Instructions
• Power On/Off Press and hold power button ( ) for 1 second to switch
ON or OFF. Note: WT-1 will switch on when it receives
detector audio. Modules will automatically switch off
after 10 minutes without a paired mate, or after 30
minutes of inactivity.
• Volume
Adjust with WR-1 volume control buttons. If using
volume-control headphones, set headphones to full
volume, and then adjust WR-1 to maximum desired
level. While hunting, additional adjustments can be
made with headphone volume controls.
• Pairing
Switch both modules on, bring within 3 feet (1 meter) of
each other, and then quickly press and release the power
button on WT-1 (TX module). The modules will remain
paired until you choose to pair them with another Z-Lynk
device.
• Recharging
Plug the supplied charging cables into the modules and
any standard USB port to recharge.
• LED Indicators Battery indicator (
approx. 3 hours remaining. Battery indicator LED displays
solid light while charging and is off when complete.
Pairing indicator ( ) will blink slowly when not paired;
will blink quickly during pairing search; and will remain
steady when paired.
• Caution
The WR-1 unit is weather resistant in light rain; the
WT-1 unit will tolerate heavier rain. The Z-Lynk modules
should never be submerged.
6
) begins blinking when there are

Specifications

Model Number: 1627100, Garrett Z-Lynk™ Wireless System
Audio Delay: 17 milliseconds (ms); 6x faster than Bluetooth®
Audio Bandwidth: 20 kHz (high fidelity)
Radio Frequency: 2.4 GHz with frequency-hopping, prevents crosstalk
Battery Life: Up to 30 hours, both modules
Recharge Time: 5 hours from any standard USB port
Environmental: Water resistant; do not submerge.
• WR-1 unit: IP 52: protects against light rain.
• WT-1 unit: IP 64: protects against heavy rain.
Warranty: 2 year, limited parts and labor
Certifications: FCC, CE, IC
Operating Temperature: -20° (-4° F) to 60° C (140° F)
• Compatible with nearly any brand and model of VLF and pulse detectors.
• Compatible with any Garrett Z-Lynk device.
• Compatible with nearly any wired headphone.
Accessory:
PN 1627410 Z-Lynk headphone cable with 2-pin AT connector
MADE IN
THE USA
Garrett Metal Detectors, garrett.com, and Z-Lynk are trade-
marks and registered trademarks of Garrett Electronics Inc.
g a r r e t t . c o m
© 2016 Garrett Metal Detectors. 1539400.A.1216
