Note battery orientation
Configuration Changes
The P161 uses the standard Alert-iT Programming Data Protocol and all the main fea-
tures can be changed using the P152 USB Interface and Data Editor Programme.
Communication Address Changes
Each badge in a care home MUST have a different communication address. To facili-
tate easy installation the Communication Address can also be changed directly from
the pager using the P173A programming cable
Safelink Radio
The Securelink failsafe feature is enabled by fitting the link shown, if not required then
park the link on one pin only.
The battery MUST be re-
moved to activate any change,
after which the HELP key is
pressed to re-energise the
monitor.
Configuration
UH1115 P161B Door Activity Handbook.ppp page 7 of 12
Avoid damage to aerial
Push battery out from here
Add to enable Securelink
