- Page 1 Installation Manual Solar storage tanks SILOS - SILOS M...
- Page 3 Arrange for the storage tank to be serviced regularly by an authorised SYLBER Technical Assistance Centre. Their personnel are specially trained to keep your storage tank efficient and cheap to run.
-
Page 4: Table Of Contents
Contents GENERAL Safety precautions page 5 General safety information “ Product description “ Identification “ Design “ Technical specifications “ Pressure drops “ Dimensions and weight “ INSTALLATION Unpacking the product page 10 Handling “ Place of installation “ Installation in older systems and systems requiring modernisation “... -
Page 5: Safety Precautions
If the product is not going to be used for an exten- and as ordered as soon as you receive it. Report ded period of time, contact the manufacturer’s any discrepancies or damage to the SYLBER dea- Technical Assistance Centre to have at least the fol- ler who sold it. -
Page 6: Product Description
Product description Solar storage tanks are specifically designed for integra- - CFC-free polyurethane insulation and an elegant exter- tion in central heating systems (not for DHW use). nal coating reduce heat loss and improve efficiency. The most important technical features of these storage - A flange is provided for easy cleaning and to allow an tanks are: extra heat exchanger to be added (only for models... -
Page 7: Design
Design SILOS 300 M - 500 M - 1000 M - 1500 M models 1 - Soft polyurethane insulation (100 mm) 2 - Vent flow connection (Ø1"1/4F) 3 - Flow/return connection (Ø 1”1/2F) 4 - Probes sockets (Ø 8 mm) 5 - Solar collector flow connection (Ø... -
Page 8: Technical Specifications
Soft PU (*) In accordance with DIN 4708 with a ΔT of 20°C (80°/60°C) at the coil. Pressure drops COIL pressure drop (SILOS 300 M - 500 M - 1000 M -1500 M models only) SILOS 1500 M SILOS 1000 M... -
Page 9: Dimensions And Weight
2500 2000 1500 1000 PORTATA (m FLOW RATE (m 3 /h) Dimensions and weight SILOS 2000 - 3000 - 5000 models SILOS 300 M - 500 M 1000 M - 1500 M models Ø Ø SILOS SILOS SILOS SILOS SILOS... -
Page 10: Unpacking The Product
Unpacking the product SILOS 300 M - 500 M - 1000 M - 1500 M solar storage SILOS 300 M - 500 M - 1000 M - 1500 M tanks are delivered in a single package, protected by a plastic bag and supported by a wooden pallet. -
Page 11: Handling
Cut the straps (1) to remove the tank from the pallet. On SILOS 300 M - 500 M - 1000 M - 1500 M models the straps are located under the insulation at the hinges. -
Page 12: Fitting The Insulation
Fitting the insulation (SILOS 2000 - 3000 - 5000) Once the storage tank is correctly positioned inside the room where it is to be installed, proceed to fit the insula- tion and the accessories to complete the tank. Proceed as follows: - Unpack all the material from the second package - Wrap the insulation (1) around the storage tank, care- fully lining up the fittings with the holes on the inside of... -
Page 13: Preparing For Initial Start-Up
Scheduled maintenance is essential for the safety, efficiency and long working life of your solar storage tank. Proper maintenance also reduces energy consumption and ensures reliability over time. Have your storage tank serviced either by a SYLBER Technical Assistance Centre or by a qualified professional at least once a year. Perform the following operations before beginning any maintenance. -
Page 14: Troubleshooting
Troubleshooting PROBLEM CAUSE CORRECTIVE ACTION Fit a pressure limiter The supply pressure is too high Little hot water is produced The flow rate is too high Fit a flow reducer Blockages or deposits Check and clean as necessary are present The pump is malfunctioning Check the pump Check the setting and condition... - Page 15 PROBLEM CAUSE CORRECTIVE ACTION Solar heating system There is air in the circuit Bleed the circuit is inefficient The flow rate is too low Make sure that the flow rate cor- or too high responds to about 30l/h per m Check that the cold pressure of Pressure is low the system is...
- Page 16 Via Risorgimento, 23 A 23900 - Lecco (LC) www.sylber.it The manufacturer strives to continuously improve all products. Appearance, dimensions, technical specifications, standard equipment and accessories are therefore liable to modification without notice.
