Format Disk Upgrade Disk Full Upgrade Fail Disk Config Change Power Failure No storage found Disk ‘No.’ : ‘serial number’ Time Change Disk ‘No.’ : Removed Time Zone Change Time Sync Auto Deletion... -
Page 21: Map Of Screens
Digital Video Recorder Map of Screens MENU SYSTEM General Date/Time User Storage System Event RECORD General Schedule Pre-Event EVENT Motion Alarm-In Video Loss Video Blind Text-In CAMERA General DEVICE Audio Alarm-Out Remote Control NETWORK General RTSP WebGuard NetFS NOTIFICATION Callback Mail Schedule DISPLAY... -
Page 22: Troubleshooting
User’s Manual Troubleshooting Problem Possible Solution Check power cord connections. No Power Confirm that there is power at the outlet. Check camera video cable and connections. Check monitor video cable and connections. Confirm that the camera has power. No Live Video ... - Page 23 Digital Video Recorder CONNECTORS Video Input Composite or HD-TVI: 4 BNC HDMI: 1 HDMI Monitor Output VGA: 1 VGA Audio In 4 RCA connector Audio Out 1 RCA connector Alarm Input/Output Terminal Blocks Ethernet Port RJ-45 RS232 Serial Port Two-connector terminal block RS485 Serial Port Two-connector terminal block IR Port...
