Tumble Dryer
OWNER'S MANUAL
MODEL:DRY.CR.CON.7KG
Read This Manual
Inside you will find many helpful hints on how to use
and maintain your tumble dryer properly. Just a little
preventative care on your part can save you a great
deal of time and money over the life of your tumble
dryer. You'll find many answers to common problems
in the chart of troubleshooting tips. If you review the
chart of troubleshooting tips first, you may not need
to call for service.
CAUTION: HOT SURFACE !
CAUTION: RISK OF FIRE !
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vogue DRY.CR.CON.7KG
Summary of Contents for Vogue DRY.CR.CON.7KG
-
Page 1: Tumble Dryer
Tumble Dryer OWNER’S MANUAL MODEL:DRY.CR.CON.7KG Read This Manual Inside you will find many helpful hints on how to use and maintain your tumble dryer properly. Just a little preventative care on your part can save you a great deal of time and money over the life of your tumble dryer. -
Page 2: Table Of Contents
Contents Safety information..............1 Installation................6 Part description................7 Attention and advice..............9 Description of controls.............10 Operation instruction...............11 Programme table..............12 Specialty drying function............13 Cleaning and routine maintenance..........15 Alarm function.................16 Precautions................17 Technical specifications ............18... -
Page 3: Safety Information
Safety information Dry care symbols Please pay attention to use the drying machine if the materials of your clothes can not be dried by it or contain the symbols as follows: Normal Not tumble dry normal Do not dry Line dry / hang to dry Drip dry Dry flat In the shade... - Page 4 Safety information 5.The tumble dryer is not to be used if industrial chemicals have been used for cleaning. 6.The lint trap has to be cleaned frequently. 7.Lint must not to be allowed to accumulate around the tumble dryer. 8.Adequate ventilation has to be provided to avoid the back flow of gases into the room from appliance burning other fuels, including open fires.
- Page 5 Safety information 16.The appliance must not be install behind a lockable door, a sliding door or a door with a hinge on the opposite side to that of the tumble dryer. In such a way that a full opening of the tumble dryer door is restricted.
- Page 6 Safety information 22.If the power cable is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. 23.This appliance is for indoor use only. 24.The openings must not be obstructed by a carpet. 25.Children of less than 3 years should be kept away unless continuously supervised.
- Page 7 Safety information Electric shock hazard Do not draw the power cord forcefully to pull out the mains plug. 2.Please do not plug/draw the mains plug with wet hands. 3.Do not damage the power cord and the power plug. Injury danger Do not disassemble and install the dryer under no instruction or supervision.
-
Page 8: Installation
Installation Transport ove cautiously. Do not grasp any salient parts of machine. The machine door can not be used as the handle for delivery. Installation position 1.Please install the dryer on solid and flat ground. 2.Please do not place the dryer on the slope, soft carpet or wooden floor. 3.Please do not install the dryer outdoors, to prevent the dryer from being frozen to damage of machine parts. -
Page 9: Part Description
Part description Part description Control Panel Container Door Power Cord Lint filter Handle Maintenance flap Accessories The following parts are optional for specific models. If your dryer has following parts, please wear gloves and install them following the instruction below . Hose holder(optional) Condensing drain hose(optional) -
Page 10: Quick Start
Part description Step 3: put the hose holder on the washing basin or any other sink. 200cm Quick start 1. Open the door and 10.Unplug the power cord load the laundry 9.Press the 【On/Off】button 2 Close the machine door 8. Clean the lint filter 3 Plug the power cord and empty container 4.Press the 【On/Off】button... -
Page 11: Attention And Advice
Attention & Advice Attention Before the first cycle, the dust and grease may remain in this dryer during the period of manufacture and transportation, to avoid contaminating your clothes, please follow these steps: a)Put some clean rags into the drum. b)Plug the power. -
Page 12: Description Of Controls
Description of controls 1.Programme Selection knob 2.Display 3.Specialty function buttons 4.Start/Pause button 5.On/Off button Display Delay start Child lock Remaining Time indicator/Error message Cycle phase status Clean filter (warning) Empty water container (warning) Dryness level (four grades) Speed dry indicator Signal indicator Anti-crease mode... -
Page 13: Operation Instruction
Operation instruction Select the programme 1.Press the【On/Off 】 button ,when the LED display screen brighten up, rotate the programme knob to select the desired programme. 2.Select the【Delay】,【Time】,【Intensity】,【Speed Dry】,【Signal】or【Anti-Crease】 functions for additional option. 3.Press the【Start/Pause】button. Programme start The drum will keep rotating after the programme start, the state light in the display area will flash in sequence, the remaining time displayed will change automatically. -
Page 15: Specialty Drying Function
Specialty drying function Specialty drying function 【 】 1. Instruction to the Delay drying procedure To delay the drying programme from 0 hour to 24 hours. The delay time means the programme will start after x hours. When the delay programme starts, the time starts to decrease on the display and the icon blinks. - Page 16 Special drying function 【Speed dry】 5. Instruction of the Used to curtail the time of drying. 】 【 Signal Set up the buzzer on or off. In the general condition, the buzzer is on. Please press it if needed. When the buzzer on: (1) The dryer will give the leading sound if press the extra function buttons.
-
Page 17: Cleaning And Routine Maintenance
Cleaning and routine maintenance Clean the lint filter Leave the dryer to cool down 1.Open the machine door. 2.Take out the lint filter, pull upward to take it out. 3.Clean the lint filter; wipe off the scrap threads accumulated on the lint filter, with your hand or rinse with water and dry thoroughly. -
Page 18: Empty The Water Container
Cleaning and routine maintenance & Alarm function Empty the water container 1.Hold and pull out the water container with two hands. 2.Tilt the water container, pour out the condensed water. 3.Insert the water container. WARNING: 1.Empty the water container after each use, the programme will be paused and the “ ”... -
Page 19: Precautions
Precautions Precautions Only authorised technicans can carry out repairs. Before you call customer service, please check if you have deal with the faulty by yourself or if you have follow the user instructions. A technician will charge you for advice, even during the warranty period. Problem Solution •The mains plug is inserted. -
Page 20: Technical Specification
Technical specification Specification Power supply 220-240V~ 50Hz Rated input Power 2000W 。 。 Ambient temperature +5c +35c 615×595×845(mm) Overall Size (LxWxH) Rated Drying Capacity 7.0kg Net Weight 42kg Note: 1.The rated capacity is the maximum capacity, make sure that the dry clothes which are loaded to the appliance do not exceed the rated capacity each time.
