Anova A2.2-120V-US Operating Manual

Anova A2.2-120V-US Operating Manual

Precision sous vide immersion circulator

Advertisement

AnovA
Precision
Immersion Circulator
Operating Manual
Sous Vide
®
Anova Culinary LLC
Houston, TX USA
TEL: 281-980-1236
FAX: 281-980-1352
www.anovaculinary.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A2.2-120V-US and is the answer not in the manual?

Questions and answers

Summary of Contents for Anova A2.2-120V-US

  • Page 1 AnovA Precision Sous Vide ® Immersion Circulator Operating Manual Anova Culinary LLC Houston, TX USA TEL: 281-980-1236 FAX: 281-980-1352 www.anovaculinary.com...
  • Page 3 24-25 Intellectual Property All Intellectual Properties, as defi ned below, owned by or which is otherwise the property of Anova Industries, Anova Culinary LLC or its suppliers relating to Anova products, including but not limited to, accessories, parts or software relating thereto, are proprietary to federal and state laws, and international treaty provisions.
  • Page 4: Operation Safety

    OPERATION SAFETY This section explains the potential dangers that may arise when operating the Anova sous vide circulator and notes many important safety precautions. Burn Hazard - the cooking container, the stainless steel portion of circulator, and food pouches all get hot when used. Use oven mitts or tongs when handling.
  • Page 5 DO NOT DISASSEMBLE. OBSERVE ALL WARNING LABELS. Do not remove warning labels. If your circulator falls into water discon- nect power ASAP to avoid shock and then send back system to repair (water damage not covered by warranty). Do not retrieve the unit until you have un- plugged the cord.
  • Page 6: Introduction

    INTRODUCTION ® Anova Precision sous vide circulators are precision temperature controlled circulators de- signed to regulate the temperature of a water bath. The system features:  high precision temperature controller with heater  screw clamp   removable skirt ...
  • Page 7: Technical Specifications

    Anova circulators are not designed for direct contact with food. Do not use Anova circulators to directly contact food – at no time should food products also come in contact with bath fl uid. Food must be vacuum- sealed, heat sealed, or zip locked before use with the circulator.
  • Page 8: Setup

    SETUP Anova sous vide circulators are designed to be used only with water.
  • Page 9: Clamp & Pot

    SETUP (clamp & pot) Anova sous vide circulators require a 6.5 inch (16.5cm) deep container or pot. Place the Anova circulator on the side of your container and turn the clamp until it is tight. Fill the pot with water between the min/max markers on the skirt. Remember large cuts of meat like a turkey can over top the water your pot.
  • Page 10: Power On

    SETUP (power on) Insert the power plug fi rmly into the system. Press the power switch in the back.    ...
  • Page 11: Pump Direction

    SETUP (pump direction) The pump can channel fl ow around large objects or away from delicate foods. Turn the pump cap to change the output direction of the water fl ow. For extremely delicate foods like eggs or fl ounder - turn the output to the back of the container wall.
  • Page 12: Set Temp

    SETUP (set temp)  Changing Temperature: 1) Press “set temp”  2) Select/Change Temp  3) Accept new setting or Exit...
  • Page 13: Set Time

    SETUP (set time)  Changing Time: 1) Press “set time”  2) Select/Change Time   3) Accept new setting or Exit...
  • Page 14: Change C/F Units

    SETUP (change c/f units) Changing Temperature Units: 1) Press “Enter System Confi g.”   2) Toggle C/F temperature units. 3) Accept new setting or Exit ...
  • Page 15: Timer Mode

    SETUP (timer mode) Changing Timer Mode: 1) Press “Enter System Confi g”   2) Toggle timer mode to alarm or to stop system 3) Accept new setting or Exit ...
  • Page 16: Start/Stop

    SETUP (start/stop) Start and Stop: 1) Press “Start”  2) Toggle display view  3) Stop unit ...
  • Page 17: Calib. Off-Set

    SETUP (calib. off-set) Calibrating:  Press “+/-” to enter calibration mode to enter in desired offset amount.
  • Page 18: Maintenance

    If any signs of physical damage are found send back for factory ser- vice and replacement parts. Repairs: If your system falls into the water or is physically damaged, contact Anova Culi- nary LLC for a return and return authorization number.
  • Page 19: Assembly

    Maintenance (assembly) Twist the skirt to the left until it comes off. Sometimes the impellers will get caught on the side of the skirt as the skirt is getting pulled off. Jiggle the skirt from side to side to loosen up the skirt You can also remove the pump cap fi...
  • Page 20: Skirt/Pump

    Maintenance (skirt/pump) Twist the pump cap until it comes off. The skirt an pump cap can be placed into the dish washer.
  • Page 21: Cleaning

    Maintenance (cleaning) CLEANING THE SKIRT : CLEANING THE CIRCULATOR: For cleaning the heating coil, To clean the stainless steel skirt and pump shaft, and sensors, use dish pump cover – place into a dish washer soap, a soft tooth brush and rinse or washed in the sink with detergent under water.
  • Page 22: Stains

    Maintenance (stains) CALCIUM & HARD WATER STAIN REMOVAL: Hard water stains will appear on the heater and stainless steel skirt. Use the following products to remove stains and lime build up: 1) ZEP Calcium Lime Rust Remover - commercial grade lime remover is a concentrate and is also the cheapest (by weight).
  • Page 23: Warranty Provisions

    Warranty Provisions The following Warranty Provisions shall apply to products sold in North America by Anova (“Seller”) to the entity shown as buyer (“Buyer”) on Seller’s invoice. 1. Initial Warranty. Seller warrants to the Buyer that the products manufactured by the Seller are free from defects in material and workmanship for a period not to exceed one (1) year or fi...
  • Page 24: Trouble Shooting/Faq

    TroubleShooting FAQ Noise: Under normal operation the system will hum due to the motor, impeller and cooling fan in operation. Grinding metal on metal noise: The stainless steel skirt is loose. Push the stainless skirt up into the guide groove and turn to the right until you hear a click.
  • Page 25 Temperature read does not match thermometer: Keep in mind, Anova immersion circulators are calibrated to a scientifi c platinum primary standard which is far more accurate than store thermometers. Cover your tank with foil and wait about 15 minutes for temperature equilibration –...
  • Page 26 Anova Culinary LLC Houston, TX USA TEL: 281-980-1236 FAX: 281-980-1352 www.anovaculinary.com...
