- Page 1 Quick Guide RVM740SM CN186-W CA LL Please read the manual before operating this product. All the tech information shown is based on the actual product, our company reserves the final interpretation. No.A00...
- Page 2 Copyright The copyright of this manual is reserved by VOXX Electronics. This manual may not be copied, reproduced or translated in whole or in part with out the express written permission of our company. Our company reserves the right to improve this product, hardware and software.
- Page 3 Care and maintenance • Please don’t insert coins or metal objects. • Please don’t try to repair by yourself. • Please don’t let the display screen incur moisture, dust or excessive temperatures. • Please don’t place the product in direct sunlight for extended periods of time. •...
-
Page 4: Table Of Contents
Contents Notes before use -----------------------------1~2 e. Easy Connected ----------------------------------15 2 Product Brief -----------------------------------3 f. FM Launcher --------------------------------------16 3 Gestures and panel buttons ----------------------4 g. Settings -------------------------------------------17 a. Gesture Control ----------------------------------4 h. Application ---------------------------------------18 b. Touch Button Definition --------------------------4 i. Reverse video -------------------------------------18 4 Basic function operation ---------------------5~20 j. -
Page 5: Notes Before Use
1 - Notes before use • This product is made up of many electronic components. Improper disassembly or modification may damage the product. If something is broken or not functioning properly, please immediately Turn off the power and notify the company or the distributor. •... - Page 6 • Please stop using this machine during extreme weather conditions to avoid distracted driving. • The following conditions will affect the normal operation of this product: ➢ Factors such as inclement weather or geographical location of the car may affect the product's wireless network and GPS access signal GPS positioning navigation may be affected.
-
Page 7: Product Brief
2 - Product Brief This product is an intelligent rearview mirror, with 7.84 inch screen that has a resolution of 1280X400. The product supports multiple functions including: • Navigation • • Bluetooth • WIFI • FM transmission • Access to mobile applications •... -
Page 8: Gestures And Panel Buttons
3 - Gestures and panel buttons description b. Button Definitions a. Gesture Control ④ Locked Key ③ Power button Gesture sensing uses free touch technology, through various sensor within the mirror that process user’s gestures that are compatible with various mirror functions. CALL Gestures sensor light is on the bottom left of the Rearview ②... -
Page 9: Basic Function Operation
4 - Basic Operation Turn on/off When the car starts up, the system will automatically start and enter the main interface. When you need to turn it off, press and hold the power button for 3 seconds to shut down. Click the button shortly to start the mirror. When the car is turned off, the system records the state of the mirror (On/Off). - Page 10 Main Interface When you boot into the home screen, you will see the navigation, traffic track record, bluetooth phone, EASY CONNECT, FM, universal settings and APP choices. In this interface, on the left side of the screen, a hidden system toolbar will be displayed in the bottom area. Within the toolbar contains the volume decreases, volume increase, mute, shortcut to screen brightness and other functions.
-
Page 11: Nav Function Operation
a. NAV function operation NOTE: GPS NAV is an optional add on to this system. In the main menu press the " GPS Navigation " button to enter the navigation mode. Navigation is based on the destination set by the user, the system will calculate the best route, display the roads and traffic signs with high-precision graphics. -
Page 12: Car Dvr Function Operation
b. CAR DVR function operation Driving recording (1080p hd records) supports a video file protection function to avoid data loss. Locked video files will be saved for future viewing and will not be overwritten. When reviewing driving records, do not remove DVR TF card, this may lead to damage of TF card. Before reviewing the video of driving, make sure your device has an installed TF card (TF card should use high speed card that C6+ version). - Page 13 Playback File management: click this button to view the saved video/photos; preview camera images, view recorded/locked video Video file playback can be reviewed by clicking play. Video playback can also be found through the system of player or ES file browser and clicking on play. The video or photos can be deleted from the formatted T card, data delete will not be able to restore, even locked files, please use this feature carefully.
