- Page 1 Spectralink DECT Repeater Installation Guide 14183300-IG, Edition 5.0 January 2018, Original document...
- Page 2 The drawings and specifications contained herein are the property of Spectralink and shall be neither reproduced in whole or in part without the prior written approval of Spectralink, nor be implied to grant any license to make, use, or sell equipment manufactured in accordance herewith.
-
Page 3: Table Of Contents
Content of the Spectralink Programming Kit Repeater Set up of the Hardware for Repeater Programming Programming the Spectralink DECT Repeater with the Service Tool Numbering of Base Stations and Repeaters in a Normal Configuration Numbering of Repeaters in a Repeater Jump Configuration Using the Spectralink DECT Repeater With External Antenna13... -
Page 4: About This Guide
This guide explains how to install the Spectralink DECT Repeater. This guide is intended for qualified technicians and the reader is assumed to have a basic knowledge about the Spectralink IP-DECT/DECT Server, Spectralink IP-DECT/DECT Base Station and Spec- tralink DECT Repeater. - Page 5 Spectralink DECT Repeater Installation Guide Subject Documentation Spectralink DECT Training material In order to gain access to the Spectralink training mater- ial, you must attend training and become Spectralink Cer- tified Specialist. Please visit http://- partneraccess.spectralink.com/training/classroom-train- for more information and registration.
-
Page 6: Installing The Spectralink Dect Repeater
Two mounting screws and anchors Description of Repeater The Spectralink DECT Repeater is a building block to be used to extend the coverage area in a wire- less Spectralink DECT solution. The repeater does not increase the number of traffic channels, how- ever it provides a larger physical spreading of the traffic channels and thereby increases the coverage area established with the Spectralink IP-DECTIP-DECT/DECT Base Stations. -
Page 7: Repeater Appearance And Components
Spectralink DECT Repeater Installation Guide Repeater Appearance and Components Below you will find a description of the repeater appearance and components: DECT Repeater - bottom DECT Repeater - rear RJ9 port Holes for wall mounted screws External antenna connector DECT Repeater - front 14183300-IG, Edition 5.0... -
Page 8: Repeater Led Indicators
Spectralink DECT Repeater Installation Guide Repeater LED Indicators Below you will find information about LED indicators on the repeater. Front Cover LED Indicator Meaning Indicator Off The repeater is not powered. Flashing Repeater has been powered, sync has still not been established. -
Page 9: How To Wall Mount The Repeater
Spectralink DECT Repeater Installation Guide How to Wall Mount the Repeater For best RF coverage, the device must be mounted vertically on walls. Caution: The repeater and external antenna is to be fixed-mounted on indoor permanent struc- tures providing a separation distance of at least 20 cm/8 inches from all persons during normal operation and must not be co-located or operating in conjunction with any other antenna or repeater. -
Page 10: Programming A Spectralink Dect Repeater With The Spec- Tralink Programming Kit
Spectralink DECT Repeater Installation Guide Programming a Spectralink DECT Repeater with the Spectralink Pro- gramming Kit Content of the Spectralink Programming Kit Repeater The Programming Kit Repeater (Part no. 02509210) consists of: Splitter Programming tool with RJ-Connector USB cable Set up of the Hardware for Repeater Programming It is recommended that you carry out the set up in the following order: 1. -
Page 11: Programming The Spectralink Dect Repeater With The Service Tool
Service Tool, refer to the Help File in the Service Tool. The Service Tool identifies the type of repeater, and with this software it is possible to program the Spectralink DECT Repeater to connect to the Spectralink DECT Radio Infrastructure solutions. Note: Before you start programming the repeater, ensure that the repeater is connected to the computer and the mains. -
Page 12: Numbering Of Repeaters In A Repeater Jump Configuration
Spectralink DECT Repeater Installation Guide Numbering of Repeaters in a Repeater Jump Con- figuration First Repeater in Chain RPN of base station + 64 Base to synchronize on: RPN of base station Second Repeater in Chain RPN of base station + 128... -
Page 13: Using The Spectralink Dect Repeater With External Antenna13
Note: Inside the area named "radio link" there is no radio coverage for handsets. If a situation occurs where the primary sync for some reason breaks down, the Spectralink DECT Repeater will obtain sync on the alternative sync. 14183300-IG, Edition 5.0... -
Page 14: Alternative Synchronization Ways
Spectralink DECT Repeater Installation Guide Alternative Synchronization Ways The Spectralink DECT Repeater with or without external antenna, 4 channels, can be programmed to obtain synchronization on two radio units (base station, wireless server 400 or repeater). Note: The primary sync has priority; the alternative sync is only in use as long as the primary sync is down. -
Page 15: Product Compatibility
If you have any questions about product compatibility, contact your system administrator. You can use the Spectralink DECT Repeater with other Spectralink products as identified by the type approval model ID and/or part number located on the label of the product. - Page 16 Spectralink DECT Repeater Installation Guide Spectralink Server Spectralink IP-DECT Server 400 K005 (0234 4500/0234 4501) Spectralink IP-DECT Server 6500 K006 (0235 0000) Spectralink DECT Server 2500 K017 (0270 xxxx) Spectralink DECT Server 8000 K016 (0233 89xx) Power Supply, 19.0V (only Server 2500) 8476 9905 Power Supply, 19.0V (only Server 8000)
