AV Proconnect AC-EX70-444-KIT User Manual

Ultra slim 70m (100m hd) 4k60 4:4:4, hdr hdbaset extender audio extraction, edid management, scaling & ethernet
Hide thumbs

Advertisement

Quick Links

Download this manual
AC-EX70-444-KIT
AC-EX70-444-KIT
Ultra Slim 70m (100m HD) 4K60 4:4:4,
HDR HDBaseT Extender Audio
Extraction, EDID Management, Scaling &
Ethernet
A V P r o C o n n e c t
3 5 1 8 N C a s c o A v e n u e ~ S i o u x F a l l s , S D 5 7 1 0 4
1 - 8 7 7 - 8 8 6 - 5 1 1 2 ~ 6 0 5 - 2 7 4 - 6 0 5 5
s u p p o r t @ a v p r o c o n n e c t . c o m
pg. 1
AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~
support@avproconnect.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the AC-EX70-444-KIT and is the answer not in the manual?

Questions and answers

Related Manuals for AV Proconnect AC-EX70-444-KIT

Summary of Contents for AV Proconnect AC-EX70-444-KIT

  • Page 1 AC-EX70-444-KIT AC-EX70-444-KIT Ultra Slim 70m (100m HD) 4K60 4:4:4, HDR HDBaseT Extender Audio Extraction, EDID Management, Scaling & Ethernet A V P r o C o n n e c t 3 5 1 8 N C a s c o A v e n u e ~ S i o u x F a l l s , S D 5 7 1 0 4 1 - 8 7 7 - 8 8 6 - 5 1 1 2 ~ 6 0 5 - 2 7 4 - 6 0 5 5 s u p p o r t @ a v p r o c o n n e c t .
  • Page 2 AC-EX70-444-KIT AVProConnect presents its 70m (100m HD) 18Gbps over CAT extender. Using ICT (Invisible Compression Technology) we have achieved what was thought to be impossible. AC-EX70-444 delivers a virtually lossless, high bandwidth, 4K HDR signal with support for any signals up to 18Gbps.

  • Page 3: Product Overview

    AC-EX70-444-KIT Product Overview ■ Model Numbers: ■ AC-EX70-444-T ~ HDBaseT Transmitter w/ Audio Extraction, IR, • RS-232, EDID, Bi-Directional PoE and Scaler AC-EX70-444-R ~ HDBaseT Receiver w/ IR, RS-232, Bi-Directional • Features ■ • HDMI 2.0(a/b) • 18Gbps Bandwidth Support (Using ICT) •...
  • Page 4 AC-EX70-444-KIT  Notice AVProConnect reserves all rights to make changes in the hardware, packaging and any accompanying documentation without prior written notice. Warning To reduce the risk of fire, electric shock or product damage: 1. Do not expose this device to 6.

  • Page 5: What's Included

    AC-EX70-444-KIT What's Included ■ Whats in the box? • AC-EX70-444-T (Transmitter) AC-EX70-444-R (Receiver) • • 48V Power Supply (One supplied) 1x IR Tx Unit • 1x IR Rx Unit • • 4x 3 Pin Terminal blocks for Audio and RS232 Ports Mounting Ears •...