-
Page 14: Video File Protection
c. Video File Protection (Locked Video Files) The system will continuously record video as you drive, overwriting older video in the process. Videos that are locked will be protected and not be overwritten. Video file protection is automatic if an impact is detected or when the lock button is pressed. "... -
Page 15: Bluetooth Handsfree Functionoperation
d. BlueTooth handsfree functionoperation In the main menu press the " BlueTooth " button to enter the bluetooth handsfree mode. NOTE: As the bluetooth modules and software of cellphone come from different brands, some functions may be different or even not compatible with other system. On the right side of list display paired and unpaired bluetooth devices. - Page 16 Phone pairing NOTE: Default pairing password: 1234 Pairing refers to connecting Bluetooth device communication for the first time, the process of mutual connection. After pairing between two devices, they will automatically connect going forward. When the connection is successful, the connection a bluetooth device name behind the success of a small icon indicates "...
- Page 17 Answer thephone 1) When there is an incoming call, in any mode, the system will automatically switch to Bluetooth handsfree, music will paused and the ring from the speakers. Answer“ , “ hang up “ on the screen to choose answer or hang up. 2) Press the“...
- Page 18 Bluetooth Music In the bluetooth interface, click the " " icon to access the music interface. If the cell phone supports music playback via Bluetooth, audio and video from the cell phone can be transferred to the loud speaker of the car. Play/Pause Previous track Next track...
-
Page 19: Easy Connected
e. Easy Connected In the main menu interface, click on the "Easy Connected" icon to get into the Easy Connected interface. Android systems can be connected through USB cable, WIFI and WIFI connection hotspot. Android USB In the Easy Connected interface, click the "Android USB " icon. Connect the mobile device via USB cable >... -
Page 20: Fm Launcher
f. FM transmit In the main interface, click the " FM transmit " icon enter the FM transmit function interface. Turn on/off " this button is blue, FM Transmit is “OFF”; When " " this button is red, FM Transmit is “ON”. When "... -
Page 21: Settings
g. Settings In the main menu interface, click on the " Settings " icon to enter the Settings interface. Once there, you can adjust Device, Personal, System, Display and other functions there. Device Personal Adjust Assistive Touch, keypad tone, parking warn line, For WIFI, WIFI hotspot, App management and Bluetooth settings. -
Page 22: Application
h. Application In the main menu interface, click on the "Application" icon to enter the application interface. Application interface is to display the Application shortcut icon. Use your finger to view application shortcut icons, click on the icon to go into the function. i. -
Page 23: Es File Explorer
k. E S File Explorer In the main interface, enter the application function to find the "ES File Explorer" icon click into the ES File Explorer function. ① Click the " " button on the upper left coner, you can choose the main page, main directory, root directory management or browse files in the SD card. -
Page 24: Trouble Shooting
5 - Trouble Shooting If problems can not be solved effectively, please contact our company or professional service center. Remedy Problem Possible Cause Car battery powersupply Power the car battery through external power supply to check whether the external power supply is in goodcontact shortage Cannot turn on ①Press Reset Button near T Card position. - Page 25 Remedy Problem Possible Cause ① Card is no lower than class 8 grade TF card, it is best to use a class 10 TF Card. ① TF card is not inserted; ②The product will not automatically delete the locked files, the TF card is less he TF card lock file ②T than 300 MB of storage space, products files need regular clean up, if not the TF...
-
Page 26: System Parameter
6 - System Parameters 7 - Accessories Standard Voltage：DC 10.5V-16V Host Unit 1piece Working Current：MAX 1.5A TF card 1pcs Standby Current: Non anti-theft mode ≤6MA ,anti-theft mode ≤15mA Power line 1set Left&right lens line 1pcs Working Temp：-20°C ~ + 60°C Easy connect extension cord 1pcs Stock Temp：-40°C ~ + 85°C NAV receiver antenna... - Page 27 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
- Page 28 For customer or technical support please call Voxx Support: 1-800-645-4994 9 AM – 6 PM (EST - Eastern) Monday – Friday VOXX Electronics Corporation, 150 Marcus Blvd., Hauppauge, New York 11788 Patented www.voxxintl.com/company/patents...
