- Page 1 Quick Install Manual Version:1.0 L201 1FXS/1FXO gateway Solwise Ltd, www.solwise.co.uk, sales@solwise.co.uk...
-
Page 2: Table Of Contents
2.1 WAN S ETUP REQUIRED FOR NTERNET ACCESS 2.2 DHCP S ETTING 2.3 F IP S IXED ETTING 2.4 PPP ETTING 2.5 NAT S ETUP 2.6 V IP C ETUP SCENARIO APPLICATION APPENDIX IRECT CALL EER TO SETUP Solwise Ltd, www.solwise.co.uk, sales@solwise.co.uk... -
Page 3: Installing Voice Broadband Gateway
Gateway for further configuration by connecting to LAN port. The management PC may be configured with a fixed IP address. For a fixed IP address, use an IP address from a 222.222.222.x network, such as 222.222.222.2.Or use DHCP form Lan port of gateway. Solwise Ltd, www.solwise.co.uk, sales@solwise.co.uk... -
Page 4: Configuring The Voice Broadband Gateway
3. If this is a first time setup of the Gateway, type admin as the User Name and admin as the Password field. Click OK. 4. The Web Configurator Setup Main Menu will open as below : Solwise Ltd, www.solwise.co.uk, sales@solwise.co.uk... -
Page 5: Setup Wizard Forq
When you select “Fixed IP“ option, you could see the Fixed IP setting menu to key in “IP address”, “Default Router IP Address” and “Subnet Mask”. Please Click on “Next “, then you enter the “NAT Setting” (Please go to 2.5 NAT Setting) Solwise Ltd, www.solwise.co.uk, sales@solwise.co.uk... -
Page 6: Pppoe Setting
Gateway Provide two modes, one is Bridge Mode, the other one is NAT Mode: 2.5.2 Setting LAN IP address to provide a C-class subnet 2.5.3 Please Click on “Next “, then you enter the “NAT Setting” (Please go to 2.6 VoIP Call Setup) Solwise Ltd, www.solwise.co.uk, sales@solwise.co.uk... -
Page 7: Oip Call Setup
3. Direct Call Plan Setting: if you don’t register Gatekeeper and want to use Peer to Peer call, you must setting the dial plan. When you use the peer to peer mode, please setting the gatekeeper field to “0.0.0.0”. (About Dial plan setting, please see the Appendix Dialing Plan.) Solwise Ltd, www.solwise.co.uk, sales@solwise.co.uk... - Page 8 3. Direct Call Plan Setting: if you don’t register SIP Proxy Server and want to use Peer to Peer call, you must setting the dial plan. When you use the peer to peer mode, please setting the SIP Proxy Server IP field to “0.0.0.0”. (About Dial plan setting, please see the Appendix Dialing Plan.) Solwise Ltd, www.solwise.co.uk, sales@solwise.co.uk...
-
Page 9: Scenario Application
VoIP call or registering H.323 Gatekeeper (SIP Proxy Server) Mode. The H.323(SIP) Dialing Plan has two kinds of directions: Outgoing (call out) and Incoming (call in). 1. Outgoing Dial Plan: Peer-to-Peer Call Mode: Effective Registering to H.323 Gatekeeper (SIP Proxy Server) Mode: Effective Solwise Ltd, www.solwise.co.uk, sales@solwise.co.uk... - Page 10 Gateway that owns this phone number. “Destination Port” is port of the destination gateway use.(Default is 5060) Example1: Normally Dial 1.001x leading call out, call to Destination IP address: 211.22.3.14 2.002x leading call out, call to Destination Domain Name: h.323.gw.net Solwise Ltd, www.solwise.co.uk, sales@solwise.co.uk...
- Page 11 If Port 1 is busy, Port will be ringing. If Port 1 and 2 are busy, Port 3 will be ringing. If Port 1, Port 2 and Port 3 are busy, Port 4 will be ringing. Solwise Ltd, www.solwise.co.uk, sales@solwise.co.uk...
- Page 12 PSTN number. ( [x]: mean wild card, 0~9. Speed dial: When you dial over the number, input “#” key can speed dial call, or you key in number as the length as the “length of number” ) Solwise Ltd, www.solwise.co.uk, sales@solwise.co.uk...