  • Page 6: Specifications

    AC-EX70-444-KIT Specifications ■ pg. 6 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 7 AC-EX70-444-KIT The Transmitter L/R Out (PCM Only) HDBaseT Back ■ RS232 HDMI In Ethernet Ports COM & Pass-through) 10/100 Front IR In IR Out IR Mode Micro USB (Firmware) Indicator Troubleshooting Lights on the Transmitter: POWER - On the front: (Red) This is an indicator that the power is connected.
  • Page 8 AC-EX70-444-KIT Indicator Troubleshooting Lights on the Transmitter cont.: LINK - Above RJ45 (HDBT) Port: (Green) This indicator shows that the AV HDBT link between the Tx and Rx is in tact. This light should ALWAYS be solid. If this light is flashing or not present attempt following: 1.
  • Page 9 AC-EX70-444-KIT Functions & Setup of the Transmitter: IR Mode Slide Switch: (On Front) This is used to select a preferred IR Mode - There are two modes: • IR-EYE - The IR Input will be configured to operate with an IR Receiver Eye.
  • Page 10 AC-EX70-444-KIT Functions & Setup of the Transmitter Cont.: Test Pattern Generator: Press and hold the setting button (for 4 seconds) while powering up the transmitter. You should see the color bar pattern to the right on screen. When in this mode, you can quick press to toggle the resolution.
  • Page 11 AC-EX70-444-KIT The Receiver ■ L/R Out (PCM Only) HDBaseT Back RS232 HDMI In Ethernet Ports COM & Pass-through) 10/100 Front IR In IR Out PoE Setting Micro USB (Choose where PoE (Firmware) Originates) Indicator Troubleshooting Lights on the Receiver: POWER - On the front: (Red) This is an indicator that the power is connected.
  • Page 12 AC-EX70-444-KIT Indicator Troubleshooting Lights on the Receiver cont.: LINK - Above RJ45 (HDBT) Port: (Green) This indicator shows that the AV HDBT link between the Transmitter and Receiver is in tact. This light will ALWAYS be solid. If this light is flashing or not present do the following: 1.
  • Page 13 AC-EX70-444-KIT Functions & Setup of the Receiver: PoE Mode Slide Switch: (On the front) This is used to select how you want to PoE is to be directed. There are two options (you are choosing where the power is ORIGINATING from): •...
  • Page 14 AC-EX70-444-KIT RS-232 Configuration ■ RS-232 can be used to pass control signals bi-directionally to & from any RS-232 compatible device. This is commonly used to route control signals in the following way: 1. Control System --> Display/Projector (ie, Power On/Off) 2.
  • Page 15 AC-EX70-444-KIT RS-232 Cable Prep ■ RS-232 Sample Application ■ pg. 15 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ support@avproconnect.com...
  • Page 16 AC-EX70-444-KIT IR Configuration ■ IR can be used in three ways: 1. From Rack (Control System Direct): Plug a MONO 3.5mm cable into an emitter port of any control system directly into the "IR IN" port on the AC-EX40-444 Transmitter to pass IR signals directly to the remote end.
  • Page 17 AC-EX70-444-KIT IR Connections to AC-EX70-444-T (Transmitter) ■ IR IN Direct Connect (I-PASS) IR OUT Emitter (Non-Flashing) IR IN w/ Receiver Eye ("IR-EYE" MODE) IR Connections to AC-EX70-444-R (Receivers) ■ IR IN (IR-EYE Only) IR OUT Emitter (Non-Flashing) pg. 17 AVProConnect ~ 3518 N Casco Ave. Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~...
  • Page 18 AC-EX70-444-KIT Audio Extraction on AC-EX70-444 ■ A feature that is always active on the AC-EX70-444 (Tx and Rx) is Audio Extraction. This feature extracts PCM Audio (2ch) from the source device in order to be run to a separate amplifier or AVR. BOTH of the audio ports are always active (on Tx &...
  • Page 19 AC-EX70-444-KIT Stereo Cable Preparation ■ NOTE: Pre-made audio cables can be purchased from www.avprostore.com. The part number is: AC-CABLE-3PIN-2CH. Using Ethernet: ■ Ethernet usage is very straight-forward. It is used for driving network communication over the HDbaseT link. This of these ports as a "hub", if you plug one port into a router all the other ports on both the Tx & Rx now have access to the network.
  • Page 20 AC-EX70-444-KIT Maintenance ■ Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzene to clean this unit. Damage Requiring Service: The unit should be serviced by qualified service personnel if: The DC power supply cord or AC adaptor has been damaged;...

  • Page 21: Warranty Limits And Exclusions

    AC-EX70-444-KIT ● Warranty Limits and Exclusions This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO DOES NOT COVER damages which occurred during shipment, failures which are...
  • Page 22 AC-EX70-444-KIT Thank you for choosing AVProConnect! Please contact us with any questions. We are happy to be of service! A V P r o C o n n e c t 3 5 1 8 N C a s c o A v e n u e ~ S i o u x F a l l s , S D 5 7 1 0 4 1 - 8 7 7 - 8 8 6 - 5 1 1 2 ~ 6 0 5 - 2 7 4 - 6 0 5 5 s u p p o r t @ a v p r o c o n n e c t .
