- Page 1 AcuDis115 User Manual Acura Embedded Systems Inc.
-
Page 2: Table Of Contents
Table of Contents_____________________ Chapter 1 Getting Started 1.1 Features of AcuDis115...…………………………………………………….1 1.2 Specifications…………………………………………..……..……….….1 1.3 Dimensions…………………………………...…………………..……….…2 1.4 Brief Description ……………..……………………......…….3 1.5 Display Mode………………………………………………………………..3 Chapter 2 2.1 AD Board OSD Functions………………………….…..……………….…...4 2.2 OSD Controls………………..…..…………………………………………..5 2.3 OSD Default Parameter…..………………………………………………..5 2.4 Main Menu………………………………………………………………..…6 Chapter 3 Installation 3.1 Introduction to the PenMount 9036 Controller Board………….….……..9... -
Page 3: Chapter 1 Getting Started
Chapter 1 Getting Started 1.1 Features of AcuDis115 • Solid Aluminum Die-casting chassis • Variety of LCD panel size selections • Front bezel IP65 • VGA/DVI input • 9~36V DC wide range power input 1.2 Specifications Hardware Display Type 15”... -
Page 4: Dimensions
1.3 Dimensions Figure 1.4: Dimensions of AcuDis115 ACUDIS115 User Manual... -
Page 5: Brief Description
AcuDis115 is a total IP65 aluminum front bezel and chassis LCD Display, which comes with a 15 inch (luminance of 350 cd/m²) TFT LCD. AcuDis115 comes with a viewing angle of 160 (H) degrees and 145 (V) degrees. AcuDis115 has more outstanding features, thus giving you the best in monitoring and control applications. -
Page 6: Ad Board Osd Functions
Please don’t let your fingers go until the AC power cord is connected again and the wording of “RGB” appears on the top left corner of your screen, and wait for 3 second. Under the non-signal entry situation, if is seen, exit is thus successfully made. Cable Not Connected ACUDIS115 User Manual... -
Page 7: Osd Controls
2.3 OSD Default Parameter Management Luminance Blue Language English H. Position auto Brightness V. Position auto Contrast Green H. Position Auto Pixel Clock auto Sharpness Mute V. Position Auto Phase auto Color 6500 Volume OSD time Auto ACUDIS115 User Manual... -
Page 8: Main Menu
For Management list, there are the following: H. Position V. Position Pixel Clock Phase Exit For Color list, there are the following: • 9300 • 6500 • 5400 • User Preset • Exit ACUDIS115 User Manual... - Page 9 For Volume list, there are the following: • Volume • Mute • Exit For OSD list, there are the following: H. Position V. Position OSD Time Exit ACUDIS115 User Manual...
- Page 10 • 繁體中文 • 简体中文 • Portuguese • 한국의 • Pусский For Recall list, there are the following: • Recall Color • Recall All • Exit For Information list, there are the following: • Display Information • Exit ACUDIS115 User Manual...
-
Page 11: Introduction To The Penmount 9036 Controller Board
Chapter 3___________________ Installation 3.1 Introduction to Touch Screen Controller Board AcuDis115's touch screen is PenMount 6300 USB control board which is designed for USB interface and specific for 4, 5, 8-wire touch screens. It is designed with USB interface features with multiple devices supporting function. - Page 12 Step 3. A License Agreement appears. Click IAgree“…” and Next”“ Step 4. Choose the folder in which to install PenMount Windows Universal Driver. Click Install. Step 5. Wait for installation. Click Next to continue. Step 6. Click OK. Step 7. Click Finish to complete installation. ACUDIS115 User Manual...
-
Page 13: Software Functions
Advanced Calibration Advanced Calibration uses 4, 9, 16 or 25 points to effectively calibrate touch panel linearity of aged touch screens. Click this button and touch the red squares in sequence with a stylus. To skip, press ESC’. ACUDIS115 User Manual... - Page 14 Calibration 4=Advanced Calibration 4 9=Advanced Calibration 9 16=Advanced Calibration 16 25=Advanced Calibration 25 Step 1. Please select a device then click “Configure”. You can also double click the device too. Step 2.Click “Standard Calibration” to start calibration procedure ACUDIS115 User Manual...
- Page 15 NOTE: The older the touch screen, the more Advanced Mode calibration points you need for an accurate calibration. Use a stylus during Advanced Calibration for greater accuracy. Please follow the step as below: Step 3.Come back to “PenMount Control Panel” and select “Tools” then Click “Advanced Calibration”. ACUDIS115 User Manual...
- Page 16 Select “Device” to calibrate, then you can start to do “Advanced Calibration”. NOTE: Recommend to use a stylus during Advanced Calibration for greater accuracy. ACUDIS115 User Manual...
- Page 17 Setting About This panel displays information about the PenMount controller and driver version. ACUDIS115 User Manual...
- Page 18 Rotating function is disabled. Enable the multiple display function as follows: Step 1. Check the Multiple Monitor Support box; then click Map Touch Screens to assign touch controllers to displays. Step 2. When the mapping screen message appears, click “OK” ACUDIS115 User Manual...
- Page 19 Calibration Calibration function Right Button Enable right button Icon function. The icon can show on Desktop or System Tray (menu bar). About You can see how many devices of PenMount controller that are plugged to your system ACUDIS115 User Manual...
- Page 20 2. Choose the rotate function (0°, 90°, 180°, 270°) in the 3rd party software. The calibration screen appears automatically. Touch this point and rotation is mapped. NOTE: The Rotate function is disabled if you use Monitor Mapping ACUDIS115 User Manual...
- Page 21 With the unique set of products, Acura Embedded Systems remains committed to its goal of providing trouble- free and customer-friendly service. A special customer service unit has been set up specifically to cater to our esteemed customers' needs. Technical Support:...
