- Page 1 Z-Verb Manual Model: ZA-28 www.drzamps.com...
- Page 2 This symbol warns the user of dangerous voltage levels localized within the enclosure. This symbol advises the user to read all accompanying literature for safely opera�ng the unit Important Safety Instruc�ons 1) Read these instruc�ons. 2) Keep these instruc�ons. 3) Heed all warnings. 4) Follow all instruc�ons.
- Page 3 General Informa�on Bust out the sur�oards boys and girls…�me to ride the crest of the Z Verb! Dr Z’s first all tube spring reverb unit is finally here. The Z Verb will handle all of your reverbera�on needs. Anything from subtle ambience to full on space explora�on…the Z Verb can do it. With a classic 3 knob set up (Dwell, Mix, and Tone) you can control all parameters of your reverb.
- Page 4 FRONT PANEL 1. Input: Input jack for your guitar or input from “send” jack when using your amp’s FX loop. 2. Tone: Controls overall tone of reverb. 3. Mix: Controls dry/wet mix. Turn clockwise to add reverb. 4. Output: Output jack. You can send signal to the input jack of your amp or to the “return” jack when using your amp’s FX loop.
- Page 5 MODEL: ___________________ SERIAL NUMBER: ___________ INPUT VOLTAGE: ____________ MADE IN USA...
- Page 7 EC/EU Declaration of Conformity Document: CE – ZA-28 Manufacturer: Dr. Z Ampli cation 17011 Broadway Ave. Maple Heights, OH 44137 -3407 We declare that the designated product (s) DR. Z Z-VERB are in conformity with the European Directives: 2014/30/EU EMC Directive of 26 February 2014 20 11/65/EU RoHS Directive of 8 June 2011 Electrical equipment designed for use within certain voltage limits...
