Procedures
When the DHCP Server Is Not in the Network
If the DHCP server is not in the network, perform the following procedure to set the network parameters.
11. If you connect the MTX100B directory to a single PC:
In the dialog box, select Use the following IP address.
Set the IP address parameter to be the same IP address as the PC's address except for the last number. The last
number must be different from the last number in the PC's IP address.
Set the Subnet mask parameter to be the same net mask (subnet mask) used by the PC. Do not enter a number if
the PC does not have a net mask.
You do not need to enter a Default gateway if you are directly connected to a single PC.
12. If you connect the MTX100B to your local Ethernet network:
In the dialog box, select Use the following IP address.
Ask your local network administrator and set the appropriate addresses.
CAUTION. To prevent communication conflicts on your Ethernet network, ask your local network administrator for the correct
numbers to enter in the dialog box if you connect the MTX100B to your local Ethernet network.
13. Verify the Ethernet connection by using a ping command from the PC.
34 MTX100B MPEG Recorder and Player
